  • Page 2: Table Of Contents

    Content Operation Notices Precautions ........................... 1 Parts name ..........................6 Operation Guide Button’s Name and Function ....................7 Introduction for icons on display screen of air conditioner ............ 7 Button’s introduction ......................8 Buttons on remote controller ....................11 Introduction for icons on display screen ................11 Introduction for buttons on remote controller ..............

  • Page 3: Precautions

    Precautions WARNING Operation and Maintenance This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4 Precautions WARNING Maintenance must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Do not repair air conditioner by yourself. It may cause electric shock or damage. Please contact dealer when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet.
  • Page 5 Precautions WARNING Attachment Installation must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Must follow the electric safety regulations when installing the unit. According to the local safety regulations, use qualified power supply circuit and circuit break. Do install the circuit break.
  • Page 6 Precautions WARNING Do not put through the power before finishing installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
  • Page 7 Precautions WARNING For the air conditioner with plug, the plug should be reachable after finishing installation. For the air conditioner without plug, an circuit break must be installed in the line. If you need to relocate the air conditioner to another place, only the qualified person can perform the work.

  • Page 8: Parts Name

    Parts’ Name Indoor Unit air outlet display button remote control box panel display and button air inlet AUTO HEALTH X-FAN HUMIDITY FILTER TURBO HOUR ON/OFF ON/OFF MODE receiving window X-FAN TEMP TIMER TURBO SLEEP LIGHT (Display content or position may be different from above remote controller graphics, please refer to actual products) Outdoor Unit...

  • Page 9: Button's Name And Function

    Button’s Name and Function ON/OFF button MODE button FUNCTION button SPEED button ▼/▲ button Introduction for icons on display screen of air conditioner up&down swing mode operation mode left&right swing mode heat mode fan mode dry mode X-fan mode cool mode auto mode timer display operation indicator...

  • Page 10: Button's Introduction

    Button’s introduction Caution: ● After putting through the power, the air conditioner will give out a sound. Opera- tion indictor “ ” is ON (red indicator). After that, you can operate the air condi- tioner by the control panel. ● Under ON status, after each pressing of button on control panel, icons on display screen will ON.
  • Page 11 Button’s introduction ● When pressing this button to select up&down swing function, the corresponding icon flashes. Meanwhile, press “▲” or “▼” button can start up or turn off up&down swing. ● When pressing this button to select left&right swing function, the corresponding icon flashes.
  • Page 12 Button’s introduction ● Press this button to select indoor ambient temperature display function, “ROOM TEMP” figures flashes. Meanwhile, press “▲” or “▼” button and indoor ambient temperature will be defaulted to display. SPEED button ● When pressing this button, fan speed will switch among "auto→low→medium→ high→...

  • Page 13: Buttons On Remote Controller

    Buttons on remote controller ON/OFF button AUTO HEALTH X-FAN MODE button HUMIDITY FILTER +/- button TURBO FAN button HOUR ON/OFF button button ON/OFF MODE HEALTH SAVE button X-FAN button (Note: X-FAN is same with BLOW) TEMP button TIMER button X-FAN TEMP TIMER TURBO button...

  • Page 14: Introduction For Buttons On Remote Controller

    Introduction for buttons on remote controller Note: ● After putting through power, air conditioner will give out a sound and operation indicator " " is ON (red indicator). You can operate the air conditioner through the remote controller. ● At ON status, after each pressing button on remote controller, the signal icon " "...
  • Page 15 Introduction for buttons on remote controller Note: For preventing cold wind, after starting up heating mode, indoor fan will blow fan afterdelaying 1-5min. (Details time is decided by indoor ambient temperature) Temperature setting range on remote controller: 16℃ -30℃ . Fan speed setting range: auto, low speed, medium speed and high speed.
  • Page 16 Introduction for buttons on remote controller Note: When selecting " " with remote controller, it’s auto swing. Horizontal louver of air conditioner will swing up&down automatically at the maximum angle. When selecting " 、 、 、 、 swing. Horizontal louver of air conditioner will stop at that position as shown by the icon to swing.
  • Page 17 Introduction for buttons on remote controller SAVE function: Under cool mode, press SAVE button and the unit will operate under SAVE mode. Dual-8nixie tube on remote controller displays "SE". Air conditioner will operate at auto speed. Set temperature can’t be adjusted. Press SAVE button again to exit SAVE mode.

  • Page 18: Function Introduction For Combination Buttons

    Introduction for buttons on remote controller hour. When holding "+" or "-" button, 2s later, the time will change quickly until to Cancel TIMER OFF: Press "TIMER" button again under TIMER OFF status. ● At OFF status, press this button once can set TIMER ON. Please refer to TIMER off for detailed operation.

  • Page 19: Operation Guide

    Operation guide 1. After putting through the power, press " " button on remote controller to ON/OFF turn on the air conditioner. 2. Press " " button to select your required mode: AUTO, COOL, DRY, FAN, MODE HEAT. 3. Press "+" or "-" button to set your required temperature. (Temperature can’t be adjusted under auto mode).

  • Page 20: Clean And Maintenance

    Clean and maintenance WARNING ■ Turn off the air conditioner and disconnect the power before cleaning the air conditioner to avoid electric shock. ■ Do not wash the air conditioner with water to avoid electric shock. ■ Do not use volatile liquid to clean the air conditioner. Clean surface of indoor unit When the surface of indoor unit is dirty, it is recommended to use a soft dry cloth or wet cloth to wipe it.
  • Page 21 Clean and maintenance NOTICE: Checking before use-season 1. Check whether air inlet and air outlet are blocked. 2. Check whether air switch, plug and socket are in good condition. 3. Check whether filter is clean. 4. Check whether the remote controller is installed with batteries.

  • Page 22: Malfunction

    Malfunction General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still can’t be eliminated, please contact local dealer or qualified professionals. Phenomenon Check items Solution ● Whether it's interfered severely ● Pull out the plug. Reinsert (such as static electricity, stable the plug after about 3min, and voltage)?
  • Page 23 Malfunction Phenomenon Check items Solution ● Because indoor air is cooled Mist is emitted rapidly. After a while, indoor ● Indoor temperature and hum- from indoor temperature and humidity will idity is high? be decrease and mist will di- unit’s air outlet sappear.
  • Page 24 Malfunction Phenomenon Check items Solution Air conditioner ● Disconnect power, put back ● Whether there’s interference, operates power, and then turn on the such as thunder, wireless normally unit again. devices, etc. suddenly ● During defrosting under heating mode, it may gener- Outdoor unit ●...
  • Page 25 Malfunction Error code ● When air conditioner status is abnormal, temperature indictor on indoor unit will blink to display corresponding error code. Please refer to below list for identific- ation of error code. Error code Troubleshooting It can be eliminated after restarting the unit. If not, please contact qualified professionals to deal with it.

  • Page 26: Installation Dimension Diagram

    Installation dimension diagram Away from wall (30cm at least for piping side) Away from obstacles Away from wall (30cm at least for piping side) Away from back side...

  • Page 27: Safety Precautions For Installing And Relocating The Unit

    Safety precautions for installing and relocating the unit To ensure safety, please be mindful of the following precautions. Warning When installing or relocating the unit, be sure to keep the refrigerant circuit free from air or substances other than the specified refrigerant. Any presence of air or other foreign substance in the refrigerant circuit will cause system pressure rise or compressor rupture, resulting in injury.

  • Page 28: Tools For Installation

    Tools for installation 1 Level meter 2 Screw driver 3 Impact drill 4 Drill head 5 Pipe expander 6 Torque wrench 7 Open-end wrench 8 Pipe cutter 9 Leakage detector 10 Vacuum pump 11 Pressure meter 12 Universal meter 13 Inner hexagon spanner 14 Measuring tape Note: ●...

  • Page 29: Requirements For Electric Connection

    Requirements for electric connection Safety precaution 1. Must follow the electric safety regulations when installing the unit. 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. 3.

  • Page 30: Installation Of Indoor Unit

    Installation of indoor unit Step one: choosing installation location Recommend the installation location to the client and then confirm it with the client. Step two: open piping hole 1. Choose the position of piping hole according to the direction of outlet pipe. 2.
  • Page 31 Installation of indoor unit open-end wrench 2. Aim the pipe joint at the correspo- nding bellmouth. union nut pipe torque wrench indoor pipe pipe joint union nut pipe Hex nut diameter(mm) Tightening torque (N . m) Φ 6.35 (1/4”) 15.7 (1.6kg.m) Φ...
  • Page 32 Installation of indoor unit 2. Remove the wire clip; connect the power connection wire to the wiring terminal according to the color; tighten the screw and then fix the power connection wire with wire clip. GVC36AH-D3NNB1A GVC60AH-F3NNB1A N(1) yellow- yellow- blue black brown blue black brown green...
  • Page 33 Installation of indoor unit 2. Reserve a certain length of drain hose and power cord for installation when binding them. When binding to a certain degree, separate the indoor power and then separate the drain hose. drain hose connection pipe band indoor power cord 3.

  • Page 34: Installation Of Outdoor Unit

    Installation of outdoor unit Step one: fix the support of outdoor unit (select it according to the actual installation situation) 1. Select installation location according to the house structure. 2. Fix the support of outdoor unit on the selected location with expansion screws. Note: ●...
  • Page 35 Installation of outdoor unit Step four: connect indoor and outdoor pipes 1. Remove the front side plate or handle. pipe joint union nut handle 3. Pretightening the union nut with hand. 4. Tighten the union nut with torque wrench by referring to the sheet 2.
  • Page 36 Installation of outdoor unit 2. Fix the power connection wire and signal control wire with wire clip (only for cooling and heating unit). Note: ● After tightening the screw, pull the power cord slightly to check if it is firm. ●...

  • Page 37: Vacuum Pumping

    Vacuum pumping Use vacuum pump piezometer 1. Remove the valve caps on the liquid valve and gas valve and the nut of refrigerant charging vent. 2. Connect the charging hose of piezo- gas valve meter to the refrigerant charging vent liquid valve valve cap of gas valve and then connect the...

  • Page 38: Check After Installation

    Check after installation ● Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been installed firmly? The unit may drop, shake or emit noise. Have you done the refrigerant leakage It may cause insufficient cooling test? (heating) capacity.

  • Page 39: Installation Instructions Of Anti-Collapse Chain

    Installation instructions of anti-collapse chain ● In order to prevent accidental collapse of indoor unit, please install the anti-collapse chain. Installation steps: 1. Remove the screw of anti-collapse hole at the top cover of indoor unit (see fig. 3); 2. Take out the anti-collapse chain and put it into the anti-collapse hole, and then tighten it with screw (see fig.

  • Page 40: Configuration Of Connection Pipe

    Configuration of connection pipe 1. Standard length of connection pipe ● 5m, 7.5m, 8m. 2.Min. length of connection pipe is 3m. 3.Max. length of connection pipe. Max length Max length Cooling Cooling of connec- of connec- capacity capacity tion pipe tion pipe 5000Btu/h 24000Btu/h...
  • Page 41 Configuration of connection pipe Additional refrigerant charging amount for R22, R407C, R410A and R134a Diameter of connection pipe Outdoor unit throttle Liquid pipe(mm) Gas pipe(mm) Cooling only(g/m) Cooling and heating(g/m) Φ6 Φ9.52 or Φ12 Φ6 or Φ9.52 Φ16 or Φ19 Φ12 Φ19 or Φ22.2 Φ16...

  • Page 42: Pipe Expanding Method

    Pipe expanding method Note: Improper pipe expanding is the main cause of refrigerant leakage. Please expand the pipe according to the following steps: A: Cut the pipe E: Expand the port ● Expand the port with expander. the distance of indoor unit and hard outdoor unit.
