  • Page 1 GDIB46LB & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L V. GDIB46LB-20240408...
  • Page 2 W a r n i n g , S a f e t y & M a i n t e n a n c e                              ...

  • Page 3: Table Of Contents

    T a b l e o f C o n t e n t s • SAFETY INSTRUCTIONS......PAGE 4 • PREPARATION..........PAGE 5 • HARDWARE ILLUSTRATION......PAGE 6 • PART / HARDWARE LIST....... PAGE 10 • ASSEMBLY INSTRUCTIONS......PAGE 12 • EXPLODED VIEW..........

  • Page 4: Safety Instructions

    Before beginning assembly, please take the time that we can assist you better. to read the instructions thoroughly. 1. Model Number m Read each step in the assembly instructions and 2. Place of Purchase follow the steps in sequence. Do not skip ahead. 3. Serial Number (S/N) If you skip ahead, you may learn later that you 4. Part # and Description have to disassemble components and that you may have damaged the equipment. m Assemble and operate the GDIB46LB on a solid, level surface. Locate the unit a few feet from the walls or furniture to provide easy access.

  • Page 5: Preparation

    Thank y ou f or p urchasing t he machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. Required Tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each the GDIB46LB include but are not limited to: step. While you may be able to assemble the GDIB46LB using the illustrations only, important safety notes and other m Standard Wrench Set tips are included in the text. m Metric Wrench Set Some pieces may have extra holes that you will not use.

  • Page 6: Hardware Illustration

    G D I B 4 6 L B H a r d w a r e I l l u s t r a t i o n                             Part #1 M12x85mm HEX HEAD BOLT QTY.
  • Page 7 G D I B 4 6 L B H a r d w a r e I l l u s t r a t i o n                             Part #5 M10x20mm BUTTON HEAD CAP SCREW QTY.

  • Page 8: M8 Flat Washer

    G D I B 4 6 L B H a r d w a r e I l l u s t r a t i o n                             Part #9 M10 LOCK WASHER QTY.
  • Page 9 G D I B 4 6 L B H a r d w a r e I l l u s t r a t i o n                             Part #13 M12 NYLON LOCK NUT QTY.

  • Page 10: Part / Hardware List

    G D I B 4 6 L B P a r t s & H a r d w a r e L i s t Part# Description FRONT BASE FRAME SIDE BASE FRAME LOWER MIDDLE FRAME RIGHT UPRIGHT UPPER MIDDLE FRME LEFT UPRIGHT BACK FRAME SUPPORT ADJUSTABLE UPRIGHT...
  • Page 11 G D I B 4 6 L B P a r t s & H a r d w a r e L i s t Part# Description T-HANDLE PULL PIN PLASTIC END CAP, 25x25mm FOOT CAP, 50x50mm PLASTIC END CAP, 38x38mm METAL BUSHING, ø20xø12.6x10mm QUICK RELEASE PULL PIN FOAM ROLLER, ø90x185mm PLASTIC END CAP, ø60mm ROUND DOME PLASTIC END CAP, ø50mm PLASTIC END CAP, 45x45mm...

  • Page 12: Assembly Instructions

    S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. DO NOT wrench tighten until instructed. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tightened to fully go on.
  • Page 13 S T E P Above shows Step 1 assembled and completed.
  • Page 14 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 2B. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 15 S T E P Above shows Step 2 assembled and completed.
  • Page 16 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 3E. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 17 S T E P Above shows Step 3 assembled and completed.
  • Page 18 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 4B. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 19 S T E P Above shows Step 4 assembled and completed.
  • Page 20 N o t e s...

  • Page 21: Exploded View

    G D I B 4 6 L B E x p l o d e d V i e w...

  • Page 22: Contact Page

    GDIB46LB PLEASE WRITE YOUR SERIAL NUMBER IN THE BOXES BELOW 000766-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product.
