PART NUMBERING SYSTEM
NE
12
Product
Input
Number of
Series
Voltage
outputs
NE-
12- 4.5~13.8V S- Single
Non-isolated
output
Series
MODEL LIST
Model Name
Packaging
NE12S0A0V20PNFA
Vertical
NE12S0A0H20PNFA
Horizontal
CONTACT:
www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
DCDC@delta-corp.com
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta
for its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license
is granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these
specifications at any time, without notice
Preliminary DS_NE12S20A_07272007
S
0A0
Output Voltage
Mounting
0A0 - programmable V- Vertical
H- Horizontal
Input Voltage
4.5V~ 13.8Vdc
4.5V~ 13.8Vdc
Europe:
Telephone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
DCDC@delta-es.tw
.
V
20
P
Output
ON/OFF
Current
Logic
20-20A
P- Positive
N- Negative
Output Voltage
Output Current
0.59V~ 5.1Vdc
20A
0.59V~ 5.1Vdc
20A
Asia & the rest of world:
Telephone: +886 3 4526107 ext. 6220
Fax: +886 3 4513485
Email:
N
F
A
Pin
Option
Length
Code
A-standard
N- 0.150"
F- RoHS 6/6
function
(Lead Free)
Efficiency
12Vin @ 100% load
94.0%@5Vout
94.0%@5Vout
DCDC@delta.com.tw
12
