PART NUMBERING SYSTEM

DNS 04
Product
Input Voltage
Series
DNS - 6A 04 - 2.8~5.5V
DNM - 10A 10 –8.3~14V
DNL - 16A

MODEL LIST

Model Name Packaging
DNS04S0A0S06NFD SMD
DNS04S0A0S06PFD SMD
DNS04S0A0R06NFD SIP
DNS04S0A0R06PFD SIP
CONTACT: www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email: DCDC@delta-corp.com
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta
for its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license
is granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these
specifications at any time, without notice
DS_DNS04SIP06A_07172008
S 0A0
Numbers of Output Package
Outputs Voltage
S - Single 0A0 - R - SIP
Programmable
S - SMD
Input Voltage
2.8 ~ 5.5Vdc
2.8 ~ 5.5Vdc
2.8 ~ 5.5Vdc
2.8 ~ 5.5Vdc
Europe:
Telephone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email: DCDC@delta-es.tw
.
R 06 P
On/Off
Output
logic
Type Current
06 - 6A N- negative
10 - 10A P- positive
16 - 16A
Output Voltage Output Current
0.75 V~ 3.3Vdc
0.75 V~ 3.3Vdc
0.75 V~ 3.3Vdc
0.75 V~ 3.3Vdc
Asia & the rest of world:
Telephone: +886 3 4526107 x6220
Fax: +886 3 4513485
Email:
F D
Option Code
D - Standard Function
F- RoHS 6/6
(Lead Free)
Efficiency
5.0Vin, 3.3Vdc @ 6A
6A 94.0%
6A 94.0%
6A 94.0%
6A 94.0%
