Panorama Antennas WMM4-7-49 Installation Instructions

Installation Instructions
4x4 MiMo Omni-Directional Antenna
WMM4-7-49
SW3-978 - v1
1. Introduction
The WMM4-7-49-[X] is a range of omni-directional antennas for 4G/5G devices which require a 4x4 MiMo antenna system and covers the
cellular bands within the frequency range 698-4900MHz.
Ideal for home, office, branch or failover applications, the antenna is suitable for external or internal mounting and is supplied with mounting
hardware for wall or mast installation.
2. Planning and Installation
Choose a suitable location to determine the installation type.
The antenna can be wall mounted using the supplied wall mount bracket and suitable screws and wall plugs (not included).
Alternatively the antenna can be mounted to a mast of 20-50mm (0.71-1.96") diameter using the supplied mast mount clamp.
NOTE: This instruction does not cover installation of a mast, which must be selected and installed as a separate process to ensure that it can
support the weight and wind load of the antenna.
To provide the best omni-directional performance, the antenna should be located as far away from other objects and structures as possible,
and if wall mounted, the wall must not be of metallic construction. As the antenna is omni-directional, it does not need to be facing any
particular direction, but it should be installed in a vertical orientation with the cables exiting downwards.
3. Safety Notes
• Please seek professional advice from an accredited installer regarding the installation if in any doubt.
• If the antenna will be fi tted to an existing mast, please ensure that it will not overload it.
• Ensure that the installation location can be safely accessed with the equipment that you have available.
• If mounting in a position which is accessible care should be taken to ensure that no one comes within 0.3m (1') of the antenna during use
CAUTION
Parts of the antenna are an electrical conductor. Contact with power lines can result in death, or serious injury. Do not install the
antenna where there is any possibility of contact with (or high voltage arc-over from) power cables. The antenna and supporting
mast must not be close to any power lines during installation, removal or in the event that part of the system should accidentally
fall.
CAUTION
If the antenna is installed above the roof line or in an exposed location, it is advisable to fi t lightning surge arrestors in the
coaxial cable feed line.
Suitable units should be sourced and installed as per the manufacturer instructions.
The installer is responsible for determining if this is a requirement for the antenna installation.
.
