- Page 1 INSTALLATION MANUAL Kore Workstation Stainless Steel Dual Mount Kitchen Sinks KWT311-15, KWT321-15, KWT301-25, KWT311-25, KWT311-25-5.5, KWT300-28, KWT310-28, KWT300-30 , KWT302-30, KWT310-30 , KWT300-33, KWT302-33, KWT310-33/PGM © 2021 Kraus USA Plumbing LLC I REV. September 22, 2021...
-
Page 2: Tools You Will Need
The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. -
Page 3: Parts List
Parts List KWT311-15 KWT311-25-5.5 Cut-Out Template Cut-Out Template · · Mounting Hardware Mounting Hardware · · Strainer ST-1 Bottom Grid KBG-UN1-25 · · Drain Cap STC-2 Strainer ST-1 · · Cover Board KCB-WS13BB Drain Cap STC-2 · · Cutting Board KCB-WS102BB ·... - Page 4 Parts List KWT302-30 KWT310-33/PGM Cut-Out Template Cut-Out Template · · Mounting Hardware Mounting Hardware · · Bottom Grid KBG-WSU1-30 x 2 Bottom Grid KBG-UN1-33/PGM · · Strainer ST-1 x 2 Strainer ST-1/PGM · · Drain Cap STC-2 x 2 Drain Cap STC-2/PGM ·...
- Page 5 Dimensions: 15" (381mm) 15" (381mm) 13" 13" (330.2mm) (330.2mm) 12" (304.8mm) Ø1 3/8" Ø1 3/8" (35mm) (35mm) R 0" R 0" (0mm) 3 1/2" (0mm) (90mm) 3 1/2" (90mm) Model #: KWT311-15 Model #: KWT321-15 Sink Dimensions: 15” x 22” x 9” Sink Dimensions: 15”...
- Page 6 Dimensions: Typical note: *= Special Order 25" (635mm) 28" (711.2mm) 23" (584.2mm) 26" (660.4mm) 5" Ø1 3/8" (127mm) Ø1 3/8" 3 1/2" (35mm) (35mm) (89mm) R 0" R 0" 3 1/2" (0mm) 3 1/2" (0mm) (90mm) (90mm) Model #: KWT311-25-5.5* Model #: KWT300-28 Sink Dimensions: 25”...
- Page 7 Dimensions: 30" (762mm) 30" (762mm) 28" (711.2mm) 28" (711.2mm) Ø1 3/8" 3 1/2" 5" (35mm) (89mm) (127mm) Ø1 3/8" 3 1/2" (35mm) (89mm) R 0" (0mm) 3 1/2" R 0" 3 1/2" (90mm) (0mm) (90mm) 13 7/8" 13 7/8" (353.6mm) (353.6mm) 1/8"...
- Page 8 Dimensions: 33" (838mm) 31" (787mm) 5" (127mm) Ø1 3/8" 3 1/2" (35mm) (89mm) R 0" 3 1/2" (0mm) (90mm) Model #: KWT310-33/PGM Sink Dimensions: 33” x 22” x 9” Min Cabinet Size: 36”...
-
Page 9: Top Mount Installation
Top Mount Installation Step 1. Position Template Check the cut-out template against the actual sink to ensure a proper · sized cut-out. Place the cut-out template in the desired location on the countertop. · NOTE: Make sure clearance is suitable for backsplash, faucet and plumbing for the sink. Step 2. - Page 10 Step 3. Cut Countertop Cut the opening in the countertop by carefully following the traced line. · NOTE: Please use the appropriate saw that best fits your countertop material.
-
Page 11: Step 4. Attach Mounting Hardware
Step 4. Attach Mounting Hardware Attach mounting hardware to the prongs protruding from the underside of the sink rim. · Make sure the hooked side of the mounting clip is facing away from the sink. · NOTE: Maximum countertop thickness for Top Mount installation is 1 1/2". - Page 12 Step 5. Apply Silicone or Plumber's Putty Clean and dry the surface around the opening of the sink. · Turn the unit upside down to apply sealant. Apply silicone-based sealant (not included) underneath the edge of the · sink.
- Page 13 Step 6. Secure Sink to Countertop Insert the sink into the opening, check the alignment of the sink to the cutout in the countertop and press firmly. · Tighten the screws in the front of the sink, followed by the ones in the back and on the sides of the sink. ·...
-
Page 14: Maintenance
Step 7. Install Plumbing Fixtures Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer's · instructions. Run water into sink and check for leaks. · Note: Before installation, please check that the drain kit complies with ASME A112.18.2/CSA B125.2 and with CUPC ·... - Page 15 Undermount Installation Step 1. Determine reveal type Use scissors to cut along the line of the paper template for your desired reveal type (Negative, Positive, or Flush Reveal) · KRAUS Recommended Installation Type 3/8" Positive Reveal Flush/Zero Reveal 3/8" POSITIVE...
- Page 16 Step 2. Position template Check the cut-out template against the actual sink to ensure a proper · sized cut-out. Place the cut-out template in the desired location on the countertop. · NOTE: Make sure clearance is suitable for backsplash, faucet and plumbing for the sink. Step 3.
- Page 17 Step 4. Cut Countertop Cut the opening in the countertop by carefully following the traced · line.
- Page 18 Step 6. Drill hole in countertop Step 7. Install anchors Insert anchors into drilled holes and lightly tap with a hammer until flush. ·...
- Page 19 Step 8. Secure sink to countertop Use a bead of silicone (or preferred adhesive) around the rim of the · sink. Check the alignment of the sink to the cutout in the countertop. Place sink over cutout hole and press firmly. Step 9.
- Page 20 Step 10. Install Plumbing Fixtures Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer's · instructions. Run water into sink and check for leaks. · Note: Before installation, please check that the drain kit complies with ASME A112.18.2/CSA B125.2 and with CUPC ·...
- Page 21 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
