INDOOR AND OUTDOOR PACKAGED SYSTEM INSTALLATION,
OPERATION, AND MAINTENANCE
INDOOR SEPARATED-COMBUSTION MODEL SSCBL
OUTDOOR POWER-VENTED MODEL RPBL
SSCBL
• Failure to follow safety warnings exactly could result in serious injury, death, or property
damage.
• Improper installation, adjustment, alteration, service, or maintenance can cause serious injury,
death, or property damage.
• Installation and service must be performed by a qualified installer, service agency, or the gas
supplier.
• Be sure to read and understand the installation, operation, and service instructions in this
manual.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a phone remote from the building. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
DO NOT DESTROY. PLEASE READ CAREFULLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
Revision: SSCBL-RPBL-IOM (10-22) 149159-C
Supersedes: SSCBL-RPBL-IOM (08-22) 149159-B
 ⚠ DANGER ⚠ 
FIRE OR EXPLOSION HAZARD
WHAT TO DO IF YOU SMELL GAS
RPBL
