HUMIDIFIED HOLDING & TRANSPORT CART
OWNERS / OPERATORS MANUAL
SAFETY PRECAUTIONS..............................................
FEATURES & SPECIFICATIONS...................................
UNPACKING, INSPECTION & FREIGHT DAMAGE...........
INSTALLATION & STARTUP ........................................
CONTROL PANEL LAYOUT.........................................
NORMAL OPERATION................................................
FOOD HOLDING GUIDE..............................................
REGULAR CLEANING PROCEDURES...........................
CABINET MAINTENANCE & REPLACEMENT PARTS......
WIRING DIAGRAM......................................................
TROUBLESHOOTING GUIDE ......................................
WARRANTY STATEMENT...........................................
Part Number: 18400-3211
MODEL: HTU12
TABLE OF CONTENTS
Printed in The United States of America
MANUFACTURED BY:
Mundelein, IL 60060 U.S.A.
Fax: 847-367-8981
Toll Free: 800-323-9793
Email: technicalservice@carter-hoffmann.com
2
3
4
5
6
7
8
9
10
11
12
13
Rev: KBA020416
Advertisement
Table of Contents
Related Manuals for CARTER-HOFFMANN HTU12
Summary of Contents for CARTER-HOFFMANN HTU12
-
Page 1: Table Of Contents
HUMIDIFIED HOLDING & TRANSPORT CART MODEL: HTU12 OWNERS / OPERATORS MANUAL MANUFACTURED BY: CARTER-HOFFMANN 1551 McCormick Avenue Mundelein, IL 60060 U.S.A. Phone: 847-362-5500 Fax: 847-367-8981 Toll Free: 800-323-9793 Email: technicalservice@carter-hoffmann.com TABLE OF CONTENTS SAFETY PRECAUTIONS……………………………..……….. FEATURES & SPECIFICATIONS………..……………..……. UNPACKING, INSPECTION & FREIGHT DAMAGE……….. -
Page 2: Safety Precautions
SAFETY PRECAUTIONS WARNING: ELECTRIC SHOCK HAZARD WARNING WARNING All service requiring access to non-insulated components must be performed by qualified service personnel. Failure to heed this warning may result in severe electric shock. CAUTION: ELECTRIC SHOCK HAZARD Disconnect this appliance from electrical power before performing any maintenance or service. -
Page 3: Features And Specifications
Height Number Capacity* Height Depth Width Diameter Shipping Weight in (mm) 12”x20” 18” x 26” in (mm) in (mm) lbs (kg) HTU12 74-3/4 36-3/8 29-7/8 (1524) (1899) (924) (759) (127) (127) 1685 W 1700 W 120 V 120V 14 Amp 14.2 Amp... -
Page 4: Unpacking And Inspection
(15) days from the date the delivery was made to you. Be sure to retain the container for inspection. Carter-Hoffmann cannot assume liability for damage or loss incurred in transit, freight damage is not covered under warranty. We will, however, at your request, supply you with the necessary documents to support your claim. -
Page 5: Installation & Startup
INSTALLATION and STARTUP LOCATION WARNING: For proper operation and maximum performance, locate the unit Risk of personal injury in an ambient air temperature of 70ºF (21ºC). Installation procedures must be Avoid placement in areas near exhaust fans or where there are performed by a qualified technician active air movements. -
Page 7: Normal Operation
NORMAL OPERATION The HTU12 Series Humidified Holding Cabinet is equipped with two CAUTION: dials to control the temperature and humidity settings. Before using, HOT SURFACE familiarize yourself with the cabinet controls. See detail on page six of this manual. Inner surfaces of the unit... -
Page 8: Food Holding Guide
FOOD HOLDING GUIDE PRODUCT SET TEMPERA- RELATIVE HUMIDITY MAXIMUM (Uncovered Food, except where TURE TIME noted) (°F /°C) (MINUTES) CAUTION: SAFE Bacon, Canadian 180°F / 82°C FOOD HOLDING Bacon, Crisp 180°F / 82°C NONE REQUIRED PRACTICES Baked Potato 180°F / 82°C RECOMMENDED Cooking food to a safe Biscuits... -
Page 9: Daily Cleaning Procedures
DAILY CLEANING PROCEDURES CAUTION: 1. After all food products have been removed from the cabinet, ELECTRIC SHOCK turn the power switch to “OFF” and allow the cabinet to cool. HAZARD 2. Unplug the unit prior to any cleaning. Disconnect appliance from electric power before cleaning. -
Page 10: Cabinet Maintenance
CABINET MAINTENANCE CASTERS WARNING: DO NOT perform Caster bearings are equipped with Zerk grease fittings so that they these procedures may be easily lubricated with a grease gun. Lubricate bearings at while the cabinet is turned on least once every six months. or heated. -
Page 11: Wiring Diagram
WIRING DIAGRAM... -
Page 12: Troubleshooting Guide
NOTE: NOTE: The technical content of this manual, For warranty service, call Carter-Hoffmann including any wiring diagrams, schemat- direct at 800-323-9793 for authorization, ics, parts breakdown illustrations and / or we will dispatch the nearest authorized adjustment procedures, is intended for service agency. -
Page 13: Warranty
Repair or replacements under this warranty will be performed, unless otherwise authorized in writing by CARTER-HOFFMANN, at its factory. All parts or components to be repaired or replaced under this warranty are to be shipped prepaid to CARTER-HOFFMANN, with reimbursement credit for such part or component to be given if found by CARTER-HOFFMANN to be defective.
