SLVUAV3A – August 2016 – Revised February 2017 TPS26600-02EVM: Evaluation Module for TPS2660x This user’s guide describes the evaluation module (EVM) for the Texas instruments TPS26600, TPS26601, and TPS26602 devices. The document provides configuration information and test setup details for working with the EVM. The EVM schematic, board layout and bill of materials (BOM) are also included. -
Page 2: Introduction
Sensors and controls Description The TPS26600-02EVM enables full evaluation of the TPS2660x devices. The EVM supports HTSOP and QFN versions of the devices on two channels (CH1 and CH2, respectively). Input power is applied at T1 (CH1) and T3 (CH2) while T2 (CH1) and T4 (CH2) provide an output connection to the load. Refer to the... -
Page 3: Schematics
5.36k 8.06k 12.1k 60.4k TP16 TP17 RTN2 TP18 Copyright © 2017, Texas Instruments Incorporated Figure 1. TPS26600-02EVM Schematic SLVUAV3A – August 2016 – Revised February 2017 TPS26600-02EVM: Evaluation Module for TPS2660x Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated... -
Page 4: General Configurations
General Configurations www.ti.com General Configurations Physical Access Table 2 lists the TPS26600-02EVM input and output connector functionality, Table 3 describes the test point availability, and Table 4 describes the jumper functionality. Table 2. Input and Output Connector Functionality Connector Label Description VIN1(+), GND(–) -
Page 5: Jumper And Led Descriptions
A resistive load is recommended for testing. If an electronic load is used, ensure that the output load is set in the constant resistance (CR) mode, not in the constant current (CC) mode. SLVUAV3A – August 2016 – Revised February 2017 TPS26600-02EVM: Evaluation Module for TPS2660x Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated... - Page 6 General Configurations www.ti.com Test Setup Figure 2 shows the typical test setup for the TPS26600-02EVM. Connect T1/T3 to the power supply and xx xx T2/T4 to the load. Oscilloscope Voltmeter LOAD Voltmeter LOAD Figure 2. EVM Test Setup TPS26600-02EVM: Evaluation Module for TPS2660x SLVUAV3A –...
-
Page 7: Power Supply Setting For The Tps26600-02Evm
24 V 2. Turn on the load and set the load resistance to 16 Ω ±1 Ω. 3. Disable the power supply, load and hook up the TPS26600-02EVM assembly as shown in Figure 2 4. Make sure the default evaluation board jumper settings are as shown in Table Table 6. -
Page 8: Tps26600-02Evm Oscilloscope Setting For The Output Voltage Start-Up Test
3. Enable the load. 4. Enable the power supply and verify that the output voltage startup waveform is as shown in Figure Table 8. TPS26600-02EVM Oscilloscope Setting for the Output Voltage Start-Up Test Oscilloscope Setting CH1 Probe Points CH2 Probe Points... -
Page 9: Tps26600-02Evm Oscilloscope Setting For The Current Limit Test
Follow the instructions to verify the current limit and various fault response modes like auto-retry, latch and circuit breaker with auto-retry: 1. Set up the oscilloscope as listed in Table Table 9. TPS26600-02EVM Oscilloscope Setting for the Current Limit Test Oscilloscope Setting CH1 Probe Points CH2 Probe Points... -
Page 10: Tps26600-02Evm: Evaluation Module For Tps2660X
14. Press and release the reset switch (S1/S2) to re-enable the device from latch-off mode and verify the recovery or restart waveform as shown in Figure TPS26600-02EVM: Evaluation Module for TPS2660x SLVUAV3A – August 2016 – Revised February 2017 Submit Documentation Feedback... - Page 11 18. Enable the power supply and verify the circuit breaker with auto retry fault response waveform as shown in Figure Figure 7. J5/J12 = Floating, Current Limit (2.23 A), Circuit Breaker With Auto-Retry Mode SLVUAV3A – August 2016 – Revised February 2017 TPS26600-02EVM: Evaluation Module for TPS2660x Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
- Page 12 Output Short-Circuit Protection Test Follow the instructions to verify the output short-circuit protection feature of the device: 1. Set up the oscilloscope as listed in Table Table 11. TPS26600-02EVM Output Short-Circuit Protection Test Oscilloscope Setting CH1 Probe Points CH2 Probe Points...
- Page 13 Reverse Polarity Test Follow the instructions to verify the reverse polarity protection feature of the device: 1. Set up the oscilloscope as listed in Table Table 12. TPS26600-02EVM Reverse Polarity Test Oscilloscope Setting CH1 Probe Points CH2 Probe Points Channel 1 = 10 V / div...
- Page 14 Figure 12 show component placement and layout of the EVM. Figure 10. Top Side Placement Figure 11. Top Layer TPS26600-02EVM: Evaluation Module for TPS2660x SLVUAV3A – August 2016 – Revised February 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
- Page 15 EVM Board Assembly Drawings and Layout Guidelines www.ti.com Figure 12. Bottom Layer SLVUAV3A – August 2016 – Revised February 2017 TPS26600-02EVM: Evaluation Module for TPS2660x Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
-
Page 16: Submit Documentation Feedback
Bill Of Materials (BOM) www.ti.com Bill Of Materials (BOM) Table 13 displays the EVM BOM. Table 13. TPS26600-02EVM Bill of Materials Item # Designator Value Part Number Manufacturer Description Package Reference !PCB1 HVL162 Printed Circuit Board C2, C3, C8, C10... - Page 17 Bill Of Materials (BOM) www.ti.com Table 13. TPS26600-02EVM Bill of Materials (continued) Item # Designator Value Part Number Manufacturer Description Package Reference TPS26600PWPR Texas Instruments 4.2V-55V, 2.23A, Industrial eFuse with Integrated PWP0016D Reverse Input Polarity Protection C1, C7 0.1uF GRM319R72A104KA01D Murata CAP, CERM, 0.1 µF, 100 V, +/- 10%, X7R, 1206...
- Page 18 Added Instructions to Evaluate the TPS26601 section................• Changed all PCB drawings in the PCB Drawings section....................• Updated BOM for board revision B. Revision History SLVUAV3A – August 2016 – Revised February 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
