- Page 1 Installation Instructions 4x4 MiMo 4G/5G MiMo Antenna DMM4-6-60 SW3-1050 - v1.1...
- Page 3 Content Installation Instructions Contact Information...
-
Page 4: Positioning The Antenna
1. Introduction The DMM4 antenna is a 4x4 MIMO (multiple input multiple output) / diversity capable accessory antenna designed to improve data rates for 2G / 3G/ 4G and 5G modem devices. 2. Positioning the Antenna The DMM4 is designed to operate with MIMO enabled modems which are able to take advantage of the scattered signal paths which exist in everyday indoor environments. -
Page 5: Routing The Cables
3. Routing the cables Route the dual coaxial cables from the antenna to the modem. The cables should not remain bunched or tightly wound as this may affect performance. Fold out desk stand feet Installing using adhesive pad Installing using suction cups Installing using screws... -
Page 6: Important Safety Notes
4. Important safety notes RF Safety Note - Ensure that the antenna is mounted in such a way that no person is likely to be within a distance of 30cms (12”) from the antenna during use. Ensure that the antenna is used only as supplied the co-axial cables should not be cut shorter or otherwise modified. -
Page 7: Contact Information
7 rue Suzanne Bernard, 33700 Mérignac 61 Frogmore, Wandsworth, London, SW18 1HF fr.sales@panorama-antennas.com sales@panorama-antennas.com +33 554 070 436 +44 (0)20 8877 4444 Panorama Antennas Pte Ltd Panorama Antennas Inc Singapore Space@ Tampines, 18 Tampines Industrial Crescent, 528605 1500 Heritage Parkway, Mansfield, TX, 76063 sales.sea@panorama-antennas.com sales.nam@panorama-antennas.com...
