DOOR LATCH REPLACEMENT KIT INSTALLATION
FOR AIR HANDLERS
Turn OFF the gas supply and then disconnect the electric power before performing service work.
• Refer to the installation manual provided with the unit for important safety information.
• Ensure that all components listed in
Item No. (See Figure
1
2
3
4
5
6
NOTE: The required tools are a push-on retainer tool or 5/8-inch deep socket and a flat-head
screwdriver.
Install the door latch replacement kit as follows. Item numbers in parentheses refer to
1. Ensure that gas and electric power are turned OFF.
DO NOT DESTROY. PLEASE READ CAREFULLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
Revision: RPB-RPBL-SSCBL-DOOR-LATCH (03-25) 112975-C
MODELS RPB, RPBL, AND SSCBL
⚠ WARNING ⚠
Table 1
Table 1. Door Latch Replacement Kit (PN 112974) Components
1) Component
Door latch shaft
Trim washer
Neoprene washer
Retainer
Pawl
2
1
Figure 1. Door Latch Assembly
Supersedes: OPT-DOOR-LATCH (11-24) 112975-B
are available before beginning installation.
Slotted head with directional arrow (#61-11-1-14)
Metal (#61-7-3-14)
Outer, black (#85-43-201-38)
Inner, black (#85-33-101-27)
Metal (#61-6-1-13)
With setscrew (#61-9-1-11)
5
3
1/4-INCH MOUNTING HOLE
DOOR PANEL
INSTALLATION
Description
6
SETSCREW
4
Figure 1.
