Printed Matter No. 9839 0890 01
Publication Date 2019-11-08
Valid from Serial No. A1790001
D2121 (750 r/min)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
8421040521
WARNING
D2121
Pistol-grip Drills
Product Instructions
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Atlas Copco D2121
Summary of Contents for Atlas Copco D2121
- Page 1 Printed Matter No. 9839 0890 01 Pistol-grip Drills Publication Date 2019-11-08 Valid from Serial No. A1790001 Product Instructions D2121 (750 r/min) 8421040521 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
- Page 2 Preparations for service and maintenance .......... 12 Service recommendations .............. 12 Preventive maintenance .............. 12 Lubrication Instructions................... 12 Rust protection and cleaning ............... 12 Lubrication guide ................. 13 Maintenance and lubrication.............. 13 Dismantling/Assembling Instructions .............. 14 Instructions for vane motor .............. 14 © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 3 Troubleshooting.................... 16 Troubleshooting .................... 16 Recycling ....................... 17 Environmental Regulations................ 17 Recycling information .................. 17 © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 4 ■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions.
- Page 5 For further Technical Information, please contact your local Atlas Copco representative. Safety Data Sheets MSDS/SDS The Safety Data Sheets describe the chemical products sold by Atlas Copco. Please consult the Atlas Copco website for more information www.atlascopco.com/sds. Installation of Vibrating Tools We recommend using a minimum length of 300 mm (12") of flexible hose for compressed air between a vi-...
- Page 6 Vibration value 2.5 m/s Height (H) Length (L) 248 mm Technical Product Data Technical Product Data can be found on either ServAid, or the Atlas Copco website. Please visit: https://servaid.atlascopco.com or www.atlascopco.com. Service Overview Maintenance and service instructions The service must only be done by authorized workshops or qualified service technicians.
- Page 7 Make sure to perform a preventive maintenance every 6 months. If it is used in heavy duty conditions or not running properly, it should be removed from operation for inspection more often. © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 8 Air Quality ■ For optimum performance and maximum product life we recommend the use of compressed air with a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration type air dryer. ■ Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of liquid water.
- Page 9 Connect the tool to the air supply. Use the appropriate drilling speed for the application. To start the tool, press the trigger. When lubrication is recommended - only use lubricants recommended by Atlas Copco. © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 10 Drain the hose of air pressure and disconnect the tool from air supply when not in use or before ► any adjustments. Always use the correct hose size and air pressure for the tool. ► © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 11 10. If the drill gets caught in the material, release the trigger immediately, unplug the drill and remove the bit from the material. When lubrication is recommended - only use lubricants recommended by Atlas Copco. © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 12 Lubrication Instructions Rust protection and cleaning Water in the compressed air can cause rust. To prevent rust we strongly recommend to install an air dryer. © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 13 5-10 seconds. The strainer in the adapter should be cleaned regularly to prevent choking which will lead to a loss in ca- pacity. © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 14 4080 0182 07 12.5 4080 0182 08 15.5 4080 0182 09 17.5 4080 0182 10 20.5 4080 0182 11 25.5 4080 0182 12 30.5 4080 0182 13 35.5 4080 0182 14 40.5 © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 15 4080 0567 02 18.5 4080 0567 06 21.5 4080 0567 03 21.5 4080 0567 07 25.5 10.5 4080 0567 08 27.5 12.5 4080 0567 09 31.5 15.5 4080 0567 10 34.5 18.5 © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 16 Make sure that the amount of ing. grease is correct. Damaged gear. Worn motor bearings. *) This service must only be carried out by authorized workshop or qualified service technician. © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 17 Plastics, Other, POM Adapter and adjacent parts Metal, Steel *The rotor blades (vanes) in the tool contains PTFE, the normal health and safety recommendations con- cerning PTFE must be observed. © Atlas Copco Industrial Technique AB - 9839 0890 01...
- Page 20 Original instructions Atlas Copco Industrial © Copyright 2019, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
