VISTA Insert LE2
INSTALLATION AND OPERATING INSTRUCTIONS
- AUSTRALIA
SERIAL #
SAFETY NOTICE
If this stove is not properly installed, a house fire may result. For your safety, follow the
installation instructions. Contact local building or fire officials about restrictions and
installation inspection requirements in your area.
MODEL: VISTA INSERT LE2
280325-24
VISTA INSERT LE2 (M)
100007585
Advertisement
Table of Contents
Related Manuals for Pacific energy VISTA INSERT LE2
Summary of Contents for Pacific energy VISTA INSERT LE2
- Page 1 If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions. Contact local building or fire officials about restrictions and installation inspection requirements in your area. MODEL: VISTA INSERT LE2 280325-24 VISTA INSERT LE2 (M)
-
Page 2: Table Of Contents
Please read this entire manual before you install and use your new room heater. Failure to follow instructions may result in property damage, bodily injury, or even death. VISTA INSERT LE2(M) 280325-24 100007585... -
Page 3: General Safety
This will also create heavy deposit build-up in the chimney. 4. DOOR GASKET - The gasket used by Pacific Energy (22mm medium density fiberglass WARNING: rope) requires only light pressure to seal. -
Page 4: Maintenance Checks
- Replace if the baffle has permanent warping greater than this or has cracking or breakage. - Please contact your Dealer if you experience any of the damage listed above. Continuing to operate your stove with broken parts may accelerate damage to other parts and may void your warranty VISTA INSERT LE2(M) 280325-24 100007585... -
Page 5: Creosote
4. After the chimney fire is out, the chimney must be cleaned and checked for stress and cracking before starting another fire. Also check combustibles around chimney and the roof. This should be done by a certified inspector/chimney sweep. VISTA INSERT LE2(M) 280325-24 100007585... -
Page 6: Operation
5) Begin normal operation after a good coal base exists and wood has charred. WARNING: Do not use grates or andirons Your Pacific Energy heater is designed for maximum overall efficiency at a moderate firing rate. Over-firing is hazardous and a waste of fuel. Too slow a burn contributes to elevate the fuel. -
Page 7: Normal Operation
3) Inadequate draft may cause back-puffing into the room and plugging of the chimney. Smoke leaking into the room through appliance and chimney connector joints indicates inadequate draft. VISTA INSERT LE2(M) 280325-24 100007585... - Page 8 OPENING AND HEARTH DIMENSIONS MINIMUM FLOOR PROTEC- 625mm TION UNDER THE APPLIANCE MUST BE 738MM DEEP X 533mm 545MM WIDE X 110MM THICK (CLAY BRICKS) 432mm 625mm 200mm 200mm Non-combustible fireplace Figure 2: Fireplace Dimensions. hearth VISTA INSERT LE2(M) 280325-24 100007585...
-
Page 9: Minimum Clearances To Combustibles
Ember Protection in front of the unit must be 9mm thick Bellis Board with a thermal conductivity of 0.1m K/W. Minimum Floor Protection under the appliance must be 738mm deep x 625mm wide x 110mm thick (Clay Bricks). VISTA INSERT LE2(M) 280325-24 100007585... -
Page 10: Masonry Fireplace Installation
Code. The Insert must be installed in accordance with local, and or AS/NZS 2918:2001 VISTA INSERT LE2(M) 280325-24 100007585... -
Page 11: Full Flue Liner
3) Attach a stove connector to the bottom of the liner. Attach the Vista Insert LE2 removable flue collar to the chimney connector. Note: To get access to the connector/and removable flue collar through the... -
Page 12: Chimney And Connector
300 cm of flue top Any nearby structure more than 300 cm 300 cm or less 60 cm min 300 cm increase from 100 cm min.until clear within 300 cm of flue top Figure 5: Chimney clearances. VISTA INSERT LE2(M) 280325-24 100007585... -
Page 13: Firebrick Installation
Firebrick Installation ITEM Dimensions 225mm x 119mm x 32mm 225mm x 54mm x 32mm 108mm x 54mm x 32mm 113mm x 76mm x 32mm 178mm x 45mm x 32mm VISTA INSERT LE2(M) 280325-24 100007585... - Page 14 4. Next, place an "E" firebrick up under the side brick retainer tab and stand another "A" brick beside the first one under the "E" firebrick. Figure 9. Figure 9: Second side wall firebricks in place. Figure 8: 1st side wall bricks in place. VISTA INSERT LE2(M) 280325-24 100007585...
- Page 15 Place four "A" firebricks on the firebox floor as shown in Figure 11. 8. Place the remaining "B" firebrick so that it sits in front and at the center, add a "C" brick on each side. Figure 12. Figure 12: Narrow front bricks in place. VISTA INSERT LE2(M) 280325-24 100007585...
-
Page 16: Combustion Air
6. Carefully slide the assembled surround over the unit and Ash Shelf, engage the tabs on the inside, back of the surround into the slots in surround brackets located on the side of the firebox. 7. Push the entire appliance back until the surround assembly is in contact with the fireplace face. Figure 13: Surround assembly. VISTA INSERT LE2(M) 280325-24 100007585... -
Page 17: Blower Operation
ER 93 and the regulatory authority as appropriate. Figure 14: Wiring diagram. For your protection against Thermal shock hazard, use only a properly Switch grounded outlet that will accept a grounded plug Hi/Low Black Rocker switch Brown White Blue VISTA INSERT LE2(M) 280325-24 100007585... -
Page 18: Cleaning/Maintenance
Primary Air Control. Installation is the reverse. Be careful not to bend the Primary Air Control when inserting in through the Blower Box. Remove Screw. One on each side Figure 15: Blower mounting screws. VISTA INSERT LE2(M) 280325-24 100007585... -
Page 19: Baffle Removal
4. Insert the baffle board above the baffle tubes inside the firebox and under the retaining tabs on the baffle air channels. Caution - Baffle Board material is very fragile. Slide the baffle board back until the lower edge is tight against the baffle. VISTA INSERT LE2(M) 280325-24 100007585... -
Page 20: Baffle Removal
(see Combustion Air section) 2) Draft too low - Chimney plugged or restricted Inspect and clean - Chimney oversized or otherwise unsuitable Consult Dealer 3) Negatively pressurized home. - Resolve issue in household. VISTA INSERT LE2(M) 280325-24 100007585... -
Page 21: Parts List
39 ..Baffle Tube Retaining Clip, LE2(not shown) .................80002889 40 ..Blower Bracket Spacer (2pc) (not shown) ................80002599 All parts may be ordered from your nearest Pacific Energy dealer. Contact Pivot Stove & Heating for the location of the dealer nearest you. - Page 22 VISTA INSERT LE2(M) 280325-24 100007585...
-
Page 23: Rating Label
Distributed by: PIVOT STOVES AND HEATING CO, 120 Victoria Street, Nth Geelong – Vic 3215, pivotstove.com.au DATE OF MANUFACTURE SERIAL # 270325 100007589 The certification label is located on the left side casing of the insert. CERTIFICATION LABEL VISTA INSERT LE2(M) 280325-24 100007585... - Page 24 © 2025 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. PIVOT STOVE & HEATING pivotstove.com.au CONTACT: 1 300 4 74 868 Printed in Canada...
