Delta Electronics Series DNT12 Specification Sheet

Delphi series DNT12 Non-Isolated Point of Load
DC/DC Power Modules: 8.3~14Vin, 0.75~5.5Vo, 3A/5A
The Delphi series DNT12, 8.3V~14V input, single output, non-isolated point of
load DC/DC converters are the latest offering from a world leader in power
systems technology and manufacturing － Delta Electronics, Inc. The DNT12
series provides a programmable output voltage from 0.75V to 5.5V using an
external resistor. This product family is available in a surface mount or SIP
package and provides up to 3A or 5A of current in an industry standard
footprint. With creative design technology and optimization of component
placement, these converters possess outstanding electrical and thermal
performance and extremely high reliability under highly stressful operating
conditions.
PRELIMINARY DATABRIEF
DB_DNT12_06252007
FEATURES
High Efficiency: 92.5% @ 12Vin, 5V/3A out
Small size and low profile:
0.80" x 0.45" x 0.27" (SMD)
0.90" x 0.40" x 0.25" (SIP)
Standard footprint and pinout
Resistor-based trim
Output voltage programmable from
0.75Vdc to 5.5Vdc via external resistors
Pre-bias startup
No minimum load required
Fixed frequency operation
Input UVLO, Output OTP, OCP
Remote ON/OFF
ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing facility
UL/cUL 60950 (US & Canada) Recognized,
and TUV (EN60950) - pending
CE mark meets 73/23/EEC and 93/68/EEC -
pending
OPTIONS
Positve On/Off logic
Surface mount and SIP packages
APPLICATIONS
Telecom/DataCom
Distributed power architectures
Servers and workstations
LAN/WAN applications
Data processing applications
