Pneumatic Arm Dual Ultrawide
Monitor Wall Mount
SKU: MOUNT-V120K
Instruction Manual
Assembly Video & Product Info
www.vivo-us.com/products/mount-v120k

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOUNT-V120K and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo MOUNT-V120K

Summary of Contents for Vivo MOUNT-V120K

  • Page 1 Pneumatic Arm Dual Ultrawide Monitor Wall Mount SKU: MOUNT-V120K Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-v120k...
  • Page 2 [THIS PAGE IS INTENTIONALLY LEFT BLANK]...
  • Page 3 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.

  • Page 4: Package Contents

    Package Contents A (x1) B (x1) C (x2) Pole Wall Mount Lower Arm E (x2) F (x1) D (x2) VESA Bracket Large Cap Upper Arm G (x1) H (x1) I (x1) Small Cap Cable Clip Wall Bracket J (x1) Strap...

  • Page 5: Included Hardware & Tools

    Included Hardware & Tools M-B (x8) M-A (x8) S-B (x2) S-A (x2) M5x12mm Screw M4x12mm Screw M8x25mm Screw Plastic Spacer M-C (x8) W-A (x5) W-B (x5) W-C (x5) M5 Washer ST6.3x55mm Screw Concrete Anchor M6 Washer T-A (x1) T-B (x1) 4mm Allen Wrench 6mm Allen Wrench Tools Needed:...

  • Page 6: Assembly Steps

    ASSEMBLY STEPS STEP 1 Option 1: Wood Stud Installation Wood Stud Predrilling Drill Bit: 3/16” (4.5mm) Hole Depth: 2.2” (55mm) Hold Wall Mount (B) up to the desired mounting position on a stud and mark drilling locations with a Pencil. Use of a stud finder and level is recommended.
  • Page 7 Option 2: Concrete/Brick Installation Concrete/Brick Predrilling Drill Bit: 3/8” (10mm) Hole Depth: 2.4” (60mm) Hold Wall Mount (B) up to the desired mounting position and mark drilling locations with a Pencil. Use of a level is recommended. Press Concrete Anchors (W-B) into the drilled holes. Secure Wall Mount (B) to the wall using ST6.3x55mm Screws (W-A), M6 Washers (W-C) and a 10mm Socket wrench.
  • Page 8 STEP 2 Press Large Cap (F) into the top hole and Small Cap (G) into the bottom hole of the Wall Mount (B).
  • Page 9 STEP 3 Insert Pole (A) fully into the Wall Mount (B). Line up the Wall Bracket (I) just under the top of the Pole (A) as shown and mark dilling locations using a Pencil. Remove the Pole.
  • Page 10 STEP 4 Using predrilling information by chosen application provided below, drill two holes into marked locations. Wood Stud Predrilling Concrete/Brick Predrilling Drill Bit: 3/8” (10mm) Drill Bit: 3/16” (4.5mm) Hole Depth: Hole Depth: 2.4” (60mm) 2.2” (55mm) STEP 5 Option 1: Wood Stud Installation Secure Wall Bracket (I) to the wall using ST6.3x55mm Screws (W-A), M6 Washers (W-C) and a 10mm Socket wrench.
  • Page 11 Option 2: Concrete/Brick Installation Press Concrete Anchors (W-B) into the drilled holes. Secure Wall Bracket (I) to the wall using ST6.3x55mm Screws (W-A), M6 Washers (W-C) and a 10mm Socket wrench.
  • Page 12 STEP 6 Loosen the Set Screws on both Pole Collars using 4mm Allen Wrench (T-A) and slide them off the Pole (A). Pole Collar Screw Insert Pole (A) into the Wall Mount (B) and secure by tightening the Set Screw using 4mm Allen Wrench (T-A).
  • Page 13 STEP 7 Slide Cable Clip (H) down the Pole (A). Slide one of the Pole Collars onto the Pole at the desired height and secure by tightening the Set Screws using 4mm Allen Wrench (T-A). Pole Collar Screw Slide one of the Lower Arms (C) down the Pole (A) so that it rests on the Pole Collar. Secure by tightening the Set Screw on the Lower Arm using 4mm Allen Wrench (T-A).
  • Page 14 STEP 8 Slide the remaining Pole Collar and Lower Arm (C) down the Pole (A) at the desired height and secure by tightening all of the Set Screws with 4mm Allen Wrench (T-A). Pole Collar Screw...
  • Page 15 STEP 9 Fasten the Strap (J) around the Wall Bracket (I) and Pole (A). Clip Make sure the Strap’s Clip is against the Bracket for a secure fit.
  • Page 16 STEP 10 Insert the Upper Arm (D) into the Lower Arm (C) and secure by tightening the Set Screw using 4mm Allen Wrench (T-A). Repeat this step for the other arm. Screw Secure VESA Brackets (E) to the Upper Arms (D) using M8x25mm Screws (S-B), Plastic Spacers (S-A), and 6mm Allen Wrench (T-B).
  • Page 17 STEP 11 Remove Thumbscrews (E1) from VESA Brackets (E) and remove VESA Plates (E2). Set Thumbscrews aside. Attach VESA Plates (E2) to your monitors using appropriate Screws (M-A,M-B), Washers (M-C), and a Phillips screwdriver. Ensure arrow on VESA Plates are facing the top of the monitors.
  • Page 18 Adjusting the Tilt Joint Tilt Joint Adjustment Screw Loosen Tilt Joint: Set Angle Use 6mm Allen Wrench (T-B) to Firmly grip the VESA Bracket and loosen the Tilt Joint Adjustment adjust to your desired viewing Screw, located on the side of VESA angle, and hold in place.
  • Page 19 STEP 12 Line up the VESA Plates (E2) on your monitors with the VESA Brackets (E) and tilt the monitors down into the VESA Brackets as shown. 2 Person Mounting is Recommended Secure using previously removed Thumbscrews (E1).
  • Page 20 Fine Tune Tilt Angle If the monitor is angled further than intended... Heavy Weighted/ Ultrawide Monitors [ 22 - 33.5 lbs ] Firmly Hold Monitor Firmly grasp and hold the monitor in place. Do NOT release monitor until you have completed steps below. Loosen Tilt Joint: With a hand still on the monitor, use 6mm Allen Wrench (T-B) to loosen the tilt joint...
  • Page 21 Adjusting Monitor Height Position Mount Arm Turn 10-20x to Set Monitor Height Position the arm horizontally, as shown above, and firmly hold in Turn 6mm Allen Wrench (T-B) 10-20 times place. to obtain proper support for your monitor. Use the guide below to adjust the tension according to the amount of counterbalance Insert 6mm Allen Wrench (T-B)
  • Page 22 STEP 13 Route cables through the built-in cable covers. Remove the covers by Slide them back on when sliding them foward. finished routing cables.
  • Page 23 Monitor Tilt Adjustments Use the 6mm Allen Wrench (T-B) to adjust the tilt of your monitor as desired.

  • Page 24: Last Updated

    LAST UPDATED: 10/08/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
