- Page 1 Drawing : - TPC578 Issue : - 1 Date : - 14/06/22 CD200 CD200 DEHUMIDIFIER CD200 CD200 DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL www.eipl.co.uk Page 1 of 12...
-
Page 2: Safety Information
Drawing : - TPC578 Issue : - 1 Date : - 14/06/22 SAFETY INFORMATION Children shall not play with the appliance. This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved. - Page 3 Before disposing all refrigerant should be evacuated and disposed of as required by local environmental laws. • If there is any damage to the appliance, DO NOT USE and contact EIPL. • The appliance must not be used in a potentially explosive atmosphere.
- Page 4 Drawing : - TPC578 Issue : - 1 Date : - 14/06/22 DEHUMIDIFIER PRINCIPLE Dehumidifiers remove moisture from the air that is circulating through the appliance. The resulting reduction of relative humidity helps prevent rust, rot, mould, mildew and condensation within the room, or other enclosed spaces where the dehumidifier is used.
-
Page 5: Installation
This unit should be connected to a single fused spur with a 20A rating. Selecting the correct fan speed – The CD200 has a low fan speed and a high fan speed and the required speed must be chosen before installation. To select the correct fan speed firstly remove the filter cover via the 9off screws, then remove the electrical box cover via the 4off M4 hex head bolts. - Page 6 Drawing : - TPC578 Issue : - 1 Date : - 14/06/22 DRAINAGE: The appliance is fitted with a condensate pump which collects all the condensate. As the condensate pump fills with water it will automatically activate and empty via the tube outlet located at the back of the dehumidifier, this should be connected to a water container or permanent drain.
-
Page 7: Operation
Drawing : - TPC578 Issue : - 1 Date : - 14/06/22 OPERATION Once the appliance is installed turn the power supply on, then the on / off switch to the ‚I‘ position, note the display will flash for approximately 1 second then show the humidity set point for approximately 12 seconds. - Page 8 If the fault clears and the float returns to its normal position, the pump will stop and the LED extinguishes If, after carrying out the above procedures, the appliance does not appear to function properly, refer to the Trouble Shooting section, which follows, or contact EIPL. Page 8 of 12...
-
Page 9: Routine Service
1. Insufficient air flow 1. Check all of the above Little or no water 2. Compressor fault 2. Contact EIPL extraction 3. Loss of refrigerant gas 3. Contact EIPL Little or no defrost 1. Faulty Timer 1. -
Page 10: Specifications
Drawing : - TPC578 Issue : - 1 Date : - 14/06/22 SPECIFICATIONS : 11182GR-GB ODEL : 832 mm (32.76 in) EIGHT : 745 mm (29.3 in) IDTH : 445 mm (17.52 in) EPTH : 80 Kg (176.4 lb) EIGHT Low - 850 M /Hr (500 CFM) IRFLOW... - Page 11 Drawing : - TPC578 Issue : - 1 Date : - 14/06/22 APPLIANCE SPARE PARTS LIST Description Part Number Product Part Number 11182GR-GB PCB Timer 1619522 Controls Display PCB 1619524 Humidity Sensor PCB 1619526 PCB Connecting Cable 2013753 Filter 2018233 Keypad Label 2018241 Condenser Coil...
- Page 12 Bishop Auckland Suite 109, Newport News County Durham Virginia, 23606-2575 DL14 9AD Tel: +44 (0) 1388 664400 Tel: +01 757 873 6800 Fax: +44 (0) 1388 662590 Fax: +01 757 873 3632 www.eipl.co.uk www.ebacusa.com sales@eipl.co.uk sales@ebacusa.com Page 12 of 12...
