MODELS: EVOL208, EVOR208, EVOL240, EVOR240
EVOLTSM208, EVOLTLG208, EVOLTSM240, EVOLTLG240
OWNERS / OPERATORS MANUAL
EVOR208
FEATURES & SPECIFICATIONS
UNPACKING, INSPECTION & FREIGHT DAMAGE
Installation & STARTUP
Wiring Diagram & REPLACEMENT PARTS LIST
WARRANTY STATEMENT
Part Number: 18400-3178
FOOD HOLDING STATIONS
TABLE OF CONTENTS
Printed in The United States of America
MANUFACTURED BY:
CARTER-HOFFMANN
1551 McCormick Avenue
Mundelein, IL 60060 U.S.A.
Phone: 847-362-5500
Fax: 847-367-8981
Toll Free: 800-421-3744
Email: TechnicalService@Carter-Hoffmann.com
EVOLTLG208
EVOLTSM208
PAGE
2
3
4
5
6
6
7
8
9
10
11-12
13
Rev4: KBA092413
Advertisement
Table of Contents
Related Manuals for CARTER-HOFFMANN EVOR208
Summary of Contents for CARTER-HOFFMANN EVOR208
- Page 1 FOOD HOLDING STATIONS MODELS: EVOL208, EVOR208, EVOL240, EVOR240 EVOLTSM208, EVOLTLG208, EVOLTSM240, EVOLTLG240 OWNERS / OPERATORS MANUAL MANUFACTURED BY: CARTER-HOFFMANN 1551 McCormick Avenue Mundelein, IL 60060 U.S.A. Phone: 847-362-5500 Fax: 847-367-8981 Toll Free: 800-421-3744 Email: TechnicalService@Carter-Hoffmann.com EVOLTLG208 EVOLTSM208 EVOR208 TABLE OF CONTENTS...
- Page 2 SAFETY PRECAUTIONS WARNING: ELECTRIC SHOCK HAZARD WARNING All service requiring access to non-insulated components must be performed by qualified service personnel. Failure to heed this warning may result in severe electric shock. CAUTION: ELECTRIC SHOCK HAZARD Disconnect this appliance from electrical power before performing any maintenance or service.
- Page 3 240V, 2400W, 10.5A, 50/60Hz, 1Ph Features & Benefits EVOL208, EVOR208, EVOL240, EVOR240. EVOR models have the small heating cabinet on the right side. EVOL models have the small heating cabinet on the left side. EVOLT models have separate small and large side cabinets.
- Page 4 This should be done within fifteen (15) days from the date the delivery was made to you. Be sure to retain the container for inspection. Carter-Hoffmann cannot assume liability for damage or loss incurred in transit, freight damage is not covered under warranty. We will, however, at your request, supply you with the necessary...
- Page 5 INSTALLATION and START-UP LOCATION WARNING: Read equipment manual completely before installing and op- Risk of personal injury erating the cabinet. Installation procedures must be Unit must be installed by qualified service personnel on- performed by a qualified technician ly. Unit must be installed in such a fashion to bear the weight with full knowledge of all applicable of the cabinet when fully loaded;...
- Page 6 CONTROL PANEL LAYOUT Controllers On/Off Toggle Switches EVOR208 OPERATION AUX Key Up Arrow Key (inoperable) Press to increase temperature set point (1° increments) Digital Display Set Key Readout Down Arrow Key Press and release Press to decrease temperature set point to display temper- (1°...
- Page 7 CONTROLLER PROGRAMMING INSTRUCTIONS AUX Key Up Arrow Key (inoperable) Press to increase temperature set point (1° increments) Set Key Down Arrow Key Press and release Press to decrease temperature set point to display temper- (1° increments) ature set point Each controller has been factory pre-set for an air temperature set point and a low temperature alarm set point. In most cases, these set points will not need to be changed.
- Page 8 DAILY CLEANING PROCEDURES CAUTION: 1. After all food products have been removed from the cabinet, ELECTRIC SHOCK turn the power switches to “OFF” and allow the cabinet to HAZARD cool. If cabinet is supplied with a plug, disconnect from pow- Disconnect appliance from er prior to cleaning.
- Page 9 TIPS FOR CLEANING STAINLESS STEEL RECOMMENDED TIPS FOR CLEANING STAINLESS STEEL Purpose Frequency Cleaning Agent Method of Application Routine Daily Soap, ammonia Sponge with cloth, rinse with clear water cleaning detergent and water and wipe dry. Smears/ Stainless steel cleaner Rub with soft cloth as directed on package.
- Page 10 WIRING DIAGRAM 18616-0035 REPLACEMENT PARTS LIST PART NUMBER DESCRIPTION PART NUMBER DESCRIPTION 18600-0042 Hi Limit 120°F Snap Disc 18600-0117 Fan Safety Hi Limit 160°F w/Reset Snap Disc 18600-0046 Hi Limit 350°F Auto 18616-0366 Dixell 208V/16A 208°F Set-point Controller 18602-0031 Switch Boot 18616-0367 Dixell 208V/16A 158°F Set-point Controller 18602-0083...
- Page 11 TROUBLESHOOTING GUIDE EVO Heater: 208VAC and 240VAC. Reference connections on wiring diagram (previous page) WARNING: All operations must be performed to requirements of NFPA-70E (Standard for Electrical Safety in the Workplace) by a qualified electrician. CALL FOR SERVICE. Symptom Possible Cause Remedy No power;...
- Page 12 Low temperature alarm External alarm For technical assistance with troubleshooting, call Carter-Hoffmann at (800)421-3744 or (847)362-5500. NOTE: Prior to calling for service locate the serial tag on the cabinet. You will need the serial number of the cabinet for proper identification.
- Page 13 Repair or replacements under this warranty will be performed, unless otherwise authorized in writing by CARTER-HOFFMANN, at its factory. All parts or components to be repaired or replaced under this warranty are to be shipped prepaid to CARTER-HOFFMANN, with reimbursement credit for such part or component to be given if found by CARTER-HOFFMANN to be defective.
