EVM User's Guide: TPS26744EQ1EVM
TPS26744E-Q1 USB PD EPR + DisplayPort EVM
Description
The TPS26744EQ1EVM is designed to evaluate
the TPS26744E-Q1 for USB Type-C
Delivery (PD) applications. This EVM supports dual
port USB PD EPR charging and DisplayPort
over USB-C
®
(DP Alt Mode) and comes with two
other variants: dual port USB PD SPR charging
(TPS26742Q1EVM) and dual port USB PD EPR
charging (TPS26742EQ1EVM). The EVM integrates
an onboard microcontroller (MCU), enabling flash
programming and debugging.
Device configuration settings are selected through an
intuitive Application Customization Tool in the form
of a graphical user interface (TPS267XX-Q1-GUI),
reducing much of the complexity associated with
competitive USB-PD designs.
Features
USB–IF certification, TID: (TBD)
SLVUD34 – APRIL 2025
Submit Document Feedback
®
and Power
Applications
TPS26744EQ1EVM
Copyright © 2025 Texas Instruments Incorporated
Charging up to 140W on Port A and Port B with
the
LM251772-Q1
(TBD)
TPD4S481-Q1 USB Type-C 48V EPR Port
Protector
TUSB564-Q1
USB Type-C DP Alt Mode for sink
side
TUSB5461-Q1
USB Type-C DP Alt Mode for
source side
Easy-to-use GUI with preconfigured firmware to
configure device
VBUS and CCx test points for both Type-C ports to
monitor PD traffic
MCU for flash programming and system telemetry
Automotive USB charging
Automotive media hub
Automotive head unit
Automotive rear seat entertainment
TPS26744E-Q1 USB PD EPR + DisplayPort EVM
Description
1
