- Page 2 CONSUMER PRODUCT INFORMATION For your own records, please attach a copy of your sales receipt to this manual and complete the following: Model Number: _____________________________________ Serial Number: _______________________________________ Purchase Date: ____________________________________ Store Purchased: _____________________________________ Installation Date: ___________________________________ Installation Co.: _______________________________________ Installer Name: _____________________________________ Installer Phone No.: ___________________________________...
- Page 3 CONTENTS SAFETY PRECAUTIONS ..............1 IMPORTANT SAFETY INSTRUCTIONS ...........3 INSTALLATION INSTRUCTIONS .............4 NORMAL SOUNDS ................13 AIR CONDITIONER FEATURES ............14 CARE AND CLEANING ..............16 TROUBLESHOOTING ...............16 This manual provides the information needed for proper use and maintenance of this air conditioner. Basic preventative care can help extend the life of this unit. The “Troubleshooting”...
- Page 4 SAFETY PRECAUTIONS READ SAFETY PRECAUTIONS BEFORE INSTALLATION To prevent injury to the user or other people and property damage, the following instructions must be followed. Incor- rect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications.
- Page 5 CAUTIONS When removing air filter, DO NOT touch metal parts of the Doing so may cause an injury. unit. DO NOT clean with water. Water may enter the unit and degrade the insulation causing an electric shock. Ensure proper ventilation especially in rooms with a stove Failure to do so may result in an oxygen shortage.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS NOTE: WARNING The power supply cord with this air condi- FOR YOUR SAFETY: Do not store or use gasoline or other flammable tioner contains a current detection device vapors and liquids in the vicinity of this or any other appliances. designed to reduce the risk of fire.
- Page 7 INSTALLATION INSTRUCTIONS If cold water pipe is interrupted by plastic, non-metallic gaskets, or other insulating materials, DO NOT use for BEFORE YOU BEGIN grounding. Check with a qualified electrician if you are in doubt as Read these instructions completely and care- to whether the appliance is pro-perly grounded.
- Page 8 INSTALLATION INSTRUCTIONS 1. Make sure you have all the necessary parts. Installation kit contents: Platform(1) Support brace(1) Adjustment bolt(1) Hex flange nut - 1 / 4 (1) Track seal(1) Side channel seal(1) Foam seal strip/Sash seal Safety bracket(1) 9-11 .Screw-2-1/2 (2), orScrew-1-3/4 (2), or Screw-1 (2) Screw-3/4 (6) Screw-3/4 self-threading(7) Window locking bracket(1)
- Page 9 INSTALLATION INSTRUCTIONS 3. Choose the proper window location Choose a window that allows the cooled air to flow freely and directly into room(s) you wish to cool. Remember, it is difficult to move air around corners. Also, choose a window that is within 6 feet of an electrical outlet.
- Page 10 INSTALLATION INSTRUCTIONS Apply track seal to 4. Peel off protective backing from track seal. Replace window side of track. seal to room side of window track. Center of seal strip should coincide with the nine marked in step 2. The two screw holes drilled in step 3 should be directly above seal strip in the inner track.
- Page 11 INSTALLATION INSTRUCTIONS 10. Clamp plastic window panel between a board and a worktable and cut along cutting line with a fine tooth saw. Remove any bars with a file. Fastening Side Channels 11. Fasten side channels to the sides of the easy using three screws (items 17) per channel.
- Page 12 INSTALLATION INSTRUCTIONS 16. Slide the inner window sash firmly against the side of the cabinet. Make sure not to peel the seal strips from the window track and cabinets side channels. If the panel frame does not fit snugly to the inner window sash, secure the panel frame to the sash with ¾-inch screws, or ¾-inch self-threading screws.
- Page 13 INSTALLATION INSTRUCTIONS Alternate Window Jamb Applications To install in windows having no flanges or wood stops on the Top and side jambs, the channels and panel frames fit against a meeting flange (or 1/16- 4 or 1 4 or 1 inch max.
- Page 14 INSTALLATION INSTRUCTIONS Measure from here About 1” to 1 ¼” 5.Adjust the platform assembly so that the rear of the air conditioner will be 3/16-inch lower than the front. This ensures proper water drainage from the air conditioner. NOTE: Adjust the platform assembly so that the air conditioner will be 111;...
- Page 15 INSTALLATION INSTRUCTIONS 15.To remove front 1.Remove the two front retaining screws from the front frame. 2.Gently pull the front out and lift up to release it from the case. 3.Then release the coupler plugs. NOTE: DO NOT push or pull air direction louvers. 13.Place the air conditioner in the window opening as Front Retaining shown to the right.
- Page 16 NORMAL SOUNDS High Pitched Chatter Vibration High efficiency compressors may Unit may vibrate and make noise because have a high pitched chatter during the of poor wall or window construction or incor- cooling cycle. rect installation. Sound of Rushing Air At the front of the unit, you may hear the sound of rushing air being moved by the fan...
- Page 17 AIR CONDITIONER FEATURES TO SELECT THE OPERATING MODE: TO ADJUST FAN SPEEDS: Press to select the Fan Speed in four steps-Auto, To choose operating mode, press Mode button.Each Low, Med or High. Each time the button is pressed, time you press the button, a mode is selected in a se- the fan speed mode is shifted.
- Page 18 AIR CONDITIONER FEATURES DISPLAYS: Exhaust Control Displays Timer Exhaust Energy Saver Timer closed open Auto Cool Dry Fan Mode DISPLAYS: Shows the set temperature in C or F and the This Exhaust Control allows the air conditioner to either Auto-timer settings.While on Fan only mode,it shows circulate inside air (Closed) or exhaust air to the the room temperature.
- Page 19 CARE AND CLEANING Air Filter Cleaning Cabinet Cleaning Be sure to unplug the air conditioner to prevent shock or fire Take the filter by the center and pull up and out. Wash the filteru sing l iquid d ishwashing d etergent hazard.
- Page 20 TROUBLESHOOTING TIPS Problem Solution Dirty air filter- air restricted. Clean air filter. Refer to Care and Cleaning section. Air conditioner cooling, but roomis too warm- NO Temperature is set too High, set temperature to a Lower setting. ice forming on cooling coil Air directional louvers positioned improperly.
