- Page 1 User manual MH-1240P Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-7 DMX Channel ……………………………………………………………………………………8-16 Dimension…………………………………………………………………………………………16 Trouble Shooting…………………………………………………………………………………17 Fixture Cleaning………………………………………………………… ………………………17 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Voltage: AC100-240V 50/60HZ Power: 500W Light source:wash:12*40W RGBW 4in1 Strip:144x0.5W cool White+warm white 2in1 Led Control mode: DMX512, self-propelled, master-slave, voice-activated, with RDM function. Channels: CH23, CH35, CH57. CH71, CH117 Zoom angle: 4.5-50° Dimming: 32bit 0-100% linear dimming Features:Tilt 202°movement+ beam + burst flash + auxiliary light Working Temperature: -30℃-50℃. -
Page 5: Control Menu
Control Menu 1.Display panel and button function: Menu key: Enter/return to the main menu Up key: menu function up selection/parameter increment Down key: menu function selection down/parameter decrease Confirm key: Select the menu function and make a confirmation and save when modifying the menu function parameters. - Page 6 and save, default to 000. 4. Focusing Modify the parameter values up or down (adjustable range 000-255), confirm and save, default to 000. Modify the parameter values up or down (adjustable range 000-255), 5. Dimming confirm and save, default to 000. Modify the parameter values up or down (adjustable range 000-255), 6.
- Page 7 1、Tilt Modify the parameter up or down (range 000-255), confirm calibration key to save, default 128. 2. Focus 1 Modify Focus 1 calibration (000-255) up or down, confirm key calibration to save, default 128. 3. Focus 2 Modify the Focus 2 calibration (000-255) up or down, confirm Calibration key to save, default 128.
-
Page 8: Dmx Channel
4.DMX Channels CH23 Channel Channel Value Functions 000-255 Tilt 000-255 Tilt fine-tuning 000-255 Tilt velocity 000-255 focus 000-255 Dimmer 000-255 main light strobe 000-255 Main light R 000-255 Main light G 000-255 Main light B 000-255 Main light W 000-255 Master Light Mode 000-255 Main light speed... - Page 9 CH35 Channel Channel Value Functions 000-255 Tilt 000-255 Tilt fine-tuning 000-255 Tilt velocity 000-255 Focus 000-255 Dimmer 000-255 Main light strobe 000-255 Main light R color selection 000-255 Main light G color selection 000-255 Main light B color selection 000-255 Main light W color selection 000-255 Master Light Mode...
- Page 10 CH57 Channel Channel Value Functions 000-255 Tilt 000-255 Tilt fine-tuning 000-255 Tilt velocity 000-255 Focus 000-255 Dimmer 000-255 Main light strobe 000-255 Main light R color selection 000-255 Main light G color selection 000-255 Main light B color selection 000-255 Main light W color selection 000-255 Master Light Mode...
- Page 11 000-255 Auxiliary light LED5 000-255 Auxiliary light LED6 000-255 Auxiliary light LED7 000-255 Auxiliary light LED8 000-255 Auxiliary light LED9 000-255 Auxiliary light LED10 000-255 Auxiliary light LED11 000-255 Auxiliary light LED12 000-255 Auxiliary light LED13 000-255 Auxiliary light LED14 000-255 Auxiliary light LED15 000-255...
- Page 12 000-255 Auxiliary light white 2 000-255 auxiliary light mode 000-255 Auxiliary light speed 000-255 Secondary light direction Reset: parameter value in 150-255 whole machine reset, 000-255 the console parameter value must be pulled to below 10 first, and then pushed to 250-255 to be useful, the parameter value in 000-149 is useless, it can not be reset.
- Page 13 000-255 Main light red 10 000-255 Main light green 10 000-255 Main light blue 10 000-255 Main light white 10 000-255 Main light red 11 000-255 Main light green 11 000-255 Main Light Blue 11 000-255 Main light white 11 000-255 Main light red 12 000-255...
- Page 14 000-255 Main light W1 000-255 Main light R2 000-255 Main light G2 000-255 Main light B2 000-255 Main light W2 000-255 Main light R3 000-255 Main light G3 000-255 Main light B3 000-255 Main light W3 000-255 Main light R4 000-255 Main light G4 000-255...
- Page 15 000-255 Main light W12 000-255 Golden Light 1 000-255 White light 1 000-255 Golden Light 2 000-255 White light 2 000-255 Golden Light 3 000-255 White Light 3 000-255 Golden Light 4 000-255 White light 4 000-255 Golden Light 5 000-255 White Light 5 000-255...
-
Page 16: Dimension
000-255 White light 22 000-255 Golden Light 23 000-255 White Light 23 000-255 Golden Light 24 000-255 White Light 24 5.Dimension... -
Page 17: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
