- Page 1 User manual PF350 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 Technical Specifications………………………………………………………………………4 Control Panel ……………………………………………………………………………………4-5 DMX Channels ……………………………………………………………………………………5 Trouble Shooting…………………………………………………………………………………6 Fixture Cleaning………………………………………………………… ………………………6 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Lamp: LED 350W import LED Color Temperature: 3200K / 4500K / 6500K / 8500K Power Consumption: 600 W Power Voltage: AC 220V-240V, 50/60Hz Average life: 50000H, control lamp on/off Color：5 colors + white(ROYGBW) Zoom：adjust the room big or small, manual adjustment the definition Strobe：1-11hz/S Projection distance：5-50meters/5-120meters Cooling system: use 6piece 8 mm thick copper tube heat conduction through 66 pieces of large... -
Page 5: Control Panel
Control Panel: 1) Power switch; 2) Power connector; 3) OLED display; 4) Fader block to control the CRT wheel, iris, dimmer, stroboscope; 5) Color selection buttons; 6) Button on / off the light source; 7) XLR connectors, for controlling the spotlight via DMX. 4.DMX Channels Control mode: When a DMX signal is input, the DMX control mode takes precedence;... -
Page 6: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
