- Page 1 User manual PZ3740 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5 DMX Channels …………………………………………………………………………………6-16 Dimension …………………………………………………………………………………………17 Trouble Shooting…………………………………………………………………………………18 Fixture Cleaning………………………………………………………… ………………………18 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu Main Menu Second Third Fourth Dmx Address 000 - 512 Dmx Mode 21CH/22CH/35CH/36CH/111CH/148CH Pixel Mode Close/111CH/148CH Run Mode DMX / Host / Sound Pan Invert Close / Open Fixture Tilt Invert Close / Open No Dmx Signal Clear / Hold Fan Control Auto / Client / High Frequency... -
Page 6: Dmx Channels
4.DMX Channels 21CH Mode Channel Function DMX value Describe 0-255 0-100%Brightness adjustment, from dark to bright Red fine 0-255 Red fine Green 0-255 0-100%Brightness adjustment, from dark to bright Green fine 0-255 Green fine Blue 0-255 0-100%Brightness adjustment, from dark to bright Blue fine 0-255 Blue fine... - Page 7 22CH Mode Channel Function DMX value Describe 0-255 0-100%Brightness adjustment, from dark to bright Red fine 0-255 Red fine Green 0-255 0-100%Brightness adjustment, from dark to bright Green fine 0-255 Green fine Blue 0-255 0-100%Brightness adjustment, from dark to bright Blue fine 0-255 Blue fine...
- Page 8 35CH Mode Channel Function DMX value Describe 0-255 0-100%Brightness adjustment, from dark to bright Red fine 0-255 Red fine Green 0-255 0-100%Brightness adjustment, from dark to bright Green fine 0-255 Green fine Blue 0-255 0-100%Brightness adjustment, from dark to bright Blue fine 0-255 Blue fine...
- Page 9 Close 5-103 Regular flashing, speed changes from slow to fast Foreground 104-107 Open Strobe 108-207 Pulse strobe, speed changes from slow to fast 208-255 Open Close 5-103 Regular flashing, speed changes from slow to fast Background 104-107 Open Strobe 108-207 Pulse strobe, speed changes from slow to fast 208-255 Open...
- Page 10 Zoom Rotation 0-255 Rotation Control Shape Selection 0-255 Shape Selection Shape Fade 0-255 Smooth gradient control Shape Speed 0-255 Shape speed control Shape Red 0-255 0-100%Brightness adjustment, from dark to bright Shape Green 0-255 0-100%Brightness adjustment, from dark to bright Shape Blue 0-255 0-100%Brightness adjustment, from dark to bright...
- Page 11 111CH Mode Channel Function DMX value Describe Red 1 0-255 0-100% brightness adjustment, from dark to bright Green 1 0-255 0-100% brightness adjustment, from dark to bright Blue 1 0-255 0-100% brightness adjustment, from dark to bright Red 2 0-255 0-100% brightness adjustment, from dark to bright Green 2 0-255...
- Page 12 Green 15 0-255 0-100% brightness adjustment, from dark to bright Blue 15 0-255 0-100% brightness adjustment, from dark to bright Red 16 0-255 0-100% brightness adjustment, from dark to bright Green 16 0-255 0-100% brightness adjustment, from dark to bright Blue 16 0-255 0-100% brightness adjustment, from dark to bright...
- Page 13 Blue 30 0-255 0-100% brightness adjustment, from dark to bright Red 31 0-255 0-100% brightness adjustment, from dark to bright Green 31 0-255 0-100% brightness adjustment, from dark to bright Blue 31 0-255 0-100% brightness adjustment, from dark to bright Red 32 0-255 0-100% brightness adjustment, from dark to bright...
- Page 14 White 5 0-255 0-100% brightness adjustment, from dark to bright Red 6 0-255 0-100% brightness adjustment, from dark to bright Green 6 0-255 0-100% brightness adjustment, from dark to bright Blue 6 0-255 0-100% brightness adjustment, from dark to bright White 6 0-255 0-100% brightness adjustment, from dark to bright...
- Page 15 Green 17 0-255 0-100% brightness adjustment, from dark to bright Blue 17 0-255 0-100% brightness adjustment, from dark to bright White 17 0-255 0-100% brightness adjustment, from dark to bright Red 18 0-255 0-100% brightness adjustment, from dark to bright Green 18 0-255 0-100% brightness adjustment, from dark to bright...
- Page 16 White 28 0-255 0-100% brightness adjustment, from dark to bright Red 29 0-255 0-100% brightness adjustment, from dark to bright Green 29 0-255 0-100% brightness adjustment, from dark to bright Blue 29 0-255 0-100% brightness adjustment, from dark to bright White 29 0-255 0-100% brightness adjustment, from dark to bright...
-
Page 17: Dimension
5. Dimension... -
Page 18: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
