Delphi DNM, Non-Isolated Point of Load
DC/DC Power Modules: 2.8-5.5Vin, 0.75-3.3V/10A out
The Delphi Series DNM04, 2.8-5.5V input, single output, non-isolated
Point of Load DC/DC converters are the latest offering from a world
leader in power system and technology and manufacturing -- Delta
Electronics, Inc. The DNM04 series provides a programmable output
voltage from 0.75V to 3.3V using an external resistor. The DNM series
has flexible and programmable tracking and sequencing features to
enable a variety of startup voltages as well as sequencing and tracking
between power modules. This product family is available in a surface
mount or SIP package and provides up to 10A of current in an industry
standard footprint. With creative design technology and optimization of
component placement, these converters possess outstanding electrical
and thermal performance and extremely high reliability under highly
stressful operating conditions.
DATASHEET
DS_DNM04SIP10_07162008D
FEATURES
High efficiency: 96% @ 5.0Vin, 3.3V/10A out
Small size and low profile: (SIP)
50.8x 13.4x 8.5 mm (2.00" x 0.53" x 0.33")
Signle-in-line (SIP) packaging
Standard footprint
Voltage and resistor-based trim
Pre-bias startup
Output voltage tracking
No minimum load required
Output voltage programmable from
0.75Vdc to 3.3Vdc via external resistor
Fixed frequency operation
Input UVLO, output OTP, OCP
Remote ON/OFF
Remote sense
ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing facility
UL/cUL 60950 (US & Canada) Recognized,
and TUV (EN60950) Certified
CE mark meets 73/23/EEC and 93/68/EEC
directives
OPTIONS
Negative On/Off logic
Tracking feature
SIP package
APPLICATIONS
Telecom / DataCom
Distributed power architectures
Servers and workstations
LAN / WAN applications
Data processing applications
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Delta Electronics Series DNM04
Summary of Contents for Delta Electronics Series DNM04
- Page 1 Delphi DNM, Non-Isolated Point of Load DC/DC Power Modules: 2.8-5.5Vin, 0.75-3.3V/10A out The Delphi Series DNM04, 2.8-5.5V input, single output, non-isolated Point of Load DC/DC converters are the latest offering from a world leader in power system and technology and manufacturing -- Delta Electronics, Inc.
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS = 25°C, airflow rate = 300 LFM, V = 2.8Vdc and 5.5Vdc, nominal Vout unless otherwise noted.) PARAMETER ABSOLUTE MAXIMUM RATINGS Input Voltage (Continuous) Tracking Voltage Operating Temperature Storage Temperature INPUT CHARACTERISTICS Operating Input Voltage Input Under-Voltage Lockout Turn-On Voltage Threshold Turn-Off Voltage Threshold Maximum Input Current... - Page 3 ELECTRICAL CHARACTERISTICS CURVES OUTPUR CURRENT(A) Figure 1: Converter efficiency vs. output current (3.3V out) OUTPUR CURRENT(A) Figure 3: Converter efficiency vs. output current (1.8V out) OUTPUR CURRENT(A) Figure 5: Converter efficiency vs. output current (1.2V out) DS_DNM04SIP10_07162008D Vin=4.5V Vin=5.0V Vin=5.5V Figure 2: Converter efficiency vs.
- Page 4 ELECTRICAL CHARACTERISTICS CURVES Figure 7: Output ripple & noise at 3.3Vin, 2.5V/10A out Figure 9: Output ripple & noise at 5Vin, 3.3V/10A out Figure 11: Turn on delay time at 3.3Vin, 2.5V/10A out DS_DNM04SIP10_07162008D Figure 8: Output ripple & noise at 3.3Vin, 1.8V/10A out Figure 10: Output ripple &...
- Page 5 ELECTRICAL CHARACTERISTICS CURVES Figure 13: Turn on delay time at 5Vin, 3.3V/10A out Figure 15: Turn on delay time at remote turn on 5Vin, 3.3V/16A out Figure 17: Turn on delay time at remote turn on with external capacitors (Co= 5000 µF) 5Vin, 3.3V/16A out DS_DNM04SIP10_07162008D Figure 14: Turn on delay time at 5Vin, 1.8V/10A out Figure 16: Turn on delay time at remote turn on 3.3Vin, 2.5V/16A...
- Page 6 ELECTRICAL CHARACTERISTICS CURVES Figure 19: Typical transient response to step load change at 2.5A/μS from 100% to 50% of Io, max at 5Vin, 3.3Vout (Cout = 1uF ceramic, 10μF tantalum) Figure 21: Typical transient response to step load change at 2.5A/μS from 100% to 50% of Io, max at 5Vin, 1.8Vout (Cout =1uF ceramic, 10μF tantalum) DS_DNM04SIP10_07162008D...
- Page 7 ELECTRICAL CHARACTERISTICS CURVES Figure 23: Typical transient response to step load change at 2.5A/μS from 100% to 50% of Io, max at 3.3Vin, 2.5Vout (Cout =1uF ceramic, 10μF tantalum) Figure 25: Typical transient response to step load change at 2.5A/μS from 100% to 50% of Io, max at 3.3Vin, 1.8Vout (Cout =1uF ceramic, 10μF tantalum) Figure 27: Output short circuit current 5Vin, 0.75Vout DS_DNM04SIP10_07162008D...
-
Page 8: Test Configurations
TEST CONFIGURATIONS TO OSCILLOSCOPE 100uF BATTERY Tantalum Note: Input reflected-ripple current is measured with a simulated source inductance. Current is measured at the input of the module. Figure 29: Input reflected-ripple test setup COPPER STRIP 10uF SCOPE tantalum ceramic Note: Use a 10μF tantalum and 1μF capacitor. Scope measurement should be made using a BNC cable. -
Page 9: Features Descriptions
DESIGN CONSIDERATIONS (CON.) The power module should be connected to a low ac-impedance input source. Highly inductive source impedances can affect the stability of the module. An input capacitance must be placed close to the modules input pins to filter ripple current and ensure module stability in the presence of inductive traces that supply the input voltage to the module. -
Page 10: Over Temperature Protection
FEATURES DESCRIPTIONS (CON.) Over-Temperature Protection The over-temperature protection consists of circuitry that provides protection from thermal damage. If the temperature exceeds the over-temperature threshold the module will shut down. The module will try to restart after shutdown. If the over-temperature condition still exists during restart, the module will shut down again. - Page 11 FEATURE DESCRIPTIONS (CON.) The amount of power delivered by the module is the voltage at the output terminals multiplied by the output current. When using the trim feature, the output voltage of the module can be increased, which at the same output current would increase the power output of the module.
- Page 12 On/Off Simultaneous Simultaneous tracking (Figure 41) is implemented by using the TRACK pin. The objective is to minimize the voltage difference between the power supply outputs during power up and down. The simultaneous tracking can be accomplished by connecting Vo to the TRACK pin of PS2.
-
Page 13: Thermal Considerations
THERMAL CONSIDERATIONS Thermal management is an important part of the system design. To ensure proper, reliable operation, sufficient cooling of the power module is needed over the entire temperature range of the module. Convection cooling is usually the dominant mode of heat transfer. Hence, the choice of equipment to characterize the thermal performance of the power module is a wind tunnel. -
Page 14: Thermal Curves
THERMAL CURVES Figure 44: Temperature measurement location * The allowed maximum hot spot temperature is defined at 125 DNM04S0A0R10(Standard) Output Current vs. Ambient Temperature and Air Velocity Output Current(A) @ Vin = 5V, Vo = 3.3V (Either Orientation) Natural Convection Figure 45: DNM04S0A0R10 (Standard) Output current vs. -
Page 15: Mechanical Drawing
MECHANICAL DRAWING SMD PACKAGE (OPTIONAL) SIP PACKAGE DS_DNM04SIP10_07162008D... -
Page 16: Part Numbering System
PART NUMBERING SYSTEM Product Numbers of Input Voltage Series Outputs DNL - 16A 04 - 2.8~5.5V S - Single DNM - 10A 10 - 8.3~14V DNS - 6A MODEL LIST Model Name Packaging DNM04S0A0R10PFD DNM04S0A0R10NFD DNM04S0A0S10PFD DNM04S0A0S10NFD CONTACT: www.delta.com.tw/dcdc USA: Telephone: East Coast: (888) 335 8201 West Coast: (888) 335 8208...
