2200PTP-18
2200PTP-24
WIRELESS TRANSDUCER POWER TOOL
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,
OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT.
DO NOT ATTEMPT TO OPERATE THE TOOL UNTIL YOU HAVE READ AND
UNDERSTOOD ALL INSTRUCTIONS AND SAFETY RULES CONTAINED IN THIS
MANUAL. FAILURE TO COMPLY MAY RESULT IN ACCIDENTS INVOLVING
FIRE, ELECTRIC SHOCK, OR SERIOUS PERSONAL INJURY. SAVE THIS
OWNER'S MANUAL FOR FUTURE REFERENCE AND REVIEW IT FREQUENTLY
FOR SAFE OPERATION.
SRT857445 Rev. A
PRODUCT INFORMATION MANUAL
- 1 -
555 Kimberly Drive, Carol Stream, IL 60188
Phones: 847/455-8677 800/877-1347
E-mail: CustomerService@srtorque.com
Original Instructions
Fax: 847/455-0347
5/17/2024
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sturtevant Richmont 2200PTP-18
Summary of Contents for Sturtevant Richmont 2200PTP-18
- Page 1 555 Kimberly Drive, Carol Stream, IL 60188 Phones: 847/455-8677 800/877-1347 Fax: 847/455-0347 E-mail: CustomerService@srtorque.com 2200PTP-18 2200PTP-24 WIRELESS TRANSDUCER POWER TOOL PRODUCT INFORMATION MANUAL THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. DO NOT ATTEMPT TO OPERATE THE TOOL UNTIL YOU HAVE READ AND UNDERSTOOD ALL INSTRUCTIONS AND SAFETY RULES CONTAINED IN THIS MANUAL.
-
Page 2: Intended Use
INTENDED USE This tool is intended for trained adult use only. This screwdriver is designed to remove and install threaded fasteners. GENERAL SAFETY RULES Read all safety warnings, instructions, illustrations and specifications WARNING provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. -
Page 3: Warning Label Identification
WARNING LABEL IDENTIFICATION Read Manuals Before Operating Product. Wear Eye Protection. Wear Hearing Protection. Wear Dust Mask. Power tools can vibrate in use. Keep body stance balanced and firm. Do not overreach when operating this tool. Recycling Do not drop the battery and charger into trashcan. CE marking is a certification mark that indicates conformity with health, safety, and environmental protection standards for products sold within the European... -
Page 4: Work Area
WORK AREA WARNING a. Keep work area clean and well lit. Cluttered and dark areas invite accidents. b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes. Keep children and bystanders away while operating a power tool. - Page 5 Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second. TOOL USE AND CARE WARNING Use clamps or other practical way to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control.
-
Page 6: Specific Safety Rules And Symbols
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. -
Page 7: Functional Description
SYMBOLS The label on your tool may include the following symbols. The symbols and their definitions are as follows: SYMBOL NAME EXPLANATION Volts Voltage (potential) No Load Speed No-load Rotational Speed Kilograms Weight Direct Current Type of Current d.c. Revolutions per Revolutions, Surface Speed, Strokes, …/min Minute... -
Page 8: Specifications
SPECIFICATIONS Model Number Unit 2200PTP-18 2200PTP-24 Voltage 1/4” Hex. Drive/Anvil Tightening Torque 3-18 6-24 Programmable Speed 50-800 50-600 Tool Weight (with 4.0 Ah. battery) 1.66 Noise value LpA= 73.7 dB(A), KpA= 3 dB(A) Vibration value ah= 0.887 m/s2 , K= 1.5 m/s2 WARNING −... -
Page 9: Operation
OPERATION OVERVIEW The 2200PTP Series Wireless Power Tools are designed to work with the Global 400 and Global 400mp controller systems. These wireless tools are designed for industrial assembly use. The tool is completely dependent on the Global 400/400mp for directions and torque results reporting. - Page 10 MODES OF OPERATION Peak Mode In Peak mode, the tool uses a torque value to determine when to stop tightening. Fig. 2 When a Peak parameter (Fig. 2) is selected and the tool is enabled, the tool will display the target torque (Tgt Trq) value, units, batch count, and batch size on the display (see Fig.
- Page 11 Angle Mode In Angle mode, the tool uses an angle value to determine when to stop tightening. Fig. 4 When an Angle parameter (Fig. 4) is selected and the tool is enabled, the tool will display the target angle (Tgt Ang) value, degree symbol, batch count, and batch size on the display (see Fig.
- Page 12 INSTALLING OR REMOVING BATTERY PACK TO INSTALL BATTERY PACK: Push battery pack (A) onto tool (B) until it locks in place (see Fig. 6). TO REMOVE BATTERY PACK: Depress the two side release buttons (C) on battery pack and pull battery pack (A) off of tool (B) (see Fig. 6). Fig.
- Page 13 Fig. 8 INSTALLING THE BIT INTO THE HEX SHANK 1. Pull out the quick connect sleeve (see Fig. 9A). 2. Insert bit into the hex shank and release the sleeve to retain the bit (see Fig. 9B). NOTE: The quick connect sleeve is designed for 1/4" (6.35 mm) bits with a nominal shaft length of 3/8”...
- Page 14 STATUS LED INDICATION There are 2 LEDs atop the display screen. The status of LEDs shall be used as follows: Green – The last tightening cycle ended between its high & low limits with beep sound. Red – The last tightening cycle ended outside of its limits with beep sound. Red/Green blink –...
-
Page 15: Maintenance
MAINTENANCE Remove the battery pack from this tool before cleaning. WARNING This tool is lubricated before it leaves the factory. This lubrication should last for the life NOTE of the tool. No further lubrication is required. This tool is a precision tool. Disassembly, assembly, adjustment require DANGER exclusive jigs, testers, and trained techniques.
