Panorama Antennas WMM48G-17-42 Isntallation Instructions

A.
The WMM48G-17-42 is a 4x4 MiMo 4G/5G wall mount antenna designed to be low profi le and un-obtrusive. The antenna can be
mounted to conductive or non-conductive panels using the supplied fl ush wall mount bracket. A multi-tilt mast / wall bracket part no.
SAB-186 is available as an optional accessory. The antenna is supplied with integrated low loss fl ame retardant cable.
B.
The antenna should normally be mounted in a fl at, vertical orientation with the cable exit at the bottom. The antenna should be mount-
ed facing the desired coverage area.
The antenna should be spaced as far away from any nearby metal structures as possible. Special care should be taken to ensure that
the area directly in front of the antenna is free from metal objects and other obstructions. Ensure that there is adequate clearance and
that the coaxial cables can be routed to the equipment.
Ensure that the selected mounting location can safely be accessed using the equipment that is available.
A low profi le wall mount bracket is supplied allowing fl at fi tment to a wall with no adjustment. Alternatively, if the antenna is fi tted to a panel
with rear access, then it can be secured to the panel using suitable length M6x1 machine screws into the threaded bushes in the antenna
back plate. A multi-tilt bracket is available as an optional accessory for mounting to a mast (diameter <60mm [2.36"] ) or wall – this allows
adjustable vertical and horizontal tilt.
C.
• The antenna is designed to be mounted by a professional installer. Please seek professional advice from an accredited installer
regarding the installation if in any doubt.
• If the antenna will be fi tted to an existing mast, please ensure that it will not overload it.
• Ensure that the installation location can be safely accessed with the equipment that you have available.
• If mounting to a wall in a position which is accessible care should be taken to ensure that no one comes within 0.5m (1.5') of the
antenna during use.
CAUTION
Parts of the antenna are an electrical conductor. Contact with power lines can result in death, or serious
injury. Do not install the antenna where there is any possibility of contact with (or high voltage arc-over from)
power cables. The antenna and supporting mast must not be close to any power lines during installation,
removal or in the event that part of the system should accidentally fall.
CAUTION
If the antenna is installed above the roof line or in an exposed location, it is advisable to fi t lightning surge
arrestors in the coaxial cable feed line.
Suitable units should be sourced and installed as per the manufacturer instructions.
The installer is responsible for determining if this is a requirement for the antenna installation.
SW3-1034- Document Version 1
