R
INSTALLATION MANUAL
Kore Workstation Stainless
Steel Farmhouse Kitchen Sinks
KWF210-24, KWF210-27,
KWF210-27/PGM, KWF210-30,
KWF210-33, KWF210-33/PGM,
KWF210-36, KWF410-30, KWF410-33,
KWF410-33/PGM, KWF410-36
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. October 26, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kore KWF210-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kraus Kore KWF210-24

Summary of Contents for Kraus Kore KWF210-24

  • Page 1 INSTALLATION MANUAL Kore Workstation Stainless Steel Farmhouse Kitchen Sinks KWF210-24, KWF210-27, KWF210-27/PGM, KWF210-30, KWF210-33, KWF210-33/PGM, KWF210-36, KWF410-30, KWF410-33, KWF410-33/PGM, KWF410-36 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. October 26, 2020...
  • Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...

  • Page 3: Tools You Will Need

    Toll-Free: 800-775-0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional.

  • Page 4: Parts List

    Parts List KWF210-24 KWF210-33/PGM KWF410-36 · Cut-Out Template · Cut-Out Template · Cut-Out Template · Mounting Hardware · Mounting Hardware · Mounting Hardware Bottom Grid KBG-UN1-24 · · Bottom Grid KBG-UN1-33/PGM · Bottom Grid KBG-UN1-36 Strainer ST-1 · · Strainer ST-1/PGM ·...
  • Page 5 Dimensions: 26 7/8" 23 7/8" (606.4mm) (682.6mm) 25" 22" (558.8mm) (635mm) 5" 5" (127mm) (127mm) 3 1/2" (90mm) Model #: KWF210-24 Model #: KWF210-27 & KWF210-27/PGM Sink Dimensions: 23 7/8” x 20 1/4” x 10” Sink Dimensions: 26 7/8” x 20 1/4” x 10” Min Cabinet Size: 27”...
  • Page 6 Dimensions: 35 7/8" (911.2mm) 29 7/8" (758.8mm) 34" (863.6mm) 28" (711.2mm) 5" 5" (127mm) (127mm) 3 1/2" 3 1/2" (90mm) (90mm) 2 1/4" (57.2mm) R1/8" (3mm) Model #: KWF210-36 Model #: KWF410-30 Sink Dimensions: 35 7/8” x 20 1/4” x 10” Sink Dimensions: 29 7/8”...
  • Page 7 Step 1. Determine Reveal Type · Use scissors to cut along the line of the paper template for your desired reveal type (Negative, Positive, or Flushed Reveal) KRAUS Recommended Installation Type 3/8” Positive Reveal 3/8” Positive Flushed/Zero Reveal Centerline Flushed/Zero Step 2.
  • Page 8 Step 3. Trace Template · Trace template on countertop with a pencil. Step 4. Cut Countertop · Cut the opening in the countertop by carefully following the traced line. NOTE: Please use the appropriate saw that best fits your countertop material.
  • Page 9 Step 5. Cut Cabinet Front · Measure height of apron front. Add 1/16" to the dimension when you mark base cabinet front cutout. Use jigsaw to cut. Step 6. Set Up Mounting Brackets · Turn countertop over and align sink with countertop. Decide location for mounting brackets. ·...
  • Page 10 Step 7. Drill Hole in Countertop · Drill 3/8" diameter x 1/2" deep hole in the countertop.
  • Page 11 Step 8. Install Anchors · Insert anchors into drilled holes and lightly tap with a hammer until flush.
  • Page 12 Step 9. Secure Sink to Countertop · Use a bead of silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the cutout in the countertop. Place sink over cutout hole and press firmly.

  • Page 13: Step 10. Attach Mounting Hardware

    Step 10. Attach Mounting Hardware · Attach mounting hardware to secure bowl. Remove excess sealant from inside lip. · Allow sealant to set for 30 - 60 minutes. NOTE: Use acetone or rubbing alcohol to remove any excess sealant.
  • Page 14 Step 11. Install Plumbing Fixtures · Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer's instructions. Run water into sink and check for leaks. · Note: Before installation, please check that the drain kit complies with ASME A112.18.2/CSA B125.2 and with CUPC ·...
  • Page 15 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
  • Page 16 Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a plumbing contractor or trade professional please contact a Kraus Pro Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
  • Page 17 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
  • Page 18 INSTALLATION MANUAL Food Waste Disposer KWD100-75, KWD100-100 www.kraususa.com Toll Free: 1.800.775.0703 © 2021 Kraus USA Plumbing LLC REV. October 12, 2021...
  • Page 19 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
  • Page 20 Metal, such as bottle caps, tin cans, or utensils Hot grease or other hot liquids. When not operating a disposer, leave the drain cover in place to reduce the risk of objects falling into the disposer. SAVE THESE INSTRUCTIONS Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance...
  • Page 21 Dimensions 7 1/2" 10 1/4" (191mm) (259.3mm) 7 5/8" 4 1/2" (193mm) (113.7mm) KWD100-75 10 3/4" 8 5/8" (273.5mm) (220mm) 4 1/2" 8 5/8" (113.7mm) (220mm) KWD100-100...

  • Page 22: Grounding Instructions

    Grounding Instructions This disposer must be grounded to reduce the risk of electric shock in the event of a malfunction or breakdown. Grounding provides a path of least resistance for electric current. This disposer is equipped with a cord having an equipment-grounding conductor and a grounding plug.

  • Page 23: Tools You May Need

    Tools You May Need Screwdriver Phillips Screwdriver Hacksaw Plumber's Putty Hammer Dishwasher Connector Kit Pipe Wrench Dowel or Steel Punch Important Safety Instructions INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS. SAVE THESE INSTRUCTIONS. WARNING –...

  • Page 24: Step 1. Removal Of Old Unit

    Step 1. Removal of Old Unit Before starting this step, turn off electrical power at the circuit breaker or fuse box. If your old mount is the same as the mount on your new disposer, just reverse the assembly instructions found in section 3. If your new mount system is different, follow these instructions: Use a pipe wrench to disconnect drain line where it attaches to disposer discharge tube (see 1A).

  • Page 25: Step 2. Dishwasher Connection

    Step 2. Dishwasher Connection If you are utilizing a dishwasher, complete the following procedure. If dishwasher is not to be connected go on to section 3. Make use of a blunt instrument to knock out the housing cap(see 2A1), please sure to use a steel punch or wooden dowel but not sharp instrument.
  • Page 26 READ COMPLETELY BEFORE STARTING NOTE: Pay close attention to the order of mount assembly parts, as they have been correctly assembled by the factory. Also, reference the cushion mount detail in illustration 3D below for the proper orientation of the cushion mount. NOTE: Try practicing this assembly before you get under the sink to get the “feel”...
  • Page 27 MOUNTING SEAL RING DETAIL SINK MOUNTING MOUNTING RING RUBBER TOP OF SINK FLANGE SINK WASHER FIBER MOUNTING WASHER BOTTOM "LIP" OF SINK BOTTOM FLANGE SINK BEAD OF GROOVE FLANGE MOUNTING SEAL RING MOUNTING RING SHOULD BE BOTTOM OPEN AREA, NO MOUNTING SEAL RING FREE TO MOVE UP &...

  • Page 28: Step 4. Electrical Connections

    Step 4. Electrical Connections Now is the time to record the BATCH NUMBER (located on the bottom of the disposer) onto the warranty card. IF YOU ARE NOT FAMILIAR WITH ELECTRICAL POWER AND PROCEDURES, CALL A QUALIFIED ELECTRICIAN. WARNING: Improper connection of the equipment grounding conductor can result in a risk of electric shock.
  • Page 29 Step 6. Connecting Disposer to Mount Assembly EZ Mount Line up disposer under mounting assembly. Guide hopper projections into mounting ring slots. Turn mounting ring about 1/4”± to right so that disposer is temporarily supported (see 6A). Turn mounting ring and disposer until drain elbow lines up with trap (see 6B). Turn mounting ring to the right (clockwise) until it locks up tight.
  • Page 30 TIPS FOR SUCCESSFUL OPERATION Be sure disposer is empty before using your dishwasher so it may drain properly. You may want to leave the stopper in the drain when not in use to prevent utensils and foreign objects from falling into the disposer. Your disposer is ruggedly built to give you many years of trouble free service.

  • Page 31: Replacement Parts

    Replacement Parts Replacement Parts List Part # 1. Sink Flange KP52000 2. Rubber Washer KP52001 3. Fiber Washer KP52002 4. Mounting Nut KP52003 5. Mounting Screw x 3 KP52004 KP52005 6. Mounting Ring KP52006 7. Mounting Seal Ring KP52007 8. Splash Guard 9.

  • Page 32: Troubleshooting

    Troubleshooting Before seeking repair or replacement, we recommend that you review the following: LOUD NOISES: (Other than those during grinding of small bones and fruit pits): These are usually caused by accidental entry of a spoon, bottle cap or other foreign objects. To correct this, turn off electrical switch and water.
  • Page 33 (5) years from the date of purchase from an authorized Kraus dealer. Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus.
  • Page 34 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
  • Page 35 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
  • Page 36 INSTALLATION GUIDE Kitchen Strainer ST-1 / ST-2 / ST-3 / BST-1 / BST-2 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. November 5, 2020...
  • Page 37 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...

  • Page 38: Prior To Installation

    Toll-Free: 800-775-0703 or Customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional.
  • Page 39 Diagram and Parts List ST-1 A. Strainer Cover B. Screw C. Metal Strainer D. Foam Gasket E. Rubber Gasket F. Main Body G. Drain Gasket H. Drain Nut ST-2 A. Strainer Cover B. Screw C. Metal Strainer D. Foam Gasket E.
  • Page 40 Diagram and Parts List BST-1 A. Strainer Cover B. Basket C. Screw D. Metal Strainer E. Foam Gasket F. Rubber Gasket G. Main Body H. Drain Gasket I. Drain Nut BST-2 A. Strainer Cover B. Basket C. Screw D. Metal Strainer E.
  • Page 41 Diagram and Parts List ST-3 A. Strainer Cover B. Screw C. Metal Strainer D. Foam Gasket E. Rubber Gasket F. Main Body G. Drain Gasket H. Drain Nut...
  • Page 42 Dimensions Ø 4 1/2" Ø 4 1/2" Ø 4 1/2" (115mm) (115mm) (114mm) 3 3/4" 3 3/4" 4 1/2" (94mm) (94mm) (114mm) 1 1/2" - 1 1/2" - 1 1/2" - 11 1/2" Ø 4 3/4" 11 1/2" Ø 4 3/4" 4 5/8"...
  • Page 43 Step 1. Disassemble strainer...
  • Page 44 Step 2. Insert metal strainer into drain hole with foam gasket attached. Install rubber gasket and main body underneath the sink Strainer Cover Screw Metal Strainer Foam Gasket Rubber Gasket Main Body Drain Gasket Drain Nut...
  • Page 45 Step 3. Using the screw, tighten the metal strainer and main body into place Screw Step 4. Insert strainer cover to seal water Strainer Cover...

  • Page 46: Replacement Parts

    Replacement Parts ST-1 Replacement Parts List Finish Part # A. Strainer Cover KPU00010 A. Strainer Cover PGM* KPU00010-PGM B. Screw 1 1/4" KPU00003 B. Screw 1 1/4" PGM* KPU00003-PGM C. Metal Strainer KPU00011 C. Metal Strainer PGM* KPU00011-PGM D. Foam Gasket KPU00005 E.
  • Page 47 Replacement Parts ST-2 Replacement Parts List Finish Part # A. Strainer Cover KPU00010 B. Screw 1 5/8" KPU00013 C. Metal Strainer KPU00011 KPU00005 D. Foam Gasket KPU00006 E. Rubber Gasket KPU00012 F. Main Body KPU00008 G. Drain Gasket KPU00009 H. Drain Nut...
  • Page 48 Replacement Parts BST-1 Replacement Parts List Finish Part # A. Strainer Cover KPU00001 B. Basket KPU00002 C. Screw 1 1/4" KPU00003 KPU00004 D. Metal Strainer KPU00005 E. Foam Gasket KPU00006 F. Rubber Gasket KPU00007 G. Main Body KPU00008 H. Drain Gasket KPU00009 Drain Nut BST-2...
  • Page 49 Replacement Parts ST-3 Replacement Parts List Finish Part # A. Strainer Cover KP22191 B. Screw KP22198 C. Metal Strainer KP22192 KP22193 D. Foam Gasket KP22194 E. Rubber Gasket KP22195 F. Main Body KP22196 G. Drain Gasket KP22197 H. Drain Nut...
  • Page 50 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
  • Page 51 12 Harbor Park Drive Port Washington, NY 11050 Toll-Free : 800-775-0703 Customerservice@kraususa.com If you are a PLUMBING CONTRACTOR OR TRADE PROFESSIONAL , please contact a Kraus Pro Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
  • Page 52 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
