FTC881 First Start

FTC881

> FTC881 First Start

Small and smart tracker

Contents

1 HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY

HOW TO INSERT MICRO-SIM CARD AND CONNECT THE

BATTERY

Gently remove FTC881 cover using plastic pry tool from one side.

Gently remove FTC881 cover using plastic pry tool from another side.

Insert Nano-SIM card as shown. Make sure that Nano-SIM card cut-off corner is pointing

forward to slot.

Connect the battery as shown on device. Make sure that "+" is pointing to SIM-slot, "-" is

pointing to GNSS antenna.

Attach device cover back. Device is ready to be connected.

Nano-SIM card insertion/removal must be performed when device is powered off –

external voltage and internal battery disconnected. Otherwise Nano-SIM card might be

damaged or device will not detect it.

PC CONNECTION (WINDOWS)

1. Power- up FTC881 with DC voltage (10-90V) power supply using power wires. LEDs should start

blinking.

2. Connect device to computer using Micro-USB cable and install USB driver, see "How to install

USB drivers (Windows)1"
