OSP Home Furnishings BRAYDON BRY1288 Assembly Instructions Manual

Writing desk

Table of Contents

Download this manual

August, 2019

BRY1288

BRAYDON WRITING DESK

Assembly Instructions - Important:

Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when

assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or

information on other products, please visit our website: www.officestar.net or call or write us.

Table of Contents

Do you have a question about the BRAYDON BRY1288 and is the answer not in the manual?

Page 1 August, 2019 BRY1288 BRAYDON WRITING DESK Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products, please visit our website: www.officestar.net or call or write us.
Page 2 LIMITED WARRANTY OSP Home Furnishings™ warrants to the original purchaser that this product will be free from defects in material and workmanship as described below. OSP Home Furnishings™ will repair or replace, at its option, without charge to the original purchaser only, defective products or parts for one (1) year from the date of purchase.
Page 3 PARTS (A) Top (1 PC) (B) Left Side Frame (1 PC) (C) Right Side Frame (1 PC) (D) Support (1 PC) HARDWARE LIST DRAWING DESCRIPTION QUANTITY Bolt 8 PCS + 1 EXTRA Cam Screw 4 PCS Cam Nut 4 PCS Flat Washer 8 PCS + 1 EXTRA Lock Washer...
Page 4 STEP 1 CAM LOCK INSTRUCTIONS 180° 180° FULLY TIGHTEN ALL CAM SCREWS (2) USING PHILLIPS SCREWDRIVER (NOT PROVIDED). STEP 2 FULLY TIGHTEN ALL CAM NUTS (3) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
Page 5 STEP 3 FULLY TIGHTEN ALL CAM NUTS (3) USING PHILLIPS SCREWDRIVER (NOT PROVIDED). STEP 4...
Page 6 STEP 5 FULLY TIGHTEN ALL BOLTS (1).
Page 7 BY213...
