Installation Instructions
2x2 MiMo Omni-Directional Antenna
W[X]MM-6-60 Range
SW3-1159 - v4
1. Introduction
The W[X]MM-6-60-[X] is a range of omni-directional panel antennas for 4G/5G applications requiring support for 2x2 MiMo across 4G LTE and 5G
NR frequencies.Versions of the product also include L1 GPS/GNSS.
Ideal for home office, branch or failover applications the antenna is suitable for external or internal mounting. The antenna is supplied as standard
with wall and mast mount brackets.
Electrical Safety Note
The WGMM-6-60 contains a single active L1 band GPS/GNSS antennas. Rated voltage: 3-5VDC Rated current (each antenna): 20mA maximum.
The supply to these devices must be provided with over current protection of 1A maximum.
2. Planning and Installation
Choose an installation type and location. The antenna can be wall mounted using the supplied wall mount bracket, self tapping screws and wall
plugs ( not included).
.
Alternatively the antenna can be mounted to masts of 18-50mm (0.71-1.96") diameter using the supplied mast mount clamp.
To minimize the effects of surrounding objects, the antenna should be located as far away from other objects and structures as possible. The
antenna is omni-directional, so it does not need to be facing a particular direction. The orientation of the antenna should be vertical with the cable
exiting downwards.
3. Safety Notes
• Please seek professional advice from an accredited installer regarding the installation if in any doubt.
• If the antenna will be fitted to an existing mast, please ensure that it will not overload it.
• Ensure that the installation location can be safely accessed with the equipment that you have available.
• If mounting in a possition which is accessible care should be taken to ensure that no one comes within 0.3m (1') of the antenna during use
CAUTION
Parts of the antenna are an electrical conductor. Contact with power lines can result in death, or serious injury. Do not install the
antenna where there is any possibility of contact with (or high voltage arc-over from) power cables. The antenna and supporting
mast must not be close to any power lines during installation, removal or in the event that part of the system should accidentally
fall.
.
Advertisement
Related Manuals for Panorama Antennas W MM-6-60 Series
Summary of Contents for Panorama Antennas W MM-6-60 Series
- Page 1 Installation Instructions 2x2 MiMo Omni-Directional Antenna W[X]MM-6-60 Range SW3-1159 - v4 1. Introduction The W[X]MM-6-60-[X] is a range of omni-directional panel antennas for 4G/5G applications requiring support for 2x2 MiMo across 4G LTE and 5G NR frequencies.Versions of the product also include L1 GPS/GNSS. Ideal for home office, branch or failover applications the antenna is suitable for external or internal mounting.
- Page 2 CAUTION If the antenna is installed above the roof line or in an exposed location, it is advisable to fit lightning surge arrestors in the coaxial cable feed line. Suitable units should be sourced and installed as per the manufacturer instructions. The installer is responsible for determining if this is a requirement for the antenna installation.
- Page 3 5. Pole/Mast Mounting In order to mount the antenna to a pole or mast you will need the following supplied parts: 1 x Antenna 1 x U-Bolt 1 x U-Bolt Plate 2 x Washers 2 x Spring Washers 2 x Nuts The u-bolt assembly allows fitting to masts of between 20-50mm (0.8”...
- Page 4 8. Notices DO NOT • operate the transmitter when someone is within 0.3m (1’) of the antenna. • operate the equipment in an explosive atmosphere. • attempt to install the antennas without the proper safe equipment to access the install location. •...
