Download
Share
Print this page
  1. Manuals
  2. Brands
  3. EIPL Manuals
  4. Dehumidifier
  5. CD425
  6. Owner's manual

EIPL CD425 Owner's Manual

Hide thumbs Also See for CD425:

Advertisement

Quick Links

Download this manual
Get In Touch
Call: 01729 824108
Email: info@puravent.co.uk
CD425
CD425
CD425
CD425
DEHUMIDIFIER
DEHUMIDIFIER
DEHUMIDIFIER
DEHUMIDIFIER
OWNER'S MANUAL
OWNER'S MANUAL
OWNER'S MANUAL
OWNER'S MANUAL
www.eipl.co.uk
www.eipl.co.uk
Page 1 of 16
Our Address
Puravent, Adremit Limited, 6 County Business Park,
Darlington Road, Northallerton, DL6 2NQ
Drawing : - TPC127A
Issue
: - 5
Date
: - 23/11/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the CD425 and is the answer not in the manual?

Questions and answers

Related Manuals for EIPL CD425

Summary of Contents for EIPL CD425

  • Page 1 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 CD425 CD425 CD425 CD425 DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER DEHUMIDIFIER OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL www.eipl.co.uk www.eipl.co.uk Page 1 of 16 Get In Touch Our Address Call: 01729 824108...
  • Page 2 The CD425 is a self contained low temperature dehumidifier. All electrical contactors, overloads, etc, are housed in an electrical box built inside the unit.

  • Page 3: Specifications

    Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 SPECIFICATIONS Model: CD425 Height: 1190mm Width: 1100mm Depth: 460mm Weight: 160 Kg Airflow: 3000 M Power Supply: 380-415V, 3 ph, 50Hz Power 6.0 Kw (max) Finish: Vinyl coated steel Refrigerant Type/Qty: R407c (2.5Kg)

  • Page 4: Installation

    : - 23/11/16 INSTALLATION POSITIONING: The CD425 is designed for indoor use only. Position the dehumidifier unit in the centre of the room to be conditioned if at all possible. Using a spirit level ensure the unit is level in both directions.
  • Page 5 Connect the outlet from the drain tray (located behind the front grille and under the evaporator coils) to a permanent drain. Please ensure that the drainage does not rise above the level of the CD425’s drain tray. Failure to observe this requirement will result in internal flooding of the dehumidifier unit.

  • Page 6: Operation

    Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 OPERATION The operation of the dehumidifier is to remove moisture from the air by having it condense on the cold tubes of the evaporator coil. The air then passes over the hot condenser coil and returns to the conditioned space slightly warmer and dryer than when it entered the dehumidifier unit.

  • Page 7: Routine Service

    Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 ROUTINE SERVICE WARNING: ENSURE THAT THE POWER CORD TO THE MACHINE HAS BEEN DISCONNECTED BEFORE CARRYING OUT ROUTINE SERVICE. THE SERVICING AND REPAIR OF THIS UNIT SHOULD ONLY BE CARRIED OUT BY A SUITABLY QUALIFIED PERSON.
  • Page 8 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 To check the operation of the defrost system, switch the machine on and leave it running for approximately 55 minutes in temperatures below 20° C. The machine will then enter defrost mode for approximately 5 minutes, before returning to normal operation.
  • Page 9 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 REPAIRS Should an electrical component fail, consult the Factory Service Center to obtain the correct replacement part. If refrigerant gas is lost from the machine, it will be necessary to use a refrigeration technician to correct the fault.

  • Page 10: Troubleshooting

    Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 TROUBLESHOOTING YMPTOM AUSE EMEDY 1. Tighten fan 1. Loose fan on shaft 2. Replace the fan motor 3. See Routine Maintenance 2. Fan motor burnt out Little or no airflow 3.
  • Page 11 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 CD425 SPARE PARTS LIST ESCRIPTION UMBER UMBER UANTITY Compressor 3944919 Axial Fan 3040119 12V LED Bulb 3932327 Condenser Coil 3020725 Evaporator Coil 3020733 Reversible Filter Dryer 3020930 Fan Motor Assembly...
  • Page 12 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 CD425 WIRING SCHEMATIC Page 12 of 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk...
  • Page 13 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 WARNINGS This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved.
  • Page 14 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 Page 14 of 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk...
  • Page 15 Drawing : - TPC127A Issue : - 5 Date : - 23/11/16 Page 15 of 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk...
  • Page 16 Germany Tel: +44 (0) 1388 664400 Tel: +01 757 873 6800 Tel: +49 3043 557241 Fax: +44 (0) 1388 662590 Fax: +01 757 873 3632 Fax: +49 3043 557240 www.eipl.co.uk www.ebacusa.com www.eip-ltd.de sales@eipl.co.uk sales@ebacusa.com sales@eip-ltd.de Page 16 of 16 Get In Touch...
