- Page 1 SMITH MACHINE ATTACHMENT ASSEMBLY MANUAL A BYOB-SMTH-HDRMTC-SET BAR-SMTH-HDRMTC-SET Scan QR code for assembly video --> www.bellsofsteel.com | www.bellsofsteel.us | 1-888-718-7997...
- Page 3 THE KAEVON GUARANTEE We are so confident that you’ll love your new Bells of Steel gear that we’re willing to put our money where our mouth is and provide a refund if you don’t love our Bells of Steel brand products within 30 days from the day that you receive your products.
- Page 4 PARTS LIST: BAR INCLUDED SMITH ATTACHMENT BAR-SMTH-HDRMTC-SET • • Hardware Package Hardware Package Description PLACE M24 x 130 bolt M16 x 120 bolt M10 x 16 bolt M24 nut M16 nut 24 washer BOX 2_4 16 washer 10 washer 24 spring washer 16 spring washer 10 spring washer 16-22-8 spacer...
- Page 5 PARTS LIST: BAR INCLUDED SMITH ATTACHMENT BAR‐SMTH‐HDRMTC‐SET • Packed in the Box 34 x 1 pc 35 x 1 pc 36 x 2 pcs 37 x 2 pcs 39 x 1 pc 38 x 1 pc x 26 pcs x 1 pc 42 x 2 pcs...
- Page 6 PARTS LIST: BYOB SMITH ATTACHMENT BYOB-SMTH-HDRMTC-SET • Hardware package Description M24 x 130 bolt M16 x 120 bolt M10 x 16 bolt M24 nut M16 nut 24 washer 16 washer 10 washer 24 spring washer 16 spring washer 10 spring washer...
- Page 7 PARTS LIST: BYOB SMITH ATTACHMENT BYOB-SMTH-HDRMTC-SET • Packed in the Box 34 x 1 pc 35 x 1 pc 38 x 1 pc 39 x 1 pc 41 x 26 pcs 43 x 1 pc 44 x 1 pc 45 x 2 pcs...
- Page 8 TOOLS REQUIRED: Hydra - 2x24mm wrenches, 5mm allen key (BYOB), 6mm + 8mm allen key (3 Piece) 17mm wrench, tape measure/ruler WE ARE HERE TO HELP Try following along on with our assembly video or call us at 1-888-718-7997...
-
Page 9: Section A: Common Components
SECTION A: COMMON COMPONENTS ASSEMBLY FOR BOTH BYOB AND BAR INCLUDED SMITH MACHINES Step 1: Begin by laying out parts #34 and #35 (left and right side rail subassemblies) on the floor facing the same direction with some room to work in between. Step 2: Install #41 (silver rungs) and bolts #3 onto #34/#35, Leave the top 2 and bottom holes empty for the time being as they may interfere with the... - Page 10 Step 3: Install the silver guide rods into the uprights. Step 4: Install top (#32) and bottom (#33) brackets into the correct position on the rack, this may take some trial and error to get them lined up depending on specific rack configurations.
- Page 11 Step 5: Connect the top hole to the corresponding slot on the bracket with a #2 bolt, installing one spacer #12 on each side between the bracket and part #33/34. Make sure that the rungs are facing the inside of the rack ( Part #33 on the left side Part #34 on the right side if outside the rack, if inside the rack #33 right side #34 left side) Don’t over-tighten the bolt as the #33/34 still need to be able to swivel and slide in the channel on bracket.
-
Page 12: Section B: Byob Version Only
SECTION B: BYOB VERSION ONLY SKIP TO SECTION C FOR BAR INCLUDED SMITH Step 7A: a) Slide each rod up through the top of #33/#34 (left and right side upright subassemblies), one at a time, until they are high enough to slide parts onto the rail from underneath. - Page 13 Step 7C: RIGHT: #44, (right side BYOB bottom subassembly), 1 x #31 (safety spring), and #39 (right side safety hook) for #35. Add plastic stopper #29 at the bottom *the plastic stopper used in this video is from a prototype version and production models will come with a thinner stopper.* The two little black spacers on #43/44 should be facing the inside of the rack and safeties will latch onto rungs if installed properly.
- Page 14 Step 9: Set the set screws at the back of the #45’s to the designated length on the chart in the instruction manual. The measurement for the length is from the top of the set screw to the point of insertion as outlined in the diagram next to the chart and is determined by the shaft diameter of your barbell.
- Page 15 Step 11: Take part #45 and while lifting the bar up, slightly tuck the side with the two screws you adjusted earlier underneath, repeat for the other side. Step 12: Reinsert bolts #22 into #45 and tighten back down until it is clamped snuggly around the bar.
- Page 16 Step 13: Repeat for the other side. Step 14: Remove Part 48 (bar hook closure) from #46 (left side bar hook) and #47 (right side bar hook) and adjust the set screw to the designated length outlined in the chart in the instruction manual based on the width of your barbell.
- Page 17 Step 15: Hang parts 46 and 47 (the threaded part of the screw on the side should be facing in towards the clamp assembly) on the appropriate rungs so that they can swing out and cradle the bar. Then reinstall part #48 back on each side by tightening the bolt #22 you removed in step 14.
-
Page 18: Section C: Bar Included Smith Only
SECTION C: BAR INCLUDED SMITH ONLY Step 7: Install sleeves (#37) onto parts #36 (bar trolleys) then install #42 (sleeve end caps) and tighten them down using the 8mm allen key. Then slide on #30 (rubber spacers) to the end of the sleeve. Step 8: Starting on one side, slide the rod up through the top of #34 (left side upright subassembly) or #35 (right side rail subassembly) high enough to slide parts... - Page 19 Step 9: Install spacer #15 on the open end of installed part #36 (bar trolley) and then slide the bar #40 (bar shaft) on. Next slide spacer #15 onto the other #36 (bar trolley) that hasn’t been installed yet and then slide #36 (bar trolley) onto the open end of the bar.
- Page 20 Step 11: With the bar in latched position tighten bolts # 14 using a 6mm allen key, through the holes near the latches on #40 (bar shaft) and into the slots on the parts #36 (bar trolley). Step 12: Next, lift up the guide rods to install #31 (springs), #38 (left side safety) on #34 (left side upright subassembly) &...
- Page 21 Step 13: Install Bolt #2 that secures the guide rods on the bottom of parts #34/#35. *** For vertical installs only: depending on the configuration you may need to undo the connecting bolt so the sides of the machine can be tilted back and the bolts that secure the guide rods can be tightened now.
- Page 22 90” Hydra Bracket and Upright Hole Alignment: STILL LOST? Call us at: 1-888-718-7997 we will walk you through it...
