CEILING CASSETTE

AIR CONDITIONER

Owner's Manual

Models:

KVM-10ISAH-I

KVM-15ISAH-I

KVM-20ISAH-I

KVM-25ISAH-I

Please read this instruction manual before using the product.

Read carefully before attempting to assemble, install, operate or maintain the product described.

Installation shall be done by Authorized Service Partners.

Retain these instructions for future reference.

Table of Contents

Need help?

Do you have a question about the KVM-10ISAH-I and is the answer not in the manual?

Questions and answers

Summary of Contents for Kolin KVM-10ISAH-I

Page 1 CEILING CASSETTE AIR CONDITIONER Owner’s Manual Models: KVM-10ISAH-I KVM-15ISAH-I KVM-20ISAH-I KVM-25ISAH-I Please read this instruction manual before using the product. Read carefully before attempting to assemble, install, operate or maintain the product described. Installation shall be done by Authorized Service Partners.
Page 3: Table Of Contents
1. Safety Precautions ................2. Outline of the Unit and Main Parts ........... 3. Operation of remote controller ......................3.1. Buttons on remote controller ......... 3.2. Introduction for icons on display screen ......3.3. Introduction for buttons on remote controller ......
Page 4 Please read this operating manual carefully before operating the unit. to the material objects for reference. The Refrigerant ● To realize the function of the air conditioner unit, a special refrigerant circulates lead to explosion . It can ● Compared to common refrigerants, R32 is a nonpolluting refrigerant with no lower.
Page 5: Safety Precautions
This mark indicates procedures which, if improperly performed, might lead to the death WARNING! or serious injury of the user. This mark indicates procedures which, if improperly performed, might possibly result in CAUTION! personal harm to the user, or damage to property. WARNING! 1.
Page 6 16. Be sure to establish an earth. Do not earth the unit to a utility pipe, arrester, or telephone earth. Incomplete earth may cause electrical shock, or fire. A high surge current from lightning or other sources may cause damage to the air conditioner. 17.
Page 7: Outline Of The Unit And Main Parts
O N / O FF MOD E I FEEL T- O N T- O FF 1. Drain age device T E M P C L O C K L I G H T i F i S L E E P 2.
Page 8: Operation Of Remote Controller
• Buttons on remote controller • Introduction for icons on display screen I feel Set fan speed Turbo mode Send signal Auto mode Cool mode Dry mode Fan mode Heat mode Sleep mode 8℃ heating function Power limiting operation Health mode ON/OFF Scavenging function X-FAN function...
Page 9: Introduction For Buttons On Remote Controller
• Introduction for icons on display screen • When selecting heating mode, the air condition- er operates under heat mode. Press " " or " " NOTE: button to adjust set temperature. Press "FAN" This is a general use remote controller. It could button to adjust fan speed.
Page 10 turn to quick COOL or quick HEAT mode. " " ically swing up & down at maximum angle. icon is displayed on remote controller. Press this ● When selecting " " , air condition- 、、、、 button again to exit turbo function and " "...
Page 11 Sleep, circulate between these, after electrified, NOTE Sleep Cancel is defaulted. ● Under on and off status, you can set T-OFF or T-ON Sleep 1 is Sleep mode 1, in Cool modes; sleep ● simultaneously. ● status after run for one hour, the main unit setting Before setting T-ON or T-OFF, please adjust the clock time.
Page 12: Function Introduction For Combination Buttons
WiFi 3.4 Function introduction for combination buttons " " i urn on WiFi functio " , " i icon will be displayed on the remote controller; Energy-saving function Hold " WiFi " button for 5s to turn off WiFi function and "...
Page 13: Replacement Of Batteries In Remote Controller
Child lock function Press " " and " " simultaneously to turn on or turn off child lock function. When child lock func- tion is on, " " icon is displayed on remote control- ler. If you operate the remote controller , the " "...
Page 14: Preparative For Installation
4.1 Selection of the Installation Location WARNING! otherwise the unit would topple or fall off. ① . Do not install where there is the danger of combustible gas leakage. ② . ③ . Children under 10 years old must be supervised not to operate the unit. Decide the installation location with the customer as follows:...
Page 15: Connection Pipe Requirement
KVM-10ISAH-I KVM-15ISAH-I KVM-20ISAH-I KVM-25ISAH-I CAUTION! KVM-10ISAH-I, KVM-15ISAH-I KVM-20ISAH-I KVM-25ISAH-I...
Page 16: Electrical Requirement
Indoor & Outdoor Communication KVM-10ISAH-I KVM-15ISAH-I 3.15 4x 2mm² 230V~ 60Hz KVM-20ISAH-I KVM-25ISAH-I ① ② ③ . ④ .
Page 17: Installation Of The Unit
35mm or less. If the distance between the ceiling and the unit is above 35mm, add some ceiling material to shorten the distance. See the following diagram. KVM-10ISAH-I, KVM-15ISAH-I, KVM-20ISAH-I KVM-10ISAH-I, KVM-15ISAH-I KVM-20ISAH-I...
Page 18 For the units: KVM-25ISAH-I Fig.3 Table 5 Unit: mm Dimensions Model KVM-25ISAH-I...
Page 19: Installation Of The Indoor Unit
5.1.2 Installing the Main Body Unit Fig.4 (1). Install the hoisting stand on the hoisting screw by using nuts and gaskets at both the upper and lower sides of the hoisting stand. To prevent the gasket from breaking off, a gasket anchor board can be helpful.
Page 20: Installation Of The Connection Pipe
5.1.4 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below. Fig.8 5.2 Installation of the Connection Pipe 5.2.1 Flare Processing (1). Cut the connection pipe with the pipe cutter and remove the burrs. (2).
Page 21 .2.2 Bending Pipes (1). The pipes are shaped by your hands. Be careful not to collapse them. Fig.10 (2). Do not bend the pipes in an angle more than 90°. Pipe Heat insulating (3). When pipes are repeatedly bent or stretched, the material pipe will Cutter...
Page 22 hand tight and then tighten it with the spanner. Refer to Table to check if the wrench has been tightened properly (too tight would mangle the nut and lead to leakage). Examine the connection pipe to see if it leaks, then take the treatment of heat insulation, as shown in the Fig.12.
Page 23 .2.4 Connecting the Pipe at the Outdoor Side Unit connector. The tightening method is the same as that as at the indoor side. .2.5 Checking the Pipe Connections for Gas Leaking For both indoor and outdoor unit side, check the joints for gas leaking by the use of a gas leakage detector without fail when the pipes Fig.13...
Page 24: Vacuum And Gas Leakage Inspection
If the outdoor unit is installed higher than the indoor unit (See Fig.16) (1). Taping should be done from lower to the upper part. (2). All pipes are bound and taped together and also should be trapped to prevent water from returning to the room. (3).
Page 25 (7). Slightly open the liquid valve and let some refrigerant go to the connection pipe to balance the pressure inside and outside of the connection pipe, so that air will not come into the connection pipe when removing the hose. Note that the gas and liquid valve can be opened fully only after the manifold valve assembly is removed.
Page 26: Installation Of The Drain Hose
It is not allowed to apply PVC or other Metal clamp ① related glue in the joints of two ends of drain Drain hose ② pipe. Small sponge ③ Metal clamp ① Large sponge ② Indoor Unit KVM-10ISAH-I, KVM-15ISAH-I, ≤12 KVM-20ISAH-I KVM-25ISAH-I ≤ 15...
Page 27 (3). When unifying multiple drain pipes, install the pipes as Fig.20. Select converging drain pipes whose gauge is suitable for the operating capacity of the unit.(take the cassette type unit for example) T-joint converging drain pipes T-joint converging drain pipes Fig.20 (4).
Page 28 3-way connection Connection of drain elbow of drainage pipe joint Connection of horizontal pipe Fig.24 Fig.25 Fig.26 5.4.3 Precautions When Doing Riser Piping Work (1). Make sure that heat insulation work is executed on the following 2 spots to prevent any possible water leakage due to dew condensation.
Page 29: The Panel Installation
Check Drainage .4.4 After the pipeline work is finished, check whether the drainage can go smoothly. (1) Add slowly about 1L of water into the water tray. After the electric circuit is completed, check the drainage condition during refrigerating operation. Single-phase units(09~24k) N(1) black brown yellow-...
Page 30 (4) Screw up the screws until the thickness of the sealing material between the front panel and the ceiling is 5-8mm. NOTES: (1) Improper screw looseness will lead to the following problem. (2) After the screws are tightened, if there is still a gap between the ceiling and the decorative front panel, adjust the height of the unit again (as shown below).
Page 31: Electrical Wiring
(3) After installing the front panel, make sure there’s no gap between the unit and the front panel. (4) Circuit of the decorative front panel. (5) Connect the front panel to the main body through the corresponding slots. Match the slots according to their different size. WARNING! After installing the panel, the insulated protective cover with the thickness of 1mm shall be used to wrap the wiring terminal, Tighten the insulated glue cover on both...
Page 32 CAUTION! ① . The power source capacity must be the sum of the air conditioner current and the current of other capacity. ② . raise the voltage. 5.6.2 Electrical Wiring (1). For solid core wiring (Fig.3 ) 1). Cut the wire end with a wire cutter or wire-cutting pliers, then strip the insulation about 25 mm (15/16") .
Page 33 After passing the connection cord fasten it with the cord clamp.(Fig.38) WARNING! . Before starting work, check that power is not being supplied to the indoor unit and outdoor unit. ① ② . Match the terminal block numbers and connection cord colors with those of the indoor unit side. ③...
Page 34: Installation Of Controller
CAUTION! Tighten the power cord respectively on the terminal boards with ① . If the power supply are wired incorrectly, the air conditioner may be damaged. ② . Connect the indoor unit connection cord properly based on the corresponding marks as shown in ③...
Page 35 Jumper cap malfunction protection Loading EEPROM malfunction Note: If there're other error codes, please contact qualified Kolin service hotline or authorized service partners. When the unit is connected with the wired controller, the error code will be simultaneously shown on it.
Page 36 (2). Instructions to the Error Indicating Lamps on the Panel of the Cassette Type Unit. KVM-10ISAH-I, KVM-15ISAH-I, KVM-20ISAH-I: Drying Heating "88" Display Receiver Indicating Lamp Indicating Lamp Cooling Power Indicating Lamp Indicating Lamp KVM-25ISAH-I: Receiver "88" Display "Auto" Button Timer Power "Test"...
Page 37: Troubleshooting And Maintenance
Note: After carrying out the check of the above items and taking relevant measures to solve the problems but the air-conditioning unit still does not function well, please stop the operation of the unit immediately and contact the Kolin service hotline or authorized service partners . Only ask professional serviceman to check and repair the unit.
Page 38: Routine Maintenance
8.2 Routine Maintenance Only a qualified service person is allowed to perform maintenance Before accessing to terminal devices, all power supply circuits must be disconnected. Do not use water or air of 50°C or higher for cleaning air filters and outside panels Notes: Do not operate the air conditioner with the filter uninstalled, otherwise dust would come into ①...
Page 39 How to clean the air filter (3) Disassemble the air purifier Remove the air purifier after removing the fixed screws on (4) Cleaning the filer screen vacuum cleaner remove dust or rinse the filter. the filter is very dirty (greasy), use warm water (below 45°C)
Page 40: Installation Notes
Qualification requirement for installation and maintenance man All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualification for dealing with the refrigeration system recognized by this industry. If it needs other technician to maintain and repair the appliance, they should be supervised by the person who bears the qualification for using the flammable refrigerant.
Page 41: Safety Instructions For Transportation And Storage
a. Shut down the unit and cut power supply b. Eliminate the refrigerant c. Vacuuming d. Clean it with N e. Cutting or welding f. Carry back to the service spot for welding The refrigerant should be recycled into the specialized storage tank. Make sure that there isn’t any naked flame near the outlet of the vacuum pump and it’s well-ventilated.
Page 42: Specialist's Manual
The following checks shall be applied to instal- General work area lations using flammable refrigerants: All maintenance staff and others working in the – the charge size is in accordance with the room size local area shall be instructed on the nature of work within which the refrigerant containing parts are in- being carried out.
Page 43 - the actual refrigerant charge is in accordance with incorrect fitting of glands, etc. the room size within which the refrigerant contain- – Ensure that the apparatus is mounted securely. ing parts are installed; – Ensure that seals or sealing materials have not de- - the ventilation machinery and outlets are operat- graded to the point that they no longer serve the pur- ing adequately and are not obstructed;...
Page 44 most refrigerants but the use of detergents contain- does not occur when using charging equipment. Hoses or lines shall be as short as possible to ing chlorine shall be avoided as the chlorine may minimise the amount of refrigerant contained in react with the refrigerant and corrode the copper them.
Page 45 the cylinder, even temporarily. not in cylinders. If compressors or compressor oils are to be remov- j) When the cylinders have been filled correctly and ed, ensure that they have been evacuated to an ac- the process completed, make sure that the cylinders ceptable level to make certain that flammable refri- and the equipment are removed from site promptly gerant does not remain within the lubricant.
Page 46 The design and specifications are subject to change with- out prior notice for product improvement. Any updates to the manual will be uploaded to the service website, please check for the latest version. If you have any concerns, please contact us at the following: Customer hotline: (02) 8852-6868 Text hotline: +63 917-881-8982...
