OUTDOOR UNIT AIR CONDITIONER
Owner's Manual
Models:
KVM-20VAH1M-O
KVM-30VAH1M-O
KVM-40VAH1M-O
KVM-50VAH1M-O
Please read this instruction manual before using the product.
Read carefully before attempting to assemble, install, operate or maintain the product described.
Installation shall be done by Authorized Service Partners.
Retain these instructions for future reference.
Advertisement
Table of Contents
Related Manuals for Kolin Versatech KVM-20VAH1M-O
Summary of Contents for Kolin Versatech KVM-20VAH1M-O
- Page 1 OUTDOOR UNIT AIR CONDITIONER Owner’s Manual Models: KVM-20VAH1M-O KVM-30VAH1M-O KVM-40VAH1M-O KVM-50VAH1M-O Please read this instruction manual before using the product. Read carefully before attempting to assemble, install, operate or maintain the product described. Installation shall be done by Authorized Service Partners. Retain these instructions for future reference.
-
Page 3: Table Of Contents
Children should be supervised to ensure that they do not play with the appliance. If it needs to install, move or maintain the air conditioner, please contact Kolin hotline or authorized service partners to conduct it at first. Air conditioner must be installed, moved or maintained by appointed unit. -
Page 4: General Information
EXPLANATION OF SYMBOLS GENERAL INFORMATION Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury. -
Page 5: The Refrigerant
THE REFRIGERANT GENERAL INFORMATION Please read this operating manual carefully before operating the unit. to the material objects for reference. The Refrigerant To realize the function of the air conditioner unit, a special refrigerant circulates lead to explosion . It can Compared to common refrigerants, R32 is a nonpolluting refrigerant with no lower. -
Page 6: Warning
Do not repair air conditioner by yourself. It may cause electric shock or damage. Please Kolin hotline or authorized service partners when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet. It may cause personal injury or damage. - Page 7 GENERAL INFORMATION WARNING If the air conditioner operates under abnormal conditions, it may cause malfunction，electric shock or fire hazard. When turning on or turning off the unit by emergency operation switch, please press this switch with an insulating object other than metal. Do not step on top panel of outdoor unit, or put heavy objects.
- Page 8 GENERAL INFORMATION WARNING The air conditioner is the first class electric appliance. It must be properly grounding with specialized grounding device by a professional. Please make sure it is always grounded effectively, otherwise it may cause electric shock. The yellow-green wire in air conditioner is grounding wire, which can't be used for other purposes.
-
Page 9: The Instructions Before Use
THE INSTRUCTIONS BEFORE USE GENERAL INFORMATION WARNING When having a burning smell or The power supply must adopt the Never cut off or damage power ★ ★ ★ smoke,please turn off the power special circuit that with air switch cables and control wires. If the supply and contact with the ser- protection and assure it has enou- power cable and signal control... -
Page 10: Name Of Parts
NAME OF PARTS GENERAL INFORMATION WARNING Be sure to cut off the power supply before cleaning the air conditioner; otherwise electric shock might happen. Wetting of air conditioner may cause the risk of electric shock. Make sure not to wash your air conditioner in any case. -
Page 11: Installer
ELECTRICAL CONNECTIONS INSTALLER KVM-20VAH1M-O 1. Remove the handle at the right side plate of the An all-pole disconnection switch having a contact outdoor unit (one screw). separation of at least 3mm in all pole should be connected in fixed wiring. Remove the cable clamp, connect the power connection cable with the terminal at the row of Wrong wire connection may cause malfunction of... - Page 12 ELECTRICAL CONNECTIONS INSTALLER GWHD(24)ND6BO，GWHD(28)ND6BO KVM-30VAH1M-O Remove the handle at the right side plate of the An all-pole disconnection switch having a contact outdoor unit (one screw). separation of at least 3mm in all pole should be connected in fixed wiring. Remove the cable clamp, connect the power connection cable with the terminal at the row of Wrong wire connection may cause malfunction of...
- Page 13 ELECTRICAL CONNECTIONS INSTALLER GWHD(36)ND6BO KVM-40VAH1M-O Remove the handle at the right side plate of the An all-pole disconnection switch having a contact outdoor unit (one screw). separation of at least 3mm in all pole should be connected in fixed wiring. Remove the cable clamp, connect the power connection cable with the terminal at the row of Wrong wire connection may cause malfunction of...
- Page 14 ELECTRICAL CONNECTIONS INSTALLER GWHD(42)ND6BO KVM-50VAH1M-O 1. Remove the handle at the right side plate of the An all-pole disconnection switch having a contact outdoor unit (one screw). separation of at least 3mm in all pole should be connected in fixed wiring. Remove the cable clamp, connect the power connection cable with the terminal at the row of Wrong wire connection may cause malfunction of...
-
Page 15: Installing The Outdoor Unit
INSTALLING THE OUTDOOR UNIT INSTALLER Location Install the drain fitting and the drain hose Use bolts to secure the unit to a flat, solid floor. (for model with heat pump only) When mounting the unit on a wall or the roof, make sure the support is firmly secured so that it cannot Condensation is produced and flows from the out- move in the event of intense vibrations or a strong... -
Page 16: Maintenance
The installation must be done by trained and qualified service personnel with reliability according to this manual. Contact Kolin hotline or authorized service partners before installation to avoid the malfunction due to unprofessional installation. When picking up and moving the units, you must be guided by trained and qualified person. -
Page 17: Check After Installation
CHECK AFTER INSTALLATION INSTALLER Check items Problems owing to improper installation Is the installation reliable? The unit may drop, vibrate or make noises May cause unsatisfactory cooling (heating) Has the gas leakage been checked? effect Is the thermal insulation of the unit May cause condensation and water dropping sufficient? Is the drainage smooth? -
Page 18: Safety Operation Of Flammable Refrigerant
SAFETY OPERATION OF FLAMMABLE REFRIGERANT INSTALLER Qualification requirement for installation and maintenance man All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualification for dealing with the refrigeration system recognized by this industry. If it needs other technician to maintain and repair the appliance, they should be supervised by the person who bears the qualification for using the flammable refrigerant. -
Page 19: Specialist's Manual
SPECIALIST’S MANUAL INSTALLER The following checks shall be applied to installations using flammable refrigerants: – the charge size is in accordance with the room size within which the refrigerant containing parts are installed; – the ventilation machinery and outlets are operating adequately and are not obstructed; –... - Page 20 SPECIALIST’S MANUAL INSTALLER adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans. Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks.
- Page 21 The design and specifications are subject to change without prior notice for product improvement. Any updates to the manual will be uploaded to the service website, please check for the latest version. If you have any concerns, please contact us at the following: Customer hotline: (02) 8852-6868 Text hotline: +63 917-881-8982...
-
Page 23: Service Centers
Tiktok : kolinphilippines Website : www.kolinphil.com.ph OFFICE PLANT Kolin Bldg.1854 Sta. Rita St., Blk 3 Lot 5, Main Drive First Cavite Guadalupe Nuevo, Makati City, 1212 Industrial Estate, Langkaan 1, Service Hotline: (632) 8852 - 6868 Dasmariñas City, Cavite Tel. No.: (046) 402-0793...
