www.ti.com
User's Guide
TPS25990 Evaluation Module for eFuse
This user's guide describes the evaluation module (EVM) for the TPS25990 eFuse. The TPS25990 device
is a 2.9-V to 16-V and 50-A stackable eFuse with a PMBus
configuration, and debugging. This device provides an accurate and fast load current monitor output, which
helps in Intel PSYS
™
and PROCHOT
TPS25985
eFuses for higher current designs by actively synchronizing the device states and sharing the loads
during start-up and steady-state.
The TPS25990 eFuse has an integrated FET with ultra-low ON resistance of 0.8-mΩ, adjustable and robust
overcurrent and short-circuits protections, fast overvoltage protection (fixed 16.7-V threshold in hardware
and adjustable through PMBus), adjustable output slew rate control for inrush current protection, and
overtemperature protection to verify FET safe operating area (SOA). The TPS25990 eFuse also has an
adjustable overcurrent transient blanking timer to support load transients, adjustable undervoltage protection,
integrated FET health monitoring, and reporting, analog die temperature monitor output, dedicated fault and
power good indication pins, and uncommitted general purpose fast comparator.
1
Introduction.............................................................................................................................................................................4
1.1 EVM Features....................................................................................................................................................................
1.2 EVM Applications...............................................................................................................................................................
2 Description..............................................................................................................................................................................
3
Schematic................................................................................................................................................................................6
Configurations..........................................................................................................................................................8
4.1 Physical Access.................................................................................................................................................................
4.2 Test Equipment and Setup...............................................................................................................................................
Procedures..................................................................................................................................................12
5.1 Hot Plug...........................................................................................................................................................................
Enable.........................................................................................................................................................14
5.3 Current Limit Based Start-up Behavior............................................................................................................................
5.4 Power Up into Short.........................................................................................................................................................
5.5 Overvoltage Lockout........................................................................................................................................................
5.6 Transient Overload Performance.....................................................................................................................................
5.7 Overcurrent Event............................................................................................................................................................
5.9 Output Hot Short..............................................................................................................................................................
5.10 Quick Output Discharge (QOD).....................................................................................................................................
5.11 Thermal Performance of TPS25990EVM.......................................................................................................................
6 Using the TPS25990EVM-GUI..............................................................................................................................................
6.1 Access the TPS25990EVM-GUI......................................................................................................................................
6.2 Introduction to the TPS25990EVM-GUI...........................................................................................................................
6.4 Quick Info.........................................................................................................................................................................
6.5
Configuration....................................................................................................................................................................27
SLVUCH7A - SEPTEMBER 2022 - REVISED JUNE 2023
Submit Document Feedback
ABSTRACT
®
interface for accurate digital telemetry, control,
™
implementations. This eFuse supports parallel connection with multiple
Caution Hot Surface.
Caution
Contact may cause burns.
Do not touch !

Table of Contents

GUI................................................................................................25
Copyright © 2023 Texas Instruments Incorporated
Table of Contents
Circuit.....................................20
TPS25990 Evaluation Module for eFuse
4
5
5
8
10
13
15
16
17
17
19
21
22
23
24
24
24
26
1
