  • Page 1 USER MANUAL ENGLISH V1.0 SPA-100 Streaming Pre-Amplifier Product code: D1242...
  • Page 2 SPA-100 Streaming Pre-Amplifier Preface Thank you for purchasing this DAP product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.

  • Page 3: Table Of Contents

    SPA-100 Streaming Pre-Amplifier Table of contents 1. Introduction ............................
  • Page 4 SPA-100 Streaming Pre-Amplifier 9. Deinstallation, Transportation and Storage ...................

  • Page 5: Introduction

    After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: Figure 1 • • DAP SPA-100 Streaming Pre-Amplifier • • Schuko to IEC power cable (1,5 m) • •...

  • Page 6: Symbols And Signal Words

    SPA-100 Streaming Pre-Amplifier 1.4. Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in death or DANGER serious injury.

  • Page 7: Safety

    SPA-100 Streaming Pre-Amplifier Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. 2.1. Warnings and Safety Instructions...

  • Page 8: Requirements For The User

    SPA-100 Streaming Pre-Amplifier • • Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the required power consumption of the device. Attention General safety   • • Do not shake the device. Avoid brute force when installing or operating the device.

  • Page 9: Description Of The Device

    Description of the Device The DAP SPA-100 Streaming Pre-Amplifier is a casting media player that can be installed into a 19-inch rack. In addition to an audio input, it has Bluetooth 5.0 with aptX HD support and has a USB/MP3 player that supports AAC, AAC+, ALAC, APE, FLAC, MP3 and WAV file formats.

  • Page 10: Product Specifications

    SPA-100 Streaming Pre-Amplifier 3.3. Product Specifications Model: SPA-100 Streaming Pre-Amplifier Inputs: Stereo Inputs 1  Stereo Input Connector RCA  Outputs: Main Outputs 1  Main Output Connector 3-pin XLR / RCA  Playback: Supported Audio Files AAC/AAC+ / ALAC / APE / FLAC / MP3 / WAV ...

  • Page 11: Dimensions

    SPA-100 Streaming Pre-Amplifier Width 483 mm Flightcase Size 19"  Rack Units 1 U Housing Steel  Colour Black  Weight 1,51 kg IP Rating IP20 (indoor use only)  Thermal Specifications: Minimum Ambient Temperature 0 °C Included Items: Included Cables IEC cable  Included Remotes IR Remote battery not included ...

  • Page 12: Installation

    The device has 1 unbalanced RCA analog input (L + R), 1 unbalanced RCA analog output (L + R) and 1 balanced XLR output (L + R). Turn off the SPA-100 when connecting audio devices in order to avoid interference. •...

  • Page 13: Connecting To Power Supply

    SPA-100 Streaming Pre-Amplifier 4.6. Connecting to Power Supply DANGER Electric shock caused by short-circuit The device accepts AC mains power at 240 V and 50 Hz. Do not supply power at any other voltage or frequency to the device. This device falls under IEC protection class I. Make sure that the device is always electrically connected to the ground (earth).

  • Page 14: Setup

    SPA-100 Streaming Pre-Amplifier Setup 5.1. Warnings and Precautions Attention Connect all data cables before supplying power. Disconnect power supply before connecting or disconnecting data cables. 5.2. Setup Example The figure below shows a typical setup with 2 streaming devices and 2 active speakers connected through an amplifier to the device.

  • Page 15: Network Setup

    5.5. Network Setup You can connect the SPA-100 directly to a network with a CAT-5e or CAT 6 cable. Internet access is automatic. No further action is necessary. To connect the SPA-100 to a network via Wi-Fi, follow the steps below: 1) Install the 4STREAM app on your Android or iOS device.
  • Page 16 SPA-100 Streaming Pre-Amplifier 5) Press 'indicator is blinking'. Note: The indicator on the SPA-100 does not blink! 6) Press 'pair via wifi'. Product code: D1242...
  • Page 17 SPA-100 Streaming Pre-Amplifier 7) Press 'Settings'. 8) Select the SPA-100 in available networks.   Product code: D1242...
  • Page 18 SPA-100 Streaming Pre-Amplifier 9) Following the internet quality check, press 'Connect only this time' or 'Always connect'. 10) Return to the app. 11) If required, enter the Wi-Fi network password of your chosen network. Note: Press 'Change Wi-Fi' to select a different Wi-Fi network.
  • Page 19 SPA-100 Streaming Pre-Amplifier 12) Press 'Continue'.     Product code: D1242...
  • Page 20 SPA-100 Streaming Pre-Amplifier 13) Press 'Settings' to connect your device to the same network as the SPA-100. 14) Return to the app. The device will now connect to your network. 15) Press 'Next' to name the device (see 6.5.2.1. Rename on page 23).

  • Page 21: Operation

    01) Press the mode button (01) on the SPA-100 until the Bluetooth symbol appears. 02) Enable Bluetooth on your Bluetooth device. 03) Scan for available devices on your Bluetooth device. The ID of the SPA-100 is 'SoundSystem'. 04) Press 'SoundSystem' on your Bluetooth device to begin pairing.

  • Page 22: Audio Input Playback

    Note: The USB player mode overrides all other modes on the SPA-100. The SPA-100 is compatible with USB drives (max. capacity 128 GB) formatted to exFAT / FAT16 / FAT32 and supports the following file formats: AAC / AAC+ / ALAC / APE / FLAC/ MP3 / WAV 6.3.

  • Page 23: Wi-Fi Control

    SPA-100 Streaming Pre-Amplifier 6.5. Wi-Fi Control The SPA-100 can be controlled with Wi-Fi via the 4STREAM app after it has been configured (see 5.5. Network Setup on page 14). 6.5.1. 4STREAM App Browse Tab From the browse tab, you can preset content (see 6.5.2.4.

  • Page 24: 4Stream App Device Tab

    SPA-100 Streaming Pre-Amplifier 6.5.2. 4STREAM App Device Tab In the app device tab, you can add new devices to the setup, synchronize play, adjust the volume, select left, right and stereo channels and access the following settings by pressing the settings icon: •...
  • Page 25 SPA-100 Streaming Pre-Amplifier • • Master Room • • Media Room • • Patio • • Playroom • • Pool • • Portable • • TV Room To set the device name: 01) Press on the existing name to enter a custom name, or;...

  • Page 26: Speaker Info

    SPA-100 Streaming Pre-Amplifier 6.5.2.2. Speaker Info This screen shows the speaker info. From this screen, it is also possible to set up a personal hotspot, change the audio prompts language and restore factory settings. To setup a personal hotspot: 01) Press the 'Personal Hotspot' button.

  • Page 27: Alarm Clock

    SPA-100 Streaming Pre-Amplifier 6.5.2.3. Alarm Clock This screen shows the alarm clock. To add an alarm: 1) Press '+' in the top right corner. Product code: D1242...

  • Page 28: Preset Content

    SPA-100 Streaming Pre-Amplifier 2) Set the hours and minutes. 3) Press the 'Repeat' button to choose specific days of the week. 4) Press 'Music' to select the sound source. 5) Set the volume using the slide control. 6) Press 'Duration' to set the duration. Press the 'No limit' button for no duration or press 'Duration' to select hours and minutes.

  • Page 29: Sleep Timer

    SPA-100 Streaming Pre-Amplifier 6.5.2.5. Sleep Timer To set the sleep timer: 01) Press the 'Sleep Timer' button. 02) Select 10Min, 20Min, 30Min, 60Min or 90Min with the sliding bar. 6.5.2.6. Audio Settings To turn the Fade-In and Fade-Out Effects on and off, press the Fade-In and Fade-Out Effects button.

  • Page 30: Functions Of The Remote Control Buttons

    SPA-100 Streaming Pre-Amplifier 6.6. Functions of the Remote Control Buttons Button Description Function On/Off Turns standby mode on/off Brightness Changes the display brightness Mute Turns mute on/off Turns USB mode on Aux in Turns audio input mode on Volume +...

  • Page 31: Troubleshooting

    SPA-100 Streaming Pre-Amplifier Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage.

  • Page 32: Maintenance

    SPA-100 Streaming Pre-Amplifier Maintenance 8.1. Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. 8.2. Preventive Maintenance Attention Before use, examine the device visually for any defects. Make sure that: •...
  • Page 33 Approval Hereby, Highlite International declares that the device SPA-100 Streaming Pre-Amplifier, product code D1242, is in compliance with Directive 2014/53/EU (RED – Radio Equipment Directive). The full text of the EU declaration of conformity is available on the respective product page on the website of Highlite International (www.highlite.com).
  • Page 34 SPA-100 Streaming Pre-Amplifier   Product code: D1242...
  • Page 35 SPA-100 Streaming Pre-Amplifier   Product code: D1242...
