- Page 1 E-Bike components User manual Rear wheel motor...
-
Page 2: Table Of Contents
Contents Safety information Riding the E-Bike Product characteristics and specifications Display Battery Battery charger Charging the battery Battery charging indicator Charging alternatives Battery faults Battery state of health (SOH) Inserting the battery Removing the battery Switching the bike ON/OFF Placing and removal of the display Base screen display 1. -
Page 3: Safety Information
Use of other battery packs can cause injury and involve a f Ensure that the wheels are securely attached to the bike before risk of fire. If you use other battery packs, SR Suntour will as- you begin your trip. If the wheels are not securely attached, the sume no liability or warranties. -
Page 4: Riding The E-Bike
Riding the E-Bike Fit the battery and push the battery ON/OFF button Note: If the battery is not used for 24 hours or longer, it will automatically go into sleep mode. Press the power button on the battery for three seconds. 0,5 Sec. -
Page 5: Product Characteristics And Specifications
Product characteristics Display Switch Battery Motor Torque sensor Product specifications Operating temperature range during discharge -20°C to 60°C Operating temperature range during charge 0°C to 45°C Storage temperature (battery) -20°C to 45°C Humidity (storage) up to 80% Charging voltage 100V to 240VAC Charging time approx. -
Page 6: Display
Display Power Key Display Display holder Dust cover Switch USB connector to charge your smartphone DIST TRIP Distance travelled DIST TOTAL Information Cumulative distance BAT LEVEL Battery level Assist mode SPORT (Assist level:4) Increase assist level CLIMB (Assist level:3) TOUR (Assist level:2) (Assist level:1) Assist mode... -
Page 7: Battery
Display Plug WARNING f Use only batteries and chargers from SR SUNTOUR with your bike. Use of other battery packs can cause injury and involve TYPE F a risk of fire. If you use other battery packs, we will assume no liability or honour warranties. -
Page 8: Charging The Battery
Charging the battery Ensure that the power plug is fully inserted into the wall outlet. GREEN The charger LED will change to green when the battery is fully charged Battery charging indicator Flashing (0.5s ON / 0.5s OFF) 100% 0 Hours 3 Hours 6 Hours Charging time... -
Page 9: Charging Alternatives
Charging alternatives Separate from the bike On the bike Battery faults If the battery is not working properly press the ‘Power’ button on the battery pack briefly. If it displays any of the LED sequences shown below stop using the battery. Flashing 0,5s ON / 0,5s OFF Over tempera-... -
Page 10: Inserting The Battery
Inserting the battery The battery must latch on with an audible click. Removing the battery 0.5 sec The bike is supplied with four battery keys. Re- placement keys are not available and any further keys required will have to be cut. Please keep at least one of the keys in a safe place. -
Page 11: Switching The Bike On/Off
Switching the bike ON/OFF SWITCHING ON 0.5 sec If the system has not been used for 0.5 sec more than 24 hours, the battery will be completely switched off. The battery can be reactivated by pressing the ON button. 0.5 sec SWITCHING OFF 10 min. -
Page 12: Base Screen Display
Base screen display Battery charge level Indication of assist level Info display Current speed (range: 0.0 to 99.9) Assist modes 1. Km/h <-> mph setting: When DIST TRIP or DIST TOTAL is displayed, you can choose between km/h & km or mph & miles. Press the “i”... -
Page 13: Battery State Of Charge (Soc)
4. Battery State of charge (SOC) Press the button briefly, one of the following patterns of the LEDs will be displayed. Indication on battery > =75% 50 to 75% 30 to 50% 10 to 30% < 10% Flashing <10% 76 to 99% (0.5 s ON / 0.5 s OFF) Flashing 51 to 75%... -
Page 14: Changing Trip Information
6. Changing trip information DIST TRIP: Distance travelled Unit: 0.1 km / miles Measurement range: 0.0 to 999.9 km / miles 0.5 Sec. (default setting) BAT LEVEL: Battery charge level RESETTING Unit: % TRIP DISTANCE Measurement range: 0% to 99% 0.5 Sec. -
Page 15: Headlight And Taillight
Headlight and taillight (if applicable) Power on/off Technical data Nominal voltage 6V 2 sec Output power: 3.0 W Charging support function Power supply for external devices via USB port. The USB connector allows you Mini-USB port to charge most devices Output: 5VDC 0.5A with a mini-USB port. -
Page 16: Removing The Rear Wheel (To Repair A Puncture)
Removing the rear wheel (to repair a puncture) 1. Cut the cable ties holding the waterproof motor cable connector under the non-drive side chain stay. Separate the two halves of the connector this requires some ‘wiggling’ of the connector to over- come the sealing. -
Page 17: Error Codes
Error codes In the rare event of a system malfunction, an error message will appear on the display. If an error message appears, turn the system completely OFF and then ON. If the error message still appears, contact your local dealer for assistance. Error Problem Description Trouble shooting... - Page 20 Spare parts phone: +49 8021 50793-11 Fax: +49 8021 50793-29 Email: service@srsuntour-cycling.com hesc@srsuntour-cycling.com SRSUNTOUR Düsseldorf GmbH (Sales) Kieshecker Weg 153 40468 Düsseldorf Germany Phone: +49 2119 84366-22 Fax: +49 2119 84366-23 www.srsuntour-cycling.com SR SUNTOUR HESC User Manual http://www.facebook.com/srsuntour Published: October 2016...
