Delta Electronics Delphi Series DNS Datasheet page 5

ELECTRICAL CHARACTERISTICS CURVES (CON.)
Figure 13: Turn on delay time at 5Vin, 3.3V/6A out
Figure 15: Turn on delay time at remote turn on 5Vin, 3.3V/16A
out
Figure 17: Turn on delay time at remote turn on with external
capacitors (Co= 5000 µF) 5Vin, 3.3V/16A out
DS_DNS04SIP06A_07172008
Figure 14: Turn on delay time at 5Vin, 1.8V/6A out
Figure 16: Turn on delay time at remote turn on 3.3Vin, 2.5V/16A
out
Figure 18: Turn on delay time at remote turn on with external
capacitors (Co= 5000 µF) 3.3Vin, 2.5V/16A out
5
