Summary of Contents for Atlas Copco PHE50H

  • Page 2 Repair Instructions No.184.11/98 PAGE PHE 50 H Special Tools Allen key, long 4931 599 010 Require Forcing disks 4931 599 018 (Dis-) Assembly tool 4931 599 011 Important! Before beginning the maintenance work, perform an initial check with a high voltage test according to VDE (see chapter Electrical and Mechanical Test Instructions).
  • Page 3 Repair Instructions No.184.11/98 PAGE PHE 50 H Removing the On both sides, loosen the screw (4) and electric remove the cover (3). components Loosen the screw (A). Lever off the Softgrip (8) from above since it is fitted at the top (see arrow in illustra- tion).
  • Page 4 Repair Instructions No.184.11/98 PAGE PHE 50 H Detaching the Loosen two screws (2) and then the four gear box cover screws (5) and detach the complete mo- tor (1) with the gear box cover (3) and the gasket (4). Remove the complete motor (1) by hitting the gear box cover (3) or the armature pin- ion with a plastic hammer.
  • Page 5 Repair Instructions No.184.11/98 PAGE PHE 50 H Detaching Remove the air deflector ring (4) from the the field motor housing (1). Undo both screws together with their spring washers (3) and knock the field (2) from the motor housing (1) with aid of a plastic hammer.
  • Page 6 Repair Instructions No.184.11/98 PAGE PHE 50 H Removing the Loosen 2 screws (2). drive shaft Pull the complete drive shaft (1) from the gear box (3). If necessary, hit the drive (1) with a plastic hammer for support fix the projecting drive in a vice with aluminium jaws and pull off the gear box (3).
  • Page 7 Repair Instructions No.184.11/98 PAGE PHE 50 H Detaching the Undo the two screws (F) and remove the bevel wheel anti-vibration plate spring (E). Undo the five screws (7) together with their washers and remove the flange (6) from the gear box (D). Undo the four nuts (9), remove the wash- ers and detach the cover (A) as well as the gasket (B).

  • Page 8: Maintenance

    Repair Instructions No.184.11/98 PAGE PHE 50 H Disassembling Remove the striker (G) from the spindle the spindle sleeve (F) and remove the O-ring (H) from sleeve the striker (G). Remove the following parts: - bearing ring (1), - balls (2) (6 pcs.), - O-rings (3), - driver (4), - ring (5),...
  • Page 9 Repair Instructions No.184.11/98 PAGE PHE 50 H Legend Cover with grease DARINA (total of 50 g) (4931 622 229) Cover with blue grease Mobilith HP 222 (40 g total) (9170 304 322) Cover with Tivela Compound A (10 g) (4931 70 215 436) 30 g 3 Nm 10 g...
  • Page 10 Repair Instructions No.184.11/98 PAGE PHE 50 H Assembly Assembling the Mount the ball bearing (E) and the locking spindle sleeve ring (D) on the spindle sleeve (F). Mount the following parts inside the spin- dle sleeve (F): - rings (C, B and A), - O-ring (9), - sleeve (8), - anvil (7),...
  • Page 11 Repair Instructions No.184.11/98 PAGE PHE 50 H Mounting Mount the following parts on the pinion (1): the pinion - ball bearing (2) (press on), - plate (3), - sleeve (A), - spring plate (4), - friction disk (5), - drive wheel (6), - friction disk (7), - spring plate (8).
  • Page 12 Repair Instructions No.184.11/98 PAGE PHE 50 H Mounting Insert the complete spindle sleeve with the crank piston and connecting rod (6) into the gear box (5). Take care that the toothing of the spin- dle sleeve and the toothing of the gear wheel work into each other.
  • Page 13 Repair Instructions No.184.11/98 PAGE PHE 50 H Mounting Insert the field (2) into the motor hous- the field ing (1) (mind the right position!) and fasten it with screws (3) and washers (tightening moment = 8 Nm). Mount the air deflector ring (4). Mounting the Fit the seal ring (9) to the armature (A).
  • Page 14 Repair Instructions No.184.11/98 PAGE PHE 50 H Mounting the Insert the sleeve (3), the spring (4) and the nosepiece bolt (5) in the nosepiece (2) from the side. Press the lever (B) onto the bolt (5) from the opposite side. Mount the sleeve (8), the O-ring (7), the bearing (6) and the gasket (9).
  • Page 15 Repair Instructions No.184.11/98 PAGE PHE 50 H Mounting the Push the plastic housing (A) over the ma- auxiliary handle chine. Fit the cover (C). Insert the dust seal (6) into the front of the plastic housing (A). Mount the tightening strap (B), the screw (7), cover (8), support (5), depth gauge (9) and clamping ring (4).
