Teltonika FTC961 First Start-Up Quick Start Manual

Small and smart waterproof tracker

Hide thumbs Also See for FTC961:

https://wiki.teltonika-gps.com/view/FTC961_First_Start

FTC961 First Start

FTC961

> FTC961 First Start

Small and smart waterproof tracker

Contents

1 HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY

HOW TO INSERT MICRO-SIM CARD AND CONNECT THE

BATTERY

Gently remove FTC961 side cover using plastic pry tool

Insert Nano-SIM card as shown. Make sure that Nano-SIM card cut-off corner is pointing

towards SIM slot.

Battery is already connected, so after configuring device fully close casing

Device is ready to be mounted.

Nano-SIM card insertion/removal must be performed when device is powered off –

external voltage and internal battery disconnected. Otherwise Nano-SIM card might be

damaged or device will not detect it.

PC CONNECTION (WINDOWS)

1. Power- up FTC961 with DC voltage (10-70V) power supply using power wires. LEDs should start

blinking.

2. Connect device to computer using Micro-USB cable and install USB driver, see "How to install

USB drivers (Windows)"

Table of Contents

Do you have a question about the FTC961 and is the answer not in the manual?

Page 1 PC CONNECTION (WINDOWS) 1. Power- up FTC961 with DC voltage (10-70V) power supply using power wires. LEDs should start blinking. 2. Connect device to computer using Micro-USB cable and install USB driver, see “How to install...
Page 2 5. Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. CONFIGURATION (WINDOWS) At first FTC961 device will have default factory settings set. These settings should be changed according to the user's needs. Main configuration can be performed via Teltonika Configurator tool (TCT).
