IMPORTANT:
KEEP THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
INSTALLATION AND OPERATING INSTRUCTIONS
If this stove is not properly installed, a house fire may result. For your safety,
follow the installation instructions. Contact local building or fire officials
about restrictions and installation inspection requirements in your area.
MODEL:
130125-28
VISTA LE2
- AUSTRALIA
SAFETY NOTICE
VISTA LE2
VISTA LE2
SERIAL #
100007584

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISTA LE2 and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific energy VISTA LE2

Summary of Contents for Pacific energy VISTA LE2

  • Page 1 IMPORTANT: KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. VISTA LE2 INSTALLATION AND OPERATING INSTRUCTIONS - AUSTRALIA SERIAL # SAFETY NOTICE If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions. Contact local building or fire officials about restrictions and installation inspection requirements in your area.

  • Page 2: Table Of Contents

    Baffle Removal ......................21 or fire officials about Troubleshooting .......................22 r e s t r i c t i o n s a n d Parts Diagram - VISTA LE2 ..................23 installation inspection Compliance Plate......................25 requirements in your area. Please read this entire manual before you install and use your new room heater.

  • Page 3: Safety And Maintenance

    WARNING: Only use materials supplied by 4. DOOR GASKETS - The gasket used by Pacific Energy (22 mm medium density manufacturer when doing maintenance fibreglass rope) requires only light pressure to seal. This will prolong seal life. It is or replacements.

  • Page 4: Maintenance Checks

    Maintenance Checks Check the following parts for damage such as cracks, excessive corrosion, burned out sections and excessive warping**: (See website for descriptions and more detail) Weekly: - Firebrick - Visual, for cracking. - Door Gasket - sagging, placement, damage. Monthly - Brick rail tabs and brick rails.

  • Page 5: Formation And Need For Removal

    Creosote Formation and Need for Removal When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote. The creosote vapours condense in the relatively cool chimney flue of a slow burning fire. As a result, creosote residue accumulates on the flue lining.

  • Page 6: Crate Removal

    Appliance Dimensions 588mm 654mm 187mm 746mm 692mm VISTA LE2 - Pedestal 441mm 654mm 187mm 692mm 746mm VISTA LE2- Leg Figure 1. Vista, Classic metric dims. Assembly Crate Removal 1. Carefully remove wood top and supports. Remove plastic cover. 2. Using a 7/16" wrench, remove lag bolts that secure the stove body to pallet •...

  • Page 7: Optional Ash Cleanout Installation

    Optional Ash Cleanout installation Remove Locate the two nuts under the firebox holding the ash system (hole) cover and gasket. Remove the nuts, leaving the bolts in place. Discard the cover plate and gasket. Remove any tabs as needed where the Ash Cleanout rod Ash Cleanout nuts will be on the left side.

  • Page 8: Flue Gas Agitator Removal/Installation

    Flue Gas Agitator Removal/Installation DO NOT OPERATE WITH AGITATOR REMOVED. The Flue Gas Agitator comes pre-installed inside the unit and should not need to be handled in any way. In the case the Agitator needs to Be replaced, follow the instructions below. Removal 1.

  • Page 9: Installing The Flue Thermocouple Guard

    Installing the Flue Thermocouple Guard 1. Remove the thermocouple guard from inside the flue collar of the unit. Figure 7 2. Remove the piece of cardboard holding the flue gas agitator in place. Figure 8 3. Re-install the thermocouple guard. Ensure all three ends are in place correctly. Figure 9 Figure 7.

  • Page 10: Smoke Detectors Be Optional Battery Box Installation

    Connecting the A/C Adapter Remove the A/C Adapter from inside the unit and connect the bar- rel plug to A/C Adapter plug in the Control Board then connect the adapter to a wall outlet. Figure 10 NOTE: If you unplug the unit for any reason, unplug the adapter from the wall outlet and wait a minimum of 30 seconds before plugging the unit back in.

  • Page 11: Minimum Clearance To Combustibles

    This protection must extend as follows: [723mm] 300mm on the firing side and 200mm both sides of the door opening . See Figure #5. [300mm] [200mm] [200mm] Non-combustible Floor Protector [781mm] Figure 14. Floor Protector Vista LE2 VISTA / CLASSIC AS 100007584 130125-28...

  • Page 12: Are Operating More Frequently. This Chimney And Connector

    Chimney and Connector WARNING: INSTALL CHIMNEY AND ALL COMPONENTS OF CHIMNEY SYSTEM ACCORDING TO CHIMNEY MANUFACTURER’S INSTRUCTIONS. Connect to a listed chimney complying with the requirements of AS/NZS2918/2001 and a chimney suitable for use with solid fuel that is lined and in good condition and meets local building codes. The chimney flue size should be the same as the stove outlet for optimal performance.

  • Page 13: Fumes Caused By Accidentally Leaving Firebrick Installation

    Firebrick Installation ITEM Dimensions 225mm x 119mm x 32mm 225mm x 54mm x 32mm 108mm x 54mm x 32mm 113mm x 76mm x 32mm 178mm x 45mm x 32mm Figure 16. Vista LE2 Firebrick. VISTA / CLASSIC AS 100007584 130125-28...
  • Page 14 Begin firebrick installation with the rear wall. 1. Stand one "A" firebrick vertically behind the tab located on the brick rail. Slide the firebrick toward the center of the rear wall Figure 17. 2. Slide a 2nd "A" firebrick underneath the tab on the brick rail Figure 18. Figure 17.
  • Page 15 Figure 21. Second side wall bricks in place. Figure 22. Front side wall firebricks in position. 5. Next, place an "E" firebrick up under the side brick retainer tab and stand another "A" brick beside the first one under the "E" firebrick Figure 21. 6.
  • Page 16 Figure 24. First two floor bricks in place. Figure 25. Third floor brick in place. Figure 26. Fourth floor brick in place. Figure 27. Short, norrow brick installed in front row. 10. Place a short narrow "F" brick against the front right side of the floor (Figure 27) followed by a longer "B" brick in the center of the front row (Figure 28).

  • Page 17: Combustion Air

    Combustion Air Intake or combustion air can be supplied to the stove in one of two ways. Consult your local building code or Installation Code for Solid-Fuel-Burning Appliances and Equipment before proceeding. Outside air supply - (Necessary for air tight homes.) Outside air may be drawn from either underneath the stove or from behind.

  • Page 18: Wood Selection

    WARNING: OPEN AIR CONTROL (AND DAMPER WHEN FITTED) BEFORE OPENING FIRING DOOR. Your PACIFIC ENERGY heater is designed for maximum overall efficiency at a moderate firing rate. Overfiring is hazardous and a waste of fuel. Too slow a burn contributes to creosote buildup and lowers combustion efficiency.

  • Page 19: How To Test Your Wood

    How to Test Your Wood Add a large piece of wood to the stove when it has a good large bed of coals. It is dry if it is burning on more than one side within one minute. It is damp if it turns black and lights within three minutes. If it sizzles, hisses and blackens without igniting in five minutes it is soaked and should not be burnt.

  • Page 20: Restarting After Extended Or Overnight Burns

    Restarting After Extended or Overnight Burns 1. Open door and rake hot embers towards the front of the heater. Add a couple of dry, DO NOT OVERFIRE THIS HEATER: split logs on top of embers, close door. Attempts to achieve heat output rates that exceed heater design specifications 2.

  • Page 21: Baffle Removal

    4. Inspect the gasket between baffle and supply tube. If necessary, replace with gasket (part#80000365) available from your Pacific Energy dealer. 5. Re-install baffle assembly in reverse order. The two side pieces of blanket insulation must be tight against the side rails.

  • Page 22: Troubleshooting

    ppendix Troubleshooting Problem Cause Cure Glass is Dirty 1. Wood is wet • Use dry wood 2. Turning down air control • Do not turn down until or damper too soon a) there is a good bed of coals b) the wood is charred 3.

  • Page 23: Parts Diagram - Vista Le2

    39 ..Wall Adapter 12V...........................80002965 40 ..Baffle Tube Retaining Clip, LE2(not shown) ................80002889 41 ..Flue Gas Agitator ...........................80002880 All parts may be ordered from your nearest Pacific Energy dealer. Contact Pacific Energy for the location of the dealer nearest you. VISTA / CLASSIC AS...
  • Page 24 Figure 31. Replacement parts. VISTA / CLASSIC AS 100007584 130125-28...

  • Page 25: Compliance Plate

    Compliance Plate ACMS KIT INSTALLED VISTA LE2(ACMS), ALDERLEA T4 LE2(ACMS) VISTA LE2(M), ALDERLEA T4 LE2(M) FREESTANDING FREESTANDING Tested by: AUSTRALIAN SOLID FUEL TESTING Tested by: AUSTRALIAN SOLID FUEL TESTING 3 GARDEN ST., MORWELL, VICTORIA 3 GARDEN ST., MORWELL, VICTORIA ASFT24113...
  • Page 26 VISTA / CLASSIC AS 100007584 130125-28...
  • Page 27 VISTA / CLASSIC AS 100007584 130125-28...
  • Page 28 © 2025 Copyright Pacific Energy Fireplace Products LTD. Reproduction, adaptation, or translation without prior written permission is prohibited except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.pacificenergy.net 2975 Allenby Rd., Duncan, BC V9L 6V8...
