Uplus Lighting MIX460 User Manual

Hide thumbs

Advertisement

Table of Contents

User manual
MIX460
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIX460 and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting MIX460

Summary of Contents for Uplus Lighting MIX460

  • Page 1 User manual MIX460 Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………4 DMX Channels …………………………………………………………………………………5-12 Trouble Shooting…………………………………………………………………………………12 Fixture Cleaning………………………………………………………… ………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...

  • Page 4: Technical Specifications

    Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

  • Page 5: Dmx Channels

    RESET All Reset No/Yes 4.DMX Channels 26CH 26CH Function DMX Value Description 0-255 0-100% Pan Axis fine 0-255 0-100% Tile 0-255 0-100% TileAxis fine 0-255 0-100% Zoom 0-255 0-100% Pan-axis infinite 0-255 0-100% Tile-axis infinite 0-255 0-100% Total dimming 0-255 0-100% 0-19 none...
  • Page 6 Scene speed 0-255 Scene speed from slow to fast 0-19 none Supplement light 20-255 Strobe from slow to fast 0-10 none 11-25 24-40 green 41-55 blue 56-70 white 71-85 red+green 86-100 red+blue Supplement macro color 101-115 green+blue 116-130 red+white 131-145 green+white 146-160 blue+white...
  • Page 7 251-255 Scene 1-24 Supplement scene speed 0-255 Scene speed from slow to fast Supplement white scene 0-255 Scenes Supplement white speed 0-255 Scene speed from slow to fast 0-250 none Reset 251-255 reset 32CH 32CH Function DMX Value Description 0-255 0-100% Pan Axis fine 0-255...
  • Page 8 0-10 none Background color 11-255 background color Background color total dimming 0-255 0-100% 0-10 none 11-20 scene 1 Scenes 241-250 scene 24 251-255 scene 1-24 Scene speed 0-255 Scene speed from slow to fast Supplement total dimming 0-255 0-100% 0-19 none Supplement Strobe 20-255...
  • Page 9 251-255 scene1-24 Supplement Scenes Speed 0-255 Scene speed from slow to fast Supplement white led 0-255 0-100 Supplement white scenes 0-255 Scenes Supplement white speed 0-255 Scene speed from slow to fast 0-250 none Reset 251-255 Reset 108CH 108CH Function DMX Value Description 0-255...
  • Page 10 Blue 0-255 0-100% White 0-255 0-100% 0-10 none Background color 11-255 background color Background color total dimming 0-255 0-100% 0-10 none 11-20 Scenes1 Scenes 241-250 Scenes24 251-255 Scenes1-24 Scene speed 0-255 Scene speed from slow to fast Supplement 0-255 0-100% total dimming 0-19 none...
  • Page 11 0-10 none 11-20 Scenes1 Supplement Scenes 241-250 Scenes24 251-255 Scenes1-24 Supplement Scenes Speed 0-255 Scene speed from slow to fast Supplement white led 0-255 0-100 Supplement white scenes 0-255 Scenes Supplement white speed 0-255 Scene speed from slow to fast 0-250 none Reset...

  • Page 12: Trouble Shooting

    Supplement White24 0-255 0-100% 6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
