COOLING COIL CABINET INSTALLATION FOR AIR HANDLERS
OPTIONS AU2, AU11, AND AU12 FOR MODELS RPB, RPBL, AND SSCBL
• Before installation, check the supporting structure to ensure that it has sufficient load-carrying
capacity to support the weight of the unit along with any optional equipment.
• Do NOT install the cooling coil cabinet before lifting the packaged blower/furnace system into
position. Lift the cooling coil cabinet separately. Do NOT install the cooling coil cabinet while
the furnace is in operation.
The cooling coil cabinet is designed to enclose a field-supplied chilled water cooling coil and is shipped separately
for field-installation. Cabinets alone (option AU2) have a horizontal discharge but may have an attached downturn
plenum (option AU11 or AU12) for vertical discharge. Option AU11 is a cooling coil cabinet with a downturn plenum
(option AQ5). Option AU12 is a cooling coil cabinet with a downturn plenum with dampers (option AQ8).
Important Safety Information
Refer to the installation manual provided with the heater for important safety information. Pay attention to all
dangers, warnings, cautions, and notes highlighted in this manual. Safety markings should not be ignored and are
used frequently throughout to designate a degree or level of seriousness.
Components
Ensure that required components (refer to
before beginning installation.
Component
Top/bottom, 35-5/16
Top/bottom, 40-13/16
Duct connector
Top/bottom, 46-5/16
Side, 18-13/16
Top
Filler panel
Left side
Right side
3/32 × 1-1/8 × 53-7/8
Rubber gasket strip
3/32 × 1-1/8 × 59-3/8
3/32 × 1-1/8 × 64-7/8
Insulation
1 × 42 × 9
#10 × 1/2
Sheet metal screw
#14 × 3/4
DO NOT DESTROY. PLEASE READ CAREFULLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
Revision: RPB-RPBL-SSCBL-AU2,11,12 (10-24) 1047571-0
⚠ DANGER ⚠
GENERAL INFORMATION
Table
Table 1. Cooling Coil Cabinet Components
Description
1) that are shipped inside the cooling coil cabinet are available
RPB Unit Size (MBTUh)
250, 300
RPBL AND SSCBL Unit Size (MBTUh)
500, 600
106338 (2)
172362 (1)
103608 (1)
11813 (24)
Supersedes: — (Original Version)
350
700, 1050
PN (Quantity)
106339 (2)
106395 (2)
172363 (1)
172357 (1)
172358 (1)
103609 (1)
172546 (2)
11813 (25)
105171 (8)
400
400, 800, 1200
106340 (2)
172364 (1)
106310 (1)
11813 (26)

Advertisement

loading
Need help?

Need help?

Do you have a question about the RPB-RPBL-SSCBL-AU2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Reznor RPB-RPBL-SSCBL-AU2

  • Page 1 Revision: RPB-RPBL-SSCBL-AU2,11,12 (10-24) 1047571-0 Supersedes: — (Original Version) COOLING COIL CABINET INSTALLATION FOR AIR HANDLERS OPTIONS AU2, AU11, AND AU12 FOR MODELS RPB, RPBL, AND SSCBL ⚠ DANGER ⚠ • Before installation, check the supporting structure to ensure that it has sufficient load-carrying capacity to support the weight of the unit along with any optional equipment.
