Ultra Wideband MiMo Antenna
WMMG Range
SW3-665 - v2

Advertisement

loading
Need help?

Need help?

Do you have a question about the MiMo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Panorama Antennas MiMo

  • Page 1 Installation Instructions Ultra Wideband MiMo Antenna WMMG Range SW3-665 - v2...
  • Page 3 Content Installation Instructions Contact Information...
  • Page 4 1. Selecting a Position 1.1. Check that all the contents are in the box - This should include: 1 x Antenna 1 x Desk Stand 2 x Wall Bracket Plates 1 x U-Bolt 1 x U-Bolt Plate 4 x Screws 4 x Plain Washers 4 x Spring Washers 2 x Nuts...
  • Page 5: Mounting The Antenna

    1.3. Mounting the Antenna Mounting the antenna internally To mount the antenna internally use the supplied desk stand and follow the instructions at 5. DESK MOUNTING INSTRUCTIONS Mounting the antenna externally Mounting the antenna outside will provide optimum signal strength and data rates. Begin by following the instructions at 1.2 concerning position and orientating the antenna.
  • Page 6 3. Mast Mounting Instructions 1 - To Mast Mount this antenna you will need: 1 x Antenna 2 x Washers 1 x U-Bolt 2 x Spring Washers 1 x U-Bolt Plate 2 x Nuts 2 - Mast Mounting the antenna externally Ensure that the selected mounting location can be safely accessed with the equipment that you have available and mount the antenna so that it has at least 1 metre (3.3’) of clearance from all obstructions if possible.
  • Page 7: Wall Mounting Instructions

    4. Wall Mounting Instructions...
  • Page 8 1 - To Wall Mount this antenna you will need: 4 x Washers 1 x Antenna 4 x Spring Washers 2 x Wall Bracket Plates 2 x Nuts 4 x Screws 2 - Fix the mounting bracket to the external wall or other flat surface using suitable screws and wall plugs (not supplied).
  • Page 9 4 - Mounting the Antenna Hold the antenna cable securely upwards against the back of the antenna. Push the mounting foot of the antenna down into the groove in the base so that the mounting holes sit flush with the pegs in the base as shown.
  • Page 10: Contact Information
