OSP Home Furnishings PMO6024 Manual

60" sit / stand electric desk
Hide thumbs

Advertisement

Table of Contents

November, 2024
PMO6024 / PMO6024B
60" SIT / STAND ELECTRIC DESK
Assembly Instructions - Important:
Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the
unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products,
please visit our website: www.officestar.net or call or write us.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMO6024 and is the answer not in the manual?

Questions and answers

Related Manuals for OSP Home Furnishings PMO6024

Summary of Contents for OSP Home Furnishings PMO6024

  • Page 1 November, 2024 PMO6024 / PMO6024B 60" SIT / STAND ELECTRIC DESK Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products,...
