- Page 1 7 Port USB 3.2 Gen 2 Type-C Hub w/ESD Surge Protection Model Number: CG-7P4C3A Installation Guide Coolgear, Inc. Version: 1.0 Date: 05/06/2024...
- Page 2 First Release 1. Introduction Thank you for purchasing Coolgear’s 7 Port USB 3.2 Gen 2 Type-C Hub. Thank you for purchasing this Super-speed 7-port USB3.2 Gen 2 Type-C Metal hub. It provides an ideal solution to expand 7 USB3.2 Gen 2 ports (4 USB-C and 3 USB-A connectors) from one single USB3.2 host port.
-
Page 3: Connector Layout
7 Port USB 3.2 Gen 2 Type-C Hub – Installation Guide 2. Connector Layout Need help? Visit: coolgear.com/support... - Page 4 +7V to 24V DC. Warning!! Please make sure the polarity of the input power should be correctly matched with the terminal block pins Need help? Visit: coolgear.com/support...
-
Page 5: Hardware Installation
Double click Generic USB Hub, the message will show that this device is working properly. 4. Environmental Specifications Operating temp.: 0 to 70°C (32 to 158°F) Operating humidity: 5 to 95% RH Dimensions (LxWxH): 178.00 x 60.30 x 26.30 mm (7.00 x 2.37 x 1.03 in) Need help? Visit: coolgear.com/support... - Page 6 Technical Support When you reach out to Coolgear support, you’ll find yourself in the hands of a solution-oriented and knowledgeable expert ready to answer whatever question you throw at them. If you ever need help with your product, visit coolgear.com/support for support tickets, downloads, and other support resources.
- Page 7 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
