Delta Electronics L36SA Datasheet

Delphi Series L36SA, 2"x1.6", 50W Family
DC/DC Power Modules: 18~75Vin, 3.3V, 5V, 12Vout
The Delphi Series L36SA, 2"x1.6", 18V~75V input, single output,
isolated DC/DC converter is the latest offering from a world leader in
power systems technology and manufacturing - Delta Electronics, Inc.
The L36SA series provides up to 50 watts of power or 15A of output
current (3.3V) in an industry standard 2x1.6 form factor and pinout. The
Delphi L36SA series operates from a wide 18V to 75V (4:1) input
voltages. With creative design technology and optimization of
component placement, these converters possess outstanding electrical
and thermal performance, as well as extremely high reliability under
highly stressful operating conditions. All models are fully protected from
abnormal input/output voltage, current, and temperature conditions.
The Delphi Series converters meet all safety requirements with basic
insulation. An optional heat spreader is available for extended
operation.
DATABRIEF
DB_L36SA_02142007
FEATURES
High efficiency: 89% @ 5V/ 10A
Size: 49.6mm x 39.4mm x 8.9mm
(1.95"x1.55"x0.35")
Industry standard pin out
Fixed frequency operation
Input UVLO, OTP, Output OCP, OVP
(auto-restart)
Monotonic startup into normal and
pre-biased loads
2250V isolation and basic insulation
No minimum load required
4:1 input voltage range
ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing
facility
UL/cUL 60950 (US & Canada)
Recognized, and TUV (EN60950) certified
CE mark meets 73/23/EEC and
93/68/EEC directives
OPTIONS
Positive On/Off logic
Sense
Heat spreader
APPLICATIONS
Telecom/DataCom
Wireless Networks
Optical Network Equipment
Server and Data Storage
Industrial/Test Equipment
