75.0036.06 LZR-FLATSCAN 3D SW 20230824
LZR
-FLATSCAN 3D SW
®
SAFETY SENSOR
FOR AUTOMATIC SWING DOORS
User's Guide for software version SW 0100
and higher
(refer to tracking label on product)
MISCELLANEOUS
FIRE DOOR ACCESSORY
< R39071 >
Page 1 of 16
Advertisement
Table of Contents
Related Manuals for Halma BEA LZR-FLATSCAN 3D SW
Summary of Contents for Halma BEA LZR-FLATSCAN 3D SW
- Page 1 Visit website for available languages of this document. -FLATSCAN 3D SW ® SAFETY SENSOR FOR AUTOMATIC SWING DOORS User’s Guide for software version SW 0100 MISCELLANEOUS and higher FIRE DOOR ACCESSORY < R39071 > (refer to tracking label on product) 75.0036.06 LZR-FLATSCAN 3D SW 20230824 Page 1 of 16...
-
Page 2: Installation Tips
INSTALLATION TIPS Avoid the presence Avoid vibrations. Do not cover Avoid moving objects of smoke and fog in the laser window. and light sources in the detection field. the detection field. 14 °F 14 °F Avoid condensation. Avoid exposure to Keep the sensor permanently sudden and extreme powered in environments... - Page 3 DESCRIPTION ® -FLATSCAN 3D SW is a safety sensor for automatic swing doors based on laser technology. It protects the moving door leaf as well as the pinch zone. To do so, a sensor must be installed in the upper corner of the door leaf(s). PRIMARY-SECONDARY CABLE 35.1329 COVER...
- Page 4 FOREWORD The FLATSCAN 3D SW can be paired with another FLATSCAN 3D SW or a FLATSCAN SW. The installation steps are identical for both product versions. For optimum safety and to access all features (e.g. opening functions), the FLATSCAN 3D SW must be the primary sensor. MOUNTING ON DOOR For applications requiring a spacer, use the provided Mounting Template (78.7001) to mount spacer to door, and then install sensor onto spacer.
- Page 5 MOUNTING ON DOOR (cont.) On the other side of the door, connect the primary- Secure the secondary sensor to the door using the secondary cable to the secondary sensor in the same three provided screws. manner (i.e. through the back). «click»...
- Page 6 WIRING TO DOOR CONTROLLER BEA recommends using a FLATSCAN 3D SW as the primary sensor. Determine the appropriate length for the door loop. Cut the excess to avoid undesired detections caused by the flexible tube. Pass the power cable through the flexible tube and Create a loop with the wires of the power cable and connect the white plug to the white connector.
-
Page 7: Wiring: Cables
WIRING: CABLES Cut the power cable to the correct length, strip the 10 wires, and connect all wires as indicated. Observe polarity. 12-24 VDC POWER SUPPLY BLACK OUTPUT 1 BLUE STOP IMPULSE NO/NC BROWN Swing side of the door OUTPUT 2 GREEN NO/NC REOPENING IMPULSE... -
Page 8: Testing And Adjusting
TEACH-IN Before launching a teach-in, make sure that: • glass surfaces near the door are covered • when a guide rail is involved in the application, an object should be placed between the full-open door and guide rail to create a larger reference point for the learn •... - Page 9 VIRTUAL PUSH BUTTONS (OUTPUT 3) Always verify compliance with ANSI 156.10, 156.19, and 156.38. If desired and in addition to ANSI 156.10, 156.19, and 156.38 Knowing Act requirement, you can add a Virtual Push Button option (max. 2 per sensor) within the second (C2) curtain simulating the performance of a knowing-act device.
- Page 10 DIP SWITCH SETTINGS (OPTIONAL) 1 2 3 4 In order to adapt these parameters by remote control, set the corresponding DIP switch to ON. (switch up) (switch down) Switch to CRITICAL when external disturbances DIP 2 ENVIRONMENT are likely to cause unwanted detections (min. obj size, standard critical immunity, and uncovered zone are increased).
- Page 11 REMOTE CONTROL SETTINGS (OPTIONAL) In order to change these settings by remote control, ensure that DIP switch 2 is set to ON UNCOVERED ZONE ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ Increase in case of snow, debris, etc. * measured in specific conditions and dependant on application and installation. BACKGROUND / In order to change these settings by remote control, ensure that DIP switch 3 is set to ON ANTIMASKING...
-
Page 12: How To Use The Remote Control
HOW TO USE THE REMOTE CONTROL After unlocking, the red LED If the red LED flashes quickly after unlocking, you need To end an adjustment flashes and the sensor can be to enter an access code from 1 to 4 digits. session, always lock the adjusted by remote control. -
Page 13: Service Mode
DETECTION FIELDS 80° 20° 4 in UNCOVERED ZONE PINCH ZONE SAFETY DOOR LEAF SAFETY adjustable by remote control factory value: 4 in Check the detection fields using our online sizer tool: https://eu.beasensors.com/sizer/flatscan/ SERVICE MODE Service Mode deactivates all detection fields for 15 minutes and can be useful during an installation, a mechanical learn of the door, or maintenance work. -
Page 14: Troubleshooting
TROUBLESHOOTING In case of unwanted reactions of the door, verify whether the problem is caused by the sensor, the door controller, or a nearby radar sensor. To do so, activate Service Mode (no safety) and cycle the door open. Be sure to exit Service Mode when finished with troubleshooting activities. - Page 15 TROUBLESHOOTING (cont.) The ORANGE LED is on The sensor encounters a Replace sensor. permanently. memory problem. The ORANGE LED flashes DIP switch setting awaiting Confirm the DIP switch setting: long push on quickly. confirmation. the push button. The ORANGE LED flashes The sensor signals an Cut and restore power supply.
-
Page 16: Technical Specifications
TECHNICAL SPECIFICATIONS Technology LASER scanner, time-of-flight measurement Detection mode Presence Max. detection range 13' (diagonal) with reflectivity of 2% (e.g. W = 5' max. H = 12') Recommended mounting height 75 – 98" Opening angle Door leaf safety: 80° Pinch zone safety: 20°...
