Instrukcja podłączenia VFI 5000 EVS do LiFePO4 48-100 (10134063)
VFI 5000 EVS to LiFePO4 48-100 (10134063) connection guide
Spis treści
1)
Informacje ogólne ........................................................................................................................... 1
2)
Zawartość opakowań VFI 5000 EVS oraz LiFePO4 48-100 (10134063) ........................................... 2
2.1
Zawartość opakowania VFI 5000 EVS ......................................................................................... 2
2.2
Zawartość opakowania LiFePO4 48-100 (10134063) ................................................................. 2
3)
Montaż produktów ......................................................................................................................... 3
1) Informacje ogólne
Przed przystąpieniem do instalacji tych artykułów należy zapoznać się z tym pomocnym
przewodnikiem.
Ważna uwaga:
Poniższe artykuły NIE będą dołączone do opakowania żadnego z tych artykułów.
Należy je nabyć we własnym zakresie lub skorzystać z pomocnych adresów URL lub inne miejsce, w
którym można je kupić.
1) 2 x kabel bateryjny / instalacyjny 4 AWAG [25 mm2]
bateryjnego LiFePO4 48-100 (10134063) lub pomiędzy dwoma modułami [wymaga ≥ sztuk modułów
10134063].
Można użyć tych kabli:
Czerwony; 4 AWG:
https://www.tme.eu/pl/details/h07v2-k2500rd/przewody-jednozylowe-
linka/helukabel/64223/
Czarny; 4 AWG:
https://www.tme.eu/pl/details/h07v2-k2500bk/przewody-jednozylowe-
linka/helukabel/64219/
2) Zaciskarka / praska hydrauliczna
do drugiego końca kabli akumulatora 4 AWG [25 mm2]. Szczegółowe informacje znajdują się w
punkcie 1)
https://www.tme.eu/pl/details/ht1p169/zaciskarki-koncowek-kablowych/hogert-technik/
3) Karta BMS (SKU: 10131017) do połączenia z bankiem energii LiFePO4 48-100 przez Ethernet,
dodawana w zestawie VFI 5000 EVS i LiFePO4 48-100 (10134063) lub zakupiona osobno*
*Zależy od aktualnie oferowanej promocji.
do podłączenia VFI 5000 EVS do modułu
do zaciśnięcia złączy akumulatora (dostarczonych z 10134063)
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VFI 5000 EVS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PowerWalker VFI 5000 EVS

  • Page 1 4 AWG [25 mm2]. Szczegółowe informacje znajdują się w punkcie 1) https://www.tme.eu/pl/details/ht1p169/zaciskarki-koncowek-kablowych/hogert-technik/ 3) Karta BMS (SKU: 10131017) do połączenia z bankiem energii LiFePO4 48-100 przez Ethernet, dodawana w zestawie VFI 5000 EVS i LiFePO4 48-100 (10134063) lub zakupiona osobno* *Zależy od aktualnie oferowanej promocji.
  • Page 2 2) Zawartość opakowań VFI 5000 EVS oraz LiFePO4 48-100 (10134063) 2.1 Zawartość opakowania VFI 5000 EVS Przed instalacją należy sprawdzić urządzenie. Upewnij się, że nic wewnątrz opakowania nie jest uszkodzone. W opakowaniu powinny znajdować się następujące elementy: • Urządzenie x 1 •...
  • Page 3 3) Montaż produktów Przygotuj kartę VFI 5000 EVS i BMS 10131017 i umieść kartę komunikacyjną w inteligentnym gnieździe zasilacza UPS (po uprzednim usunięciu śrub i pustego panelu).
  • Page 4 Za pomocą dostarczonego kabla Ethernet z kartą BMS 10131017 podłącz jeden koniec do karty podczas gdy drugi koniec musi być podłączony do boku banku energii LiFePO4 48-100 (10134063) Należy upewnić się, że przełącznik główny LiFePO4 48-100 (10134063) jest ustawiony we właściwej pozycji.
  • Page 5 W przypadku więcej niż jednego modułu bateryjnego w systemie równoległym, moduł bateryjny podłączony do UPS jest baterią główną, a kod ID powinien być ustawiony na 0. Aby uzyskać więcej informacji, zapoznaj się z instrukcją obsługi LiFePO4 48-100 (10134063). Należy również upewnić się, że dołączona zworka RJ-11 jest podłączona zgodnie z wykresem po prawej stronie Następnie należy przygotować...
  • Page 6 W przypadku drugiego końca kabli 4 AWG należy wykonać następujące kroki, aby prawidłowo zacisnąć złącza akumulatora. Poluzować i zdemontować dostarczone wtyczki złącza akumulatora. Następnie przełóż kabel akumulatora przez tunel i obudowę, a następnie odizoluj kabel akumulatora na długości 11,5±0,2 mm. 11.5±0.2 Zaciśnij kabel i wtyczkę...
  • Page 7 Podsumowując, schemat podłączenia kabla akumulatora 4 AWG jest następujący: Jeśli podłączonych jest więcej niż jeden moduł baterii, użyj kabla bateryjnego, aby połączyć główny moduł bateryjny i pozostałe moduły jeden po drugim, jak na poniższym schemacie.
  • Page 8: General Information

    Guide contents General information ........................8 Package contents of the VFI 5000 EVS and LiFePO4 48-100 (10134063) ........9 Package contents of the VFI 5000 EVS ..................9 Package contents of the LiFePO4 48-100 (10134063) ..............9 Product installation ........................10 1) General information Before proceeding with installation of these articles, please read this helpful guide.
  • Page 9 2) Package contents of the VFI 5000 EVS and LiFePO4 48-100 (10134063) 2.1 Package contents of the VFI 5000 EVS Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should have received the following items inside of package: •...
  • Page 10: Product Installation

    3) Product installation Please prepare the VFI 5000 EVS and BMS card 10131017 and place the communication card inside of the UPS’s intelligent slot (upon first removing the screws and blank panel). Using the provided Ethernet cable with BMS card 10131017 please connect the one end to...
  • Page 11 Please make sure the Master Switch of the LiFePO4 48-100 (10134063) is switched to the correct position. Depending on how many battery modules are connected, the master switch configuration needs to be changed. If more than one battery module in the parallel system, the battery module connected to the UPS is the Master battery and the ID code should be set as 0.
  • Page 12 The end result should look like the picture on the right. For the other end of the 4 AWG cables, please follow these steps to successfully clamp the battery connectors. Loosen and disassemble the provided plugs of the supplied battery connector. Next, insert the battery cable through the tunnel and housing, and strip battery cable 11.5±0.2mm.
  • Page 13 To summarize, the 4 AWG battery cable connection scheme is as follows:...
