- Page 1 CENTRIFUGAL DUCT FAN IN SOUND INSULATED CASING ISO-RB USER’S MANUAL...
-
Page 2: Table Of Contents
ISO-RB www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Unit design and operating principle ..........................6 Installation and connection ..............................6 Connection to power mains ..............................8 Control ......................................... - Page 3 ISO-RB www.blaubergventilatoren.de • Do not change the power cable length at your own discretion. Do not bend the power • Do not lay the power cable of the unit in cable. Avoid damaging the power cable. Do close proximity to heating equipment. not put any foreign objects on the power cable.
-
Page 4: Purpose
ISO-RB www.blaubergventilatoren.de PURPOSE THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT THE APPROPRIATE TRAINING. THE UNIT MUST BE INSTALLED AND CONNECTED ONLY BY PROPERLY QUALIFIED PERSONNEL AFTER THE APPROPRIATE BRIEFING. THE CHOICE OF UNIT INSTALLATION LOCATION MUST PREVENT UNAUTHORIZED ACCESS BY UNATTENDED CHILDREN. -
Page 5: Technical Data
2 holes 100 mm Overall and connecting dimensions of the fan [mm] Н А А1 А2 В В1 Weight [kg] ISO-RB 100 ISO-RB 125 ISO-RB 125 max 568,5 ISO-RB 150 ISO-RB 160 ISO-RB 200 3575 22.6 ISO-RB 250 ISO-RB 315 max... -
Page 6: Unit Design And Operating Principle
ISO-RB www.blaubergventilatoren.de UNIT DESIGN AND OPERATING PRINCIPLE The fan casing is made of aluzinc. For easy installation and operation, the top cover of the fan is secured with a special lock. The casing is heat- and sound-insulated with a 50 mm layer of non-fl ammable mineral wool. To ensure better noise absorption, the inner surface of the insulation is made of a perforated metal sheet. - Page 7 ISO-RB www.blaubergventilatoren.de Fan and remote terminal box installation sequence • Before installation, lay the wires and cables necessary to connect the fan to the mains. • Minimal distance from the fan casing to the wall is 300 mm. • Fasteners for fan mounting are not included in the delivery set and should be ordered separately. •...
-
Page 8: Connection To Power Mains
The fan is connected to power mains by means of the power cord with a plug (XP) or in the remote terminal box (X1). ISO-RB 100, ISO-RB 125, ISO-RB 125 max, ISO-RB 150, ISO-RB 160, ISO-RB 200, ISO-RB 250, ISO-RB 355... -
Page 9: Technical Maintenance
ISO-RB www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! The technical maintenance includes periodic cleaning of the surfaces from accumulated dust and dirt. The impeller blades require thorough cleaning once in 6 months. Clean the blades with a soft brush or a vacuum cleaner. While cleaning the fan be careful not to displace the impeller counter weights. -
Page 10: Manufacturer's Warranty
ISO-RB www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/ EU and CE-marking Directive 93/68/EEC. -
Page 11: Certifi Cate Of Acceptance
ISO-RB www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Centrifugal duct fan in sound insulated casing Model ISO-RB ______________________ Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 12 www.blaubergventilatoren.de B143-1EN-01...
