- Page 1 Range Name: Willow Box 1 dimensions: W95xD48.5xH20(cm) Product Dimension: W80xD40xH80(cm) Willow Sideboard Up to 45 minutes Two person assembly time assembly This product is intended for domestic use only, not for commercial purposes. P-1/15 V-2.0...
- Page 2 IMPORTANT ASSEMBLY TIP Before you begin, it's best to identify all of the parts and fittings to build your sideboard frame. We advise laying these out on the floor to check you have everything, and to familiarise yourself with all of the parts and fittings before building.
- Page 3 Parts list 14 x2 P-3/15...
- Page 4 Parts list Before you begin building your Willow Sideboard, please take a moment to read through the instructions and make sure that you have all the relevant parts listed on the parts check list. Part Description Quantity Part Description Quantity...
- Page 5 1. Attach parts to Sideboard Top, Side Panels and Middle Panel. Ø8*30mm Dowel 6pcs M6*35mm Bolt M4*14mm Screw Wall Bracket 10pcs 2pcs 2pcs 2. Attach Centre Support to Side Panels and Middle Panel. Ø8*60mm Dowel Ø15mm Cam Lock Ø8*30mm Dowel P-5/15 4pcs 2pcs...
- Page 6 3. Attach Sideboard Top to Side Panels and Middle Panel. Ø15mm Cam Lock 6pcs 4. Slide Back Panels into the Frame. P-6/15...
- Page 7 5. Attach the Bottom Panel onto the frame. Allen Key M7*48mm Screw Ø8*30mm Dowel 6pcs 6pcs 6. Attach the Leg Side Support to the Legs. Allen Key M6*40mm Bolt P-7/15 4pcs...
- Page 8 7. Attach the Legs to the frame. Ax10 Allen Key M6*30mm Bolt 10pcs 8. Attach the Plastic Buckles. Plastic Buckle M3.5*14mm Screw P-8/15 8pcs 8pcs...
- Page 9 9. Fix the Wall Bracket to the wall. Ø6*30mm Wall Plug M4*35mm Screw 2pcs 2pcs 10. Attach Bolts to the Drawer Front. M6*35mm Bolt P-9/15 8pcs...
- Page 10 11. Assemble the Drawers. M4*35mm Screw 8pcs 12. Slide the Drawer Bottom into the Drawer. P-10/15...
- Page 11 13. Attach the Drawer Front and tighten the CAM Locks. Ø15mm Cam Lock Ø20mm Sticker 8pcs 8pcs 14. Attach the Handle. Handle M4*20mm Bolt P-11/15 2pcs 2pcs...
- Page 12 15. Slide the Drawers into the Frame. 16. Attach the Hinges and Handles to the Door Panels. Hinge Handle M4*20mm Bolt M3.5*14mm Screw P-12/15 2pcs 2pcs 4pcs 8pcs...
- Page 13 17. Attach the Door Panels to the frame. M3.5*14mm Screw P-13/15 16pcs...
- Page 14 18. Attach the Shelf pins to the frame. Ø5*14mm Shelf Pin 8pcs 19. Slide the shelves into the frame. P-14/15...
- Page 15 P-15/15...
